U S E R I N S T R U C T I O N S

I c e & W a t e r D i s p e n s e r

F D F B 1 0 5 0 1 & F D F T 1 0 5 0 1

G E N E R A L O P E R A T I N G I N S T R U C T I O N

Read these instructions before use and save them for future reference.

Let the unit rest and unplugged for 24 hours before use.

 Remove all external and internal packaging materials. Be sure that all parts

have been included before discarding any packaging materials. You may

want to keep the packaging materials for use at a later date.

 Upon receipt and inspection of the unit, the power cord must be replaced if

it is damaged.

 Contact our customer service at 800-433-9938 or

info@fluridaappliances.com.

w w w . f l u r i d a a p p l i a n c e s . c o m

SAFETY INSTRUCTIONS-----------------------2

FEATURES & SPECIFICATIONS----------------4

DISPENSER USE-------------------------------6

DISPENSER CARE-----------------------------10

INSTALLATION INSTRUCTIONS--------------13

TROUBLESHOOTINGS------------------------18

SERVICE & IMPORTANT NOTICE-------------21

Need help?

Do you have a question about the FDFB10501 and is the answer not in the manual?

Questions and answers

Summary of Contents for Flurida FDFB10501

Page 1: Table Of Contents
U S E R I N S T R U C T I O N S I c e & W a t e r D i s p e n s e r F D F B 1 0 5 0 1 & F D F T 1 0 5 0 1 SAFETY INSTRUCTIONS-----------------------2 FEATURES &...
Page 2: Safety Instructions
SAFETY INSTRUCTIONS Electrical Safety Improper use of the power cord plug can result in the risk of DANGER electrical shock, property damage and personal injury or death.  This appliance is equipped with a 3-prong grounding- type plug, and shall be plugged into a properly connected grounding-type outlet.
Page 3 Cleaning To reduce the risk of injury when cleaning your appliance, follow DANGER these basic precautions.  Unplug appliance disconnect power before performing maintenance or cleaning.  Do not clean appliance with flammable fluids. Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other unit.
Page 4: Features & Specifications
Overview This is a great appliance to help you prepare cold or hot beverages and drinks. The FDFB10501 and FDFT10501 ice and water dispensers are an innovative design that combines cubed and crushed ice with hot and room-temperature water in a single compact product. The freezer keeps 9 lbs of crescent ice cold and available anytime.
Page 5  Automatic alerts for water and filter will not allow you to run out of water or leave water contaminated.  Child safety design protects your children from burning. Specifications and Dimensions Model No FDFB10501 FDFT10501 Ice Type Cubed and Crushed Cubed and Crushed...
Page 6: Dispenser Use
DISPENSER USE DANGER Hot water can scald your hands and body and cause serious injury. CAUTION Do not store food and drink in the ice freezer. For the first time use, allow 24 hours to produce the first batch of NOTE ice.
Page 7 Use of the Dispenser  Once the unit is powered, the ice and hot water functions will be turned on and “ON” green LEDs will light accordingly.  If bottled water is selected, the water pump works immediately to pump water from the bottle to the water tank.
Page 8: Dispensing Hot Water
 Press the “Hot” button once to turn the hot water off and the “OFF” red LED will light; press the button again to turn it on and the “ON” green LED will light.  You can turn off the hot water when it reaches the temperature you prefer.
Page 9 Dispensing cubed ice Cubed ice dispensing button  Place a cup under the ice dispenser.  Press and hold the “Cubed” button to dispense cubed ice. Dispensing crushed ice Crushed ice dispensing button  Place a cup under the ice dispenser. ...
Page 10: Dispenser Care
DISPENSER CARE DANGER Unplug the unit or disconnect power before performing any maintenance. If ice cubes block the feeler arm, clear the ice cubes before you pull out the ice bin. CAUTION Move the feeler arm up and keep it above the ice bin while you pull out the ice bin.
Page 11 How to release water  Use the water release drain located in the storage compartment to release the water left in the unit. How to remove condensate  The unit is operated with automatic defrost cycle. The water collects in a water tray that is located at the compressor compartment.
Page 12 If the ice bin is stuck  Unplug the unit.  Use a hair dryer with warm or cold air to melt the ice.  Pull out the ice bin and empty it.  Wipe up water and put the ice bin back. ...
Page 13: Installation Instructions
INSTALLATION INSTRUCTIONS Location This unit is designed for indoor use only. CAUTION Use the rear wheels to move the unit around.  Place the unit away from direct sunlight and heat sources.  Do not install the unit in moist areas. ...
Page 14 How to insert or disconnect a tube or plug 1. Remove the lock clip first. 2. To install, insert a tube or plug until it is engaged; To disconnect, press the release ring down and pull out a tube or plug. 3.
Page 15  Open the storage door more than 90 degrees.  Check if the water inlet (2) and outlet (3) are closed with plugs. They cannot be open.  Remove the plug of the pump pipe connector (1) and insert the pump pipe into it (1).
Page 16  Place the free end of the tubing in a container or sink and turn the shutoff valve on to flush the tubing until water is clear. Then turn the shutoff valve off.  Remove the plug of the plumbed water line connector (8), which is located at the back of the unit.
Page 17 Parts for using filtered water Description Part No Quantity 1/4" OD Water Line W/ 0111700110 Compression Nut & Sleeves Water Filter Q5305 0182000000 Water Filter Q5333 0182000100 Water Filter Q5321 0182000200 Water Filter Q5320 0182000300 Model Q5305 Model Q5333 Model Q5321 Model Q5320 ...
Page 18: Troubleshootings
TROUBLESHOOTINGS Complaint Possible Causes Response Unit is not a. Power cord is unplugged a. Plug in the power cord b. No power b. Check for outlet and breaker or working and fuse display is not c. Power cord problems c. Call for service d.
Page 19 d. The ice maker water pump d. Call for services is defective e. The ice maker is not e. Call for service working properly f. The cooling system is not f. Call for service working properly Ice cubes are a. The water shutoff valve is a.
Page 20 not hot enough Hot water a. The hot water tank is dry a. Call for service heater smells burning Water a. Water selection switch is a. Select the bottled or plumbed not selected correctly water source, unplug and plug the dispensing is unit not working...
Page 21: Service & Important Notice
These Terms and Conditions can only be modified in writing, signed by both Purchaser and Seller. FD is a registered trademark of Flurida Appliances Inc. All products, features, and services are subject to change without notice. We cannot guarantee the accuracy of the contents of this document.
