Quick Start Guide T-Sinus 154 DSL
You will find full instructions in German on the CD-ROM supplied with the pack.
■
Overview
■
T-Sinus 154 DSL with built-in ADSL modem is a router providing access to the Internet via DSL for wired and
wireless inhouse networks. It is also an access point to the wired network for computers with a wireless
module. It also includes a print server with which a USB printer can be connected to the private network.
Carefully follow the security information, system requirements, installation steps and warranty conditions as
described in full in the T-Sinus 154 DSL instructions (please see the CD-ROM supplied with the pack).
This Quick Start Guide shows you how to connect and configure your T-Sinus 154 DSL and then connect to
the Internet.
Security aspects
■
The T-Sinus 154 range of products offer comprehensive security functions designed to prevent attacks from
the Internet, attempts at 'listening in' on traffic in the wireless network and the use of communications by
unwanted users in the internal network. You will find detailed information about these aspects in the T-Sinus
154 DSL instructions on the CD-ROM supplied.
Opening the detailed operating instructions on the CD
■
Insert the CD-ROM supplied into your CD-ROM drive. The CD launches automatically and displays a dialogue
box. Click on T-Sinus 154 DSL and then on Dokumentation. The manual opens.
If the manual does not open: In the dialogue box click on Acrobat Reader
the on-screen instructions.
Contents
■
1x T-Sinus 154 DSL
1x mains adapter MNo. SNG 3-acc
2 x Ethernet cables Cat.5 (2 m/3 m)

Installation overview

■
1. First install an Ethernet network card or wireless network adapter in your PC. The installation procedure
can be found in the product's User Guide (e.g. T-Sinus 154data).
2. Next install the T-Sinus 154 DSL.
– Connect the T-Sinus 154 DSL.
– Configure your PC for the network. For a wireless connection, make the connection from the wireless
network adapter to the T-Sinus 154 DSL. This is described in the instructions for the network adapter.
– Configure the T-Sinus 154 DSL. You will need your T-Online access data to do this.
These steps are described on the following pages. You will need around 10-15 minutes to complete them.
3. You can connect further PC's to the network if you require.
1 x CD-ROM with software for the printer port installation and
detailed operating instructions
1 x Quick Start Guide in German, English, Turkish
and then on Installation. Follow
,
