- Page 1 KEROSENE FORCED AIR HEATER operation manual HK070F HK125FW HK175FW HK215FW...
-
Page 2: Table Of Contents
Safety 6 Safety Rules 7 Safety Warnings 10 Unpacking Features 11 Features of Model HK070F 11 Features of Models HK125FW/HK175FW Assembly 12 Hardware Components 12 Frame Components for Models HK125FW/ HK175FW/HK215FW 13 Attaching Handle for Model HK070F 13 Assembly Cord Wrap 13 Assembly Frame and Wheels Models HK125FW/HK175FW/HK215FW 14 Assembly Cord Wrap Operation 15 Kerosene (1-K) 15 Theory of Operation 16 Fueling the Heater 17 Ventilation 17 Starting the Heater 18 Stopping the Heater 18 ... - Page 3 Exploded View 28 Exploded View Parts List 29 HK070F 31 HK125FW 33 HK175FW 35 HK215FW Parts List 37 Model HK070F 37 Model HK125FW/HK175FW/HK215FW Warranty 38 Limited Warranty...
- Page 4 introduction Attention: Read through the complete manual prior to the initial use of your Compressor Using the Operator’s manual The operating manual is an important part of your Heater and should be read thoroughly before initial use, and referred to often to make sure adequate safety and service concerns are being addressed. Reading the owner’s manual thoroughly will help avoid any personal injury or damage to your heater. By knowing how best to operate this machine you will be better positioned to show others who may also operate the unit. You can refer back to the manual at any time to help troubleshoot any specific operating functions, so store it with the machine at all times.
-
Page 5: Product Identification
product identification Record Identification Numbers Heater If you need to contact an Authorized Dealer or Customer Service line (1- 866-770-1711) for information on servicing, always provide the product model and identification numbers. You will need to locate the model and serial number for the heater and record the information in the places provided below. Date of Purchase: Dealer Name: Dealer Phone: Product Identification Numbers Model Number: Serial Number:... -
Page 6: Safety
safety Save these Instructions SAFETy RULES This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. The safety alert symbol ( ) is used with a signal word (DANGER, CAUTION, WARNING), a pictorial and/or a safety message to alert you to hazards. DANGER indicates a hazard which, if not avoided, will result in death ... - Page 7 safety WARNING • FIRE, BURN, INHALATION, AND EXPLOSION HAZARD. KEEP SOLID COMBUSTIBLES, SUCH AS BUILDING MATERIALS, PAPER OR CARDBOARD, A SAFE DISTANCE AWAY FROM THE HEATER AS RECOMMENDED BY THESE INSTRUCTIONS. NEVER USE THE HEATER IN SPACES WHICH DO OR MAY CONTAIN VOLATILE OR AIRBORNE COMBUSTIBLES, OR PRODUCTS SUCH AS GASOLINE, SOLVENTS, PAINT THINNERS, DUST PARTICLES OR UNKNOWN CHEMICALS. WARNING • NOT FOR HOME OR RECREATIONAL USE. WARNING • Do not operate this heater until you have read, and thoroughly understand these safety and operating instructions. WARNING • This heater is NOT suitable for use with Bio-Diesel; use of Bio-Diesel will damage he filter and seals. Any damage caused by using Bio- Diesel will not be covered by warranty WARNING Risk of indoor air pollution • Use this heater only in well ventilated areas! Provide at least a three square foot (2,800 sq cm) opening of outside air for every 100,000 BTU/hr of heater rating. • People with breathing problems should consult a physician before using the heater. • Carbon Monoxide Poisoning: Early signs of carbon monoxide poisoning resemble flu-like symptoms such as headaches, dizziness, and/or nausea. If you have these symptoms, your heater may not be working properly. Simply locate fan in safe, desired position on level ground, and connect to approved power source. • Get fresh air at once! Have the heater serviced. Some people are more affected by carbon monoxide than others. These include pregnant women, those with heart or lung problems, anemia, or those under the influence of alcohol, or at high altitudes.
- Page 8 safety DANGER Carbon Monoxide poisoning may lead to death! • Humans can tolerate small amounts of carbon monoxide, and precautions should be taken to provide proper ventilation. Failure to provide proper ventilation according to this manual can result in death. Early signs of carbon monoxide poisoning resemble the flu. Symptoms of improper ventilation are: * headache * dizziness * burning of the nose and eyes * nausea * dry mouth * sore throat • For optimal performance of this heater, it is strongly suggested that 1-K kerosene be used. 1-K kerosene has been refined to virtually eliminate contaminants, such as sulfur, which can cause a rotten egg odor during the operation of the heater. However, #1 or #2 fuel oil (diesel fuel) may also be used if 1-K kerosene is not available. Be advised that these fuels do not burn as clean as 1-K kerosene, and care should be taken to provide more fresh air ventilation to accommodate any added contaminants that may be added to the heated space. Use of #1 or #2 fuel oil may result in more periodic maintenance. WARNING Risk of Electric Shock! • ...
- Page 9 safety WARNING Risk of Burns/Fire/Explosion! • NEVER use fuels such as gasoline, benzene, paint thinners, or other oil compounds in this heater (RISK OF FIRE OR EXPLOSION). • NEVER refill the heater’s fuel tank while heater is operating or still hot. This heater is EXTREMELY HOT while in operation. • Keep all combustible materials away from this heater. • NEVER block air inlet (rear) or air outlet (front) of heater. • NEVER use duct work in front or at rear of heater. • NEVER move or handle heater while still hot. • NEVER transport heater with fuel in its tank. • If equipped with a thermostat, the heater may start at any time. • ALWAYS locate heater on a stable and level surface. • ALWAYS keep children and animals away from heater. • Bulk fuel storage should be a minimum of 25 ft. from heaters, torches, portable generators, or other sources of ignition. All fuel storage should be in accordance with federal, state, or local authorities having jurisdiction. • Never use this heater in living or sleeping areas. • NEVER use this heater where flammable vapors may be present. Minimum clearance from Combustibles: 70k 125k ...
- Page 10 safety UnpACkIng Remove the heater and all of the packaging materials from the shipping carton. NOTE: Save the box and packaging materials for future storage. Check the chart below to be sure that you have all of the parts required to assembly your heater. If you find that any parts are missing, call BE Pressure Supply at 1-800-663-8331 for assistance in receiving the missing components.
-
Page 11: Unpacking
Features Features FEATURES OF MODEL HK070F NEVER LEAVE HEATER UNATTENDED WHILE BURN ING OR WHILE CONNECTED TO A POWER SOURCE... -
Page 12: Assembly
Assembly HARDWARE COMPONENTS HK070F HK125FW HK175FW HK215FW Wheel support frame NEVER LEAVE HEATER UNATTENDED WHILE BURN- ING OR WHILE CONNECTED Wheel (2 pieces) TO A POWER SOURCE NEVER LEAVE HEATER Front and Rear Handle UNATTENDED WHILE BURN- Assembly ING OR WHILE CONNECTED TO A POWER SOURCE... -
Page 13: Attaching Handle For Model Hk070F
Assembly (Continued) ASSEMBLING CORDWRA MODELS PT-45/70T-KFA ONLY - Tools required: Medium phillips screw driver. ATTACHING HANDLE FOR MODEL HK070F 1. Align holes in cordwrap wit handle. Insert screws (B) th ASSEMBLING HANDLE tighten (see Figure 7.). Tools required: Medium phillips screw driver. 1.Align the holes in the upper housing with the 2 holes in the 1. Align the holes in the upper housing with the 2 holes in the handle. -
Page 14: Assembly Cord Wrap
NEVER LEAVE HEATER assembly UNATTENDED WHILE BURN- ING OR WHILE CONNECTED TO A POWER SOURCE Assembly (Continued) ASSEMBLy CORD WRAP ONLY ASSEMBLING CORDWRAP crew driver. 1. Align holes in cordwrap with corresponding holes in rear 1. Align holes in cord wrap with corresponding holes in rear handle. In- handle. Insert screws (B) through holes, attach nuts and sert screws (B) through holes, attach nuts and tighten (see Figure 7). -
Page 15: Operation
operation Operation KEROSENE (1-K) For optimal performance of this heater, it is strongly suggested that 1-K kerosene be used. 1-K kerosene has been refined to virtually eliminate contaminants, such as sulfur, which can cause a rotten egg odor during the operation of the heater. However, #1 or #2 fuel oil (diesel fuel) may also be used if 1-K kerosene is not available. Be advised that these fuels do not burn as clean as 1-K kerosene, and care should be taken to provide more fresh air ventilation to accommodate any added contaminants that may be added to the heated space. Using diesel fuel can cause excess soot production. DO NOT use any fuel that is not approved above. NOTICE Kerosene should only be stored in a blue container that is clearly marked “kerosene”. Never store kerosene in a red container. Red is as- sociated with gasoline. • NEVER store kerosene in the living space. Kerosene should be stored in a well ventilated area outside the living area. • NEVER use fuel such as gasoline, benzene, alcohol, white gas, camp stove fuel, paint thinners, or other oil compounds in this heater (THESE ARE VOLATILE FUELS THAT CAN CAUSE A FIRE OR EXPLOSION). • NEVER store kerosene in direct sunlight or near a source of heat. • NEVER use kerosene that has been stored from one season to the next. Kerosene deteriorates over time. OLD KEROSENE WILL NOT BURN PROPERLY IN THIS HEATER. • Use 1-K kerosene in this heater. #1 fuel is a suitable substitute. THEORy OF OPERATION Fuel System: This heater is equipped with an air pump that operates off of the electric motor. The pump forces air through the air line connected to the fuel tank, drawing fuel to the nozzle in the burner head. Air also ... -
Page 16: Fueling The Heater
operation Air System: A fan is turned by the heavy duty motor, which forces air around and into the combustion chamber, where it is super-heated and forced out the front of the chamber. Temperature Limit Control: This heater is equipped with a Temperature Limit Control designed to turn the heater off should the internal tempera- ture rise to an unsafe level. If this device activates and turns your heater off, it may require service. Once the temperature falls below the reset temperature, you will be able to start your heater. NEVER LEAVE HEATER Electrical System protection: The heaters’ electrical system is protected UNATTENDED WHILE BURN- by a circuit breaker that protects the system components from damage. If ING OR WHILE CONNECTED the heater fails, check the fuse first, and replace if necessary. TO A POWER SOURCE Flame Sensor: The heater uses a photocell to “see” the flame in the Operation combustion chamber. Should the flame extinguish, the sensor will stop electrical current and the heater will shut off. ggested ined to can cause a wever, #1 or ne is not... -
Page 17: Ventilation
operation WARNING • Never refuel this heater while it is hot or operating. Fire or explosion could result. VENTILATION Risk of indoor air pollution. Use heater only in well ventilated areas. Always provide a fresh air opening in the heated space of at least three square feet (2,800 sq. cm) for each 100,000 BTU/hr. of heater output. Provide a larger opening if more heaters are being used. STARING THE HEATER 1. Fill the tank with kerosene until fuel gauge points to “F”. 2. Be sure fuel cap is secure. 3. Plug power cord into three prong, grounded extension cord and plug extension cord into three prong 120V grounded outlet. The extension cord should be at least six feet long. Extension cord wire size requirements are as follows: • 6 to 10 feet (1.8 to 3 meters), use 18 AWG wire. • 11 to 100 feet (3.4 to 30.4 meters), use 16 AWG wire. • 101 to 200 feet (30.8 to 61 meters), use 14 AWG wire. 4. Turn thermostat control knob to desired temperature setting (70/125/175 only). The setting range is from 40° F to 110° F. Push the Power switch to the “ON” position (See figure 9). The power indi- cator lamp and room temperature display (125/175 only) will light and the heater will start. NOTICE The room temperature display (125/175 only) will indicate the following. -
Page 18: Stopping The Heater
Room Temp. Lamp 2. To remove Display(Except downward (except HK070F) PT-70T-KFA) Figure 11). Power Switch Power Switch Thermostat Control Knob Models PT-70T / 125T / 175T / 215T-KFA Model PT-45-KFA... -
Page 19: Long Term Storage
(See figure 9). PT-45 / 70T-KFA) 175/215 only) will rature display Storage Drawer (except will start. y says “LO”. (except HK070F) PT-45 / 70T-KFA) 75/215 only) will says “HI”. Electric Outlet (120v 5amp max al temperature. non fused) says “LO”. - Page 20 NEVER LEAVE HEATER UNATTENDED WHILE BURN- operation ING OR WHILE CONNECTED TO A POWER SOURCE Operation (Continued) se and swirl the Drain Plug ty the tank fully. nto the drain hole and Fuel Tank to the head hole (See Seal Head sene over the summer.
-
Page 21: Maintenance
UNATTENDED WHILE BURN- Drain Plug he tank fully. ING OR WHILE CONNECTED he drain hole and TO A POWER SOURCE Fuel Tank he head hole (See Operation (Continued) maintenance Seal Head e over the summer. and swirl the Drain Plug Head Flange the tank fully. -
Page 22: Nozzles
maintenance Maintenance (Continued) nOZZLES: NOZZLES: SPARK PLUG: Nozzles should be cleaned or replaced at least once per heating season. Nozzles should be cleaned or replaced at least once per heating Clean and re-gap ev Contaminated fuel could make this necessary immediately. To clean dirt season. Contaminated fuel could make this necessary needed.After removi from nozzle, blow compressed air through nozzle front. It may be neces- wire brush. Re-gap t immediately sary to soak nozzle in clean 1-K kerosene to help loosen any particles. To clean dirt from nozzle, blow compressed air through nozzle front. - Page 23 NEVER LEAVE HEATER UNATTENDED WHILE BURN- maintenance ING OR WHILE CONNECTED TO A POWER SOURCE NEVER LEAVE HEATER UNATTENDED WHILE BURN- Maintenance (Continued) ING OR WHILE CONNECTED TO A POWER SOURCE SPARK PLUG: enance (Continued) SpARk pLUg: st once per heating Clean and re-gap every 600 hours of operation, or replace as Clean and re-gap every 600 hours of operation, or replace as needed. ...
-
Page 24: Fuel Filter
1-K kerosene. Contaminated fuel NOTICE could make this necessary immediately (See Figure 19). To remove the filter from model HK070F, turn filter 90° clockwise. To NOTE: To remove the filter from models PT-45 / 70T-KFA, turn remove the filter from models HK125FW/HK175FW/HK215FW, turn filter 90 ° clockwise. To remove the filter from models PT-125T / Adjustin 175T / 215T-KFA, turn filter 90 °... -
Page 25: Pump Pressure Adjustment
While heater is operating, turn relief valve clockwise to increase, screwdriver to turn valve. Correct pump pressure is as follows: counterclockwise to decrease (see Figure 20). Use flat blade screwdriver Model # Pump Pressure to turn valve. Correct pump pressure is as follows: PT-45-KFA 3.0 PSI Model # Pump Pressure PT-70T-KFA 4.0 PSI HK070F 4.0 PSI PT-125T-KFA 5.0 PSI Board HK125FW 5.0 PSI PT-175T-KFA 7.5 PSI PT-215T-KFA 9.0 PSI HK175FW 7.5 PSI... -
Page 26: Troubleshooting
troubleshooting Troubleshooting TROUBLESHOOTING CHART Problem Possible Case Solution Heater fires, but Main 1. Incorrect pump pressure. 1. Adjust Pump Pressure (P.11) PCB shuts heater off 2. Dirty Input, Output or Lint 2. Clean/replace Air Filter (P.9) after a short period of Filter. 3. Clean/replace Fuel Filter time. Lamp is flickering, 3. Dirty Fuel Filter. (P.11) and LED display shows 4. Nozzle is Dirty. 4. Clean/replace Nozzle (P.10) “E1”. 5. Photocell lens is Dirty 5. Clean/replace Photocell (P. 6. Photocell not installed properly. 6. Adjust Photocell position 7. Photocell Defective (P.10) 8. Improper electrical 7. Replace Photocell (P.10) connection between 8. Check wiring connections Main PCB and Photocell. (See Wiring Diagrams, P.14) Heater will not operate, 1. No kerosene in fuel tank. 1. Fill tank with fresh kerosene or motor runs for short ... - Page 27 troubleshooting Problem Possible Case Solution Poor Combustion 1. Dirty Input, Output or Lint 1. Clean/replace Air Filter (P.9) and / or excess soot Filter. 2. Clean/replace Fuel Filter production. 2. Dirty Fuel Filter. (P.10) 3. Poor quality of fuel. 3. Be sure fuel is not 4. PSI is too high or too contaminated or old low. 4. Use proper pressure (P.11) Heater does not turn on 1. Temperature limit sensor 1. Push Power Switch to “OFF” and the lamp is not lit. has overheated. and allow heater to cool for 2. No electrical power. 10 minutes. Push Power 3. Fuse Blown. Switch to back to “ON” 4. Improper electrical 2. Check power cord and connection between extension cord to insure Temperature Limit Sensor of proper connection. Test and Circuit Board. power supply. 3. Check/replace Fuse. 4. Inspect all electrical connections. Wiring ...
-
Page 28: Exploded View
exploded view NEVER LEAVE HEATER UNATTENDED WHILE BURN- ING OR WHILE CONNECTED TO A POWER SOURCE Exploded View Exploded View (125/175/215 only) (70 only) (125/175/215 only) (125/175/215 only) (125/175/215 only) (125/175/215 only) 58 (125/175/215 (125/175/ only) 60 215 only) (125/175/215 only) (125/175/215 only) Figure 21: Exploded View for Models PT-45 / 70T / 125T / 175T / 215T-KFA ©... -
Page 29: Parts List
Parts List HK070F Item # Description HK070F 1 Fuel Tank Assembly 70-002-0100 2 Drain Plug – 3 Fuel Gauge Assembly 70-007-0115 4 Fuel Filter Assembly 70-003-0100 5 Fuel Cap 70-006-0100 Power Cord 70-034-0100 7 Power Switch 70-038-0100 8 Window Display – 9 Thermostat Control Knob 70-031-0100 10 Lower Shell – 11 Air Line 70-035-0200 ... - Page 30 Item # Description HK070F 39 Capacitor 70-020-0125 40 Fan Assembly 70-024-0200 Ignitor 70-037-0300 42 Right Side Cover 70-008-0200 43 Left Side Cover 70-009-0100 Fan Guard 70-016-0700 Main PCB Assembly 70-027-0200 46 Fuse 70-027-0101 47 Clip Nut 70-001-0105 48 Upper Shell – 49 Storage Box – 50 Bushing Grommet 70-017-0100 51 ...
-
Page 31: Hk125Fw
parts list HK125FW Item # Description HK125FW 1 Fuel Tank Assembly 70-002-0200 2 Drain Plug 70-002-0105 3 Fuel Gauge Assembly 70-007-0210 4 Fuel Filter Assembly 70-003-0200 5 Fuel Cap 70-006-0100 Power Cord 70-034-0200 7 Power Switch 70-038-0100 8 Window Display 70-040-0100 9 Thermostat Control Knob 70-031-0100 10 Lower Shell – 11 Air Line 70-035-0300 12 Thermostat Limit Control ... - Page 32 parts list Item # Description HK125FW Ignitor 70-037-0300 42 Right Side Cover 70-008-0300 43 Left Side Cover 70-009-0200 Fan Guard 70-016-0200 Main PCB Assembly 70-027-0300 46 Fuse 70-027-0101 47 Clip Nut 70-001-0105 48 Upper Shell – 49 Storage Box 70-053-0100 50 Bushing Grommet 70-017-0100 51 Socket Cover 70-030-0100 52 Air Pressure Gauge 70-025-0100 53 Cord Bushing ...
-
Page 33: Hk175Fw
parts list HK175FW Item # Description HK175FW 1 Fuel Tank Assembly 70-002-0300 2 Drain Plug 70-002-0105 3 Fuel Gauge Assembly 70-007-0210 4 Fuel Filter Assembly 70-003-0200 5 Fuel Cap 70-006-0100 Power Cord 70-034-0200 7 Power Switch 70-038-0100 8 Window Display 70-040-0100 9 Thermostat Control Knob 70-031-0100 10 Lower Shell – 11 Air Line 70-035-0400 12 Thermostat Limit Control ... - Page 34 parts list Item # Description HK175FW Ignitor 70-037-0300 42 Right Side Cover 70-008-0400 43 Left Side Cover 70-009-0300 Fan Guard 70-016-0200 Main PCB Assembly 70-027-0300 46 Fuse 70-027-0101 47 Clip Nut 70-001-0105 48 Upper Shell – 49 Storage Box 70-053-0100 50 Bushing Grommet 70-017-0100 51 Socket Cover 70-030-0100 52 Air Pressure Gauge 70-025-0100 53 Cord Bushing ...
-
Page 35: Hk215Fw
parts list HK215FW Item # Description HK215FW 1 Fuel Tank Assembly 70-002-0300 2 Drain Plug 70-002-0105 3 Fuel Gauge Assembly 70-007-0215 4 Fuel Filter Assembly 70-003-0200 5 Fuel Cap 70-006-0100 Power Cord 70-034-0200 7 Power Switch 70-038-0100 8 Window Display 70-040-0100 9 Thermostat Control Knob 70-031-0100 10 Lower Shell – 11 Air Line 70-035-0500 12 Thermostat Limit Control ... - Page 36 parts list Item # Description HK215FW Ignitor 70-037-0300 42 Right Side Cover 70-008-0450 43 Left Side Cover 70-009-0300 Fan Guard 70-016-0220 Main PCB Assembly 70-027-0300 46 Fuse 70-027-0101 47 Clip Nut 70-001-0105 48 Upper Shell – 49 Storage Box 70-053-0100 50 Bushing Grommet 70-017-0100 51 Socket Cover 70-030-0100 52 Air Pressure Gauge 70-025-0100 53 Cord Bushing ...
-
Page 37: Model Hk070F
UNATTENDED WHILE BURN- ING OR WHILE CONNECTED wiring diagrams TO A POWER SOURCE Wiring Diagrams Wiring Diagrams Wiring Diagrams MODEL HK070F Figure 23: Model PT-70T-KFA Figure 22: Model PT-45-KFA Figure MODEL HK125FW/HK175FW/HK215FW / 215T- Figure 23: Model PT-125T / 175T / 215T-... -
Page 38: Warranty
warranty LIMITED WARRANTY X-Stream warrants this heater to the original retail purchaser only, to be free from defects in material and workmanship for a period of one (1) year from the date of initial purchase. This product must be properly installed, maintained and operated in accordance with the instructions provided. - Page 39 warranty X-Stream assumes no responsibility for any defects caused by third parties. This Limited Warranty gives the purchaser specific legal rights; a purchaser may have other rights depending upon where he or she lives. Some states do not allow the exclusion or limitation of special, incidental or consequential damages, or limitations on how long a warranty lasts, so the above exclusion and limitations may not apply to you.
