Icom BC-121N Instruction Manual page 8

3
WALL ATTACHMENT AND SPECIFICATIONS
D WALL ATTACHMENT
The charger has holes in the rear panel allowing it to be
hung from a wall. Use appropriate screws (6 mm, 0.24 inch
diameter) and attach it to a solid surface (capable of
withstanding 20 kg of force).
CAUTION: NEVER place anything other than transceivers
or batteries in the charger.
Attach the
4 rubber
attachment
Use 6 mm (0.24 in) (d) screws
4
D SPECIFICATIONS
• Input voltage: 12 ~ 16 V DC or the specified
power adapter (BC-157S)
• Charging current: 840 mA ± 10% (rapid charging)
670 mA ± 10% (rapid charging)
540 mA ± 10% (rapid charging)
420 mA ± 10% (rapid charging)
30 mA ± 10 mA (trickle charging)
• Charging voltage: 8.4 V ± 0.1 V
• Charging temperature range:
10°C ~ 40°C, 50°F ~ 104°F
• Dimensions (projections not included):
300 (W) × 197 (D) × 93 (H) mm
11.8 (W) × 7.7 (D) × 3.6 (H) in
• Weight (approximate)
BC-121N: 1.4 kg, 3 lb 1 oz (except BC-157S)
BC-121NA: 1.6 kg, 3 lb 5 oz (except BC-157S)
• Electrostatic durability: Air discharge
Contact discharge 4 kV
(Li-ion battery)
8 kV
