Accessories - Skutt EnviroVent 2 Operating Manual

Accessories

14
14
Dual Intake Kit
The Dual Intake Kit is used when you are venting 2 kilns that are each at or under 12 Cubic Feet or when you
are venting a single kiln between 12 and 24 Cubic Feet. The kit contains the following items:
• Two 8 ft. x 3" Flexible Aluminum Duct
• One Spring Loaded Plenum Cup Assembly
Cast Plenum Cup
Fiber Gasket
Plenum Stand w/Base
Plenum Spring
• Four Hose Clamps
• One Y Duct Connector
Extension Kit
The Extension Kit is used when you need additional ducting than what is provided with a standard Envirovent
2. The kit contains the following items:
• One 8 ft. x 3" Flexible Aluminum Duct
• Two Hose Clamps
• One 3" Connector
Individual Fittings
3" Connector
EnviroLink
The EnviroLink is an accessory item that can be ordered for the
EnviroVent and Envirovent 2 that works in conjunction with the Skutt
KilnMaster or GlassMaster controller. It allows you to program the con-
troller to automatically turn the vent on and off throughout a firing pro-
gram. You simply enter an on/off setting for each segment of a Ramp and
Hold program while you are programming the kiln. There are preset "vent
programs" that can be run in conjunction with a ConeFire Mode program
as well. If ordering for a kiln that is equipped with a Link Board, be sure to
order the EnviroLink for Link Board version.
3" to 4" Connector 3" Y Duct Connector
14
