Summary of Contents for PYLE Audio PSBV600BT

  • Page 2: Table Of Contents

    Contents Important Safety Instructions ..................2 Safety .....................................2 Warning ..................................3 Identifying the Parts .....................4 Main Unit ..................................4 Remote Control .................................5 Preparations........................5 Prepare the Remote Control ..........................5 Replace the Remote Control Battery .........................6 Placing TV or Monitor ..............................6 Connections ........................7 Use the OPTICAL Connection ..........................7 Use the AUX Connection ............................7 Use the MP3 Link Connection ..........................8 Connect Power ................................8...

  • Page 3: Important Safety Instructions

    Important Safety Instructions 8 Do not install near any heat sources such CAUTION as radiators, heaters, stoves, or other RISK OF ELECTRIC SHOCK apparatus (including amplifiers) that DO NOT OPEN produce heat. CAUTION: TO REDUCE THE RISK OF ELECTRIC 9. Do not defeat the safety purpose of the SHOCK, DO NOT REMOVE COVER (OR BACK).

  • Page 4: Warning

    Caution: wall outlet, always pull directly on the U s e o f c o n t r o l s o r a d j u s t m e n t s o r plug, never yank on the cord. performance of procedures other than those described herein, may result in hazardous radiation exposure or other...

  • Page 5: Identifying The Parts

    Identifying the Parts Main Unit Top view / 0 1 2 Front view Back view 6 Status LED Indicators Standby indicator lights up red when the STANDBY mode. unit is in STANDBY mode. 2 SOURCE Aux/Bluetooth/Optical/Mp3 Link indicator Select the play function. lights up when which function is active.

  • Page 6: Remote Control

    Remote Control STANDBY mode. 2 SOURCE Select the play function. 3 VOL+/VOL- Bluetooth mode. mode. 6 PAIR mode and disconnect the existing paired Bluetooth device. 7 MUTE 8 EQ Preparations Prepare the Remote Control The provided Remote Control allows the unit to be operated from a distance. Even if the Remote Control is operated within the effective range (6m), remote control operation may be impossible if there are any obstacles between the unit and the remote control.

  • Page 7: Replace The Remote Control Battery

    Replace the Remote Control Battery 1 Pull out the battery tray and remove the old battery. 2 Place a new CR2025 battery into the battery tray with correct polarity (+/-) as indicated. 3 Insert the battery tray back into the slot. Precautions Concerning Batteries When the Remote Control is not to be used for a long time (more than a month), remove the battery from the Remote Control to prevent it from leaking.

  • Page 8: Connections

    Connections Use the OPTICAL Connection Remove the protective cap of the OPTICAL socket, then connect an OPTICAL cable (not included) to the TV’s OPTICAL OUT socket and the OPTICAL socket on the unit. OPTICAL cable Tip: If there is no sound come out of the soundbar and the indicator flash quickly. Make sure the audio setting of your source player (e.g.

  • Page 9: Use The Mp3 Link Connection

    Use the MP3 Link Connection Connect 3.5mm to 3.5mm audio cable (included) to the MP3 LINK socket on the unit and the audio output socket on external audio device (e.g.MP3 player, iPhone...). 3.5mm to 3.5mm audio cable Phone/MP3 Player Connect Power Risk of product damage! Ensure that the power supply voltage corresponds to the voltage printed on the back or the underside of the unit.

  • Page 10: General Operation

    General Operation Standby/ON When you first connect the unit to the mains socket, the unit will be in standby mode and the Standby Indicator will be red. button to switch the main unit ON. button again to switch the unit back to STANDBY mode. The POWER indicator will light up red.

  • Page 11: Bluetooth Operation

    3 Activate your Bluetooth device and select the search mode. “PSBV600BT” will appear on your Bluetooth device list. 4 Select “PSBV600BT” in the pairing list. The Bluetooth indicator will light up solidly while the pairing succeeds. 5 To disconnect the Bluetooth function, switch to another function on the unit or disable the function from your Bluetooth device.

  • Page 12: Listen To Music From Bluetooth Device

    again. Listen to Music from Bluetooth Device you can listen to the music stored on the device through the player. player’s remote control to play music stored on the device. 1. Pair your device with the player. 2. Play music via your device (if it supports A2DP). 3.

  • Page 13: Specifications

    effect. I can't find the Bluetooth name of this unit on my Bluetooth device for Bluetooth pairing within 8 metres between. Specifications General Power requirements ........................AC120V~ 60Hz Power consumption .............................18 W Output power RMS ...........................15W x 2 + 30W Total harmonic distortion ........................1%(1kHz, 1W) Audio input sensitivity ...........................
