Summary of Contents for PYLE Audio PPHP83MU
- Page 2 11. Be cautious of the weight of the unit and be careful when transporting and placement not in, and not in use. 12. Refer all servicing to qualified service personnel or Pyle Audio Specialist. Servicing is required if the unit has been damaged in any way, or appears not to be performing as described, or performance/operation has changed.
- Page 3 Electrical Safety: All units are fitted with a power cord (supplied) which connects to the AC mains via the back control panel of the PA speaker. The power cord has an IEC female connector on one end and male mains connection on the other, to provide a safe and consistent power flow to the unit.
- Page 4 Control Panel Layout Model: PPHP103MU Model: PPHP803MU PyleAudio.com Speaker Systems...
- Page 5 Control Panel Layout Models: PPHP123MU PPHP153MU Aux (3.5mm) Input Aux Input Volume Control 3-Pin XLR Type Microphone Input Microphone Input Volume Control 1/4'' Microphone Input Line Level Input Volume Control RCA (L/R) Input Connectors Master Volume Control 3-Pin XLR Type Input Connector Treble Audio Control...
-
Page 6: System Features
System Features PPHP103MU Loudspeaker PA Cabinet Speaker System, Powered 2-Way Full Range Sound, Recording Ability, USB/SD, 10-Inch, 800 Watt, Aux Input www.PyleAudio.com Visit for more info MP3 Audio Recording Ability: It's Easy: One Button Record Activation Record Audio as Streamed through the Speaker System Ability to Record Vocals via Microphone Can Also Record Audio via Line &... - Page 7 System Features PPHP123MU PPHP153MU Loudspeaker PA Cabinet Speaker System, Powered 2-Way Full Range Loudspeaker PA Cabinet Speaker System, Powered 2-Way Full Range Sound, Recording Ability, USB/SD, 12-Inch, 1000 Watt, Aux Input Sound, Recording Ability, USB/SD, 15-Inch, 1200 Watt, Aux Input MP3 Audio Recording Ability: MP3 Audio Recording Ability: It's Easy: One Button Record Activation...
- Page 8 Feedback Prevention Acoustic feedback occurs when sound from the PA loudspeaker finds its way back into the performer's microphone when the system is in use. This unwanted audio signal can cause interference, noise, distortion or plainly cause a non-desired and non-expected sound. Pyle PA speakers are designed with more relatively flat response rates to aid in minimizing any type of unwanted feedback.
