Summary of Contents for Sylvania SY14Q5144C series
- Page 1 14” 4-CHANNEL COLOR QUAD OBSERVATION SYSTEM MODEL: SY14Q5144C SERIES FOR MORE INFORMATION WWW.SYLVANIACCTV.COM Before operating this system, please read this Manual thoroughly and retain it for future reference!!!
- Page 2 System. Sylvania is committed to providing our customers with a high quality, reliable security product that customers have come to expect from us. With the new Sylvania Quad system, you are capable of viewing up to 4 camera locations in real time. This system allows you multiple viewing options including: Quad, Sequential, Selectable or Sequential Picture in Picture, Zoom, Freeze and full screen viewing options.
-
Page 3: For More Information
NOTE This equipment has been certified and found to comply with the limits regulated by FCC, EMC and LVD. Therefore, it is designed to provide reasonable protection against interference and will not cause interference with other appliance usage. However, it is imperative that user follows this manual's guidelines to avoid improper usage which may result in damage to the unit, electrical shock and fire hazard or injury. -
Page 4: General Precautions
GENERAL PRECAUTIONS 1. Read Instructions - All the safety and operating instructions should be read before the product is operated. 2. Retain Instructions - The safety and operating instructions should be retained for future reference. 3. Heed Warnings - All warnings on the product and in the operating instruction should be adhered to. 4. - Page 5 18. Object and Liquid Entry - Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product. 19.
-
Page 6: Table Of Contents
CONTENTS 1. CAUTIONS & FEATURES ------------------------------------------------------------------------------4 2. SYSTEM INCLUDES -------------------------------------------------------------------------------------5 3. MONITOR CONTROLS - FRONT PANEL ----------------------------------------------------------6 4. MONITOR CONTROLS - BACK PANEL -----------------------------------------------------------10 5. SETTING MENU ------------------------------------------------------------------------------------------11 6. STANDARD WIRED CAMERA & CAMERA INSTALLATION---------------------------------12 7. MONITOR CONNECTIONS & TROUBLE SHOOTING ----------------------------------------13 8. -
Page 7: Cautions & Features
CAUTIONS 1. All the warnings and instructions of this manual should be followed 2. Remove the plug from the outlet before cleaning. Do not use liquid aerosol detergents. Use water damped cloth for cleaning 3. Do not use this unit in very humid and wet places 4. -
Page 8: System Includes
SYSTEM INCLUDES 1/4” CMOS COLOR CAMERA 14” 4-CHANNEL COLOR WITH METAL STAND AND QUAD MONITOR WITH 63 FT CABLE REMOTE CONTROL (4 CAMERAS INCLUDED WITH MODEL SY14Q5144C) IMPORTANT NOTE : To increase the life of the CRT and to help prevent “burn in” on the monitor, it is strongly recommended that the monitor be set to standby mode when not in use for observation. -
Page 9: Monitor Controls - Front Panel
MONITOR CONTROLS - FRONT PANEL Q U A D M IC C H 1 C H 2 C H 3 C H 4 V C R A U TO 2 P IP SE TU P SE TTIN G A U TO 1 TA LK A U D IO S TA N D -B Y M O D E... - Page 10 10. Channel 4 – Displays Full Screen of Camera 4. 11. VCR – Press and hold this button to change the display from the camera inputs to the VCR Audio/Video playback and recording signal. The amber LED light located over this button will be ON when the VCR mode selection has been chosen.
- Page 11 MENU OSD / SCREEN SHOTS Time - Sets the time. Use the Up/Down/Left/Right keys to change and press the ‘Enter’ button on the monitor to confirm your selection. Date - Sets the date. Use the Up/Down/Left/Right keys to change and press the ‘Enter’ button on the monitor to confirm your selection.
- Page 12 Alarm - This screen allows you to change Alarm functions (Alarm OFF, N/O – Normally Open and N/C – Normally Closed) individually. Adjust the duration to which the alarm will occur. Key Buzzer - Select ‘Y’ or ‘N’ by using the Enter button to select the Buzzer sound. Loss Buzzer - ‘L’...
-
Page 13: Monitor Controls - Back Panel
MONITOR CONTROLS - BACK PANEL O FF O N POWER TR IG G E R O U TP U T A U D IO IN P U T 1 2 3 4 G N D C H 1 C H 2 C H 3 C H 4 A C IN... -
Page 14: Setting Menu
SETTING MENU Features of the Remote Control. For more details on specific remote control features, refer to the Monitor features FUNCTION DESCRIPTION STANDBY Turns Unit into Standby Mode TALK Allows to Talk to a specific camera location AUDIOSEL Allows to select Audio for a specific camera CH 1-4 Sets monitor to display selected channel in full screen ZOOM... -
Page 15: Standard Wired Camera & Camera Installation
STANDARD WIRED CAMERA Camera Lens – Delivers high quality image by using a CMOS Color Camera Microphone – Picks up sound around the camera Camera Inputs – Connects cable to monitor Speaker – Delivers sound from the monitor to the camera Bracket –... -
Page 16: Monitor Connections & Trouble Shooting
MONITOR CONNECTIONS O F F O N POWER T R IG G E R O U T P U T A U D IO IN P U T 1 2 3 4 G N D C H 1 C H 2 C H 3 C H 4 1. -
Page 17: Technical Specifications
TECHNICAL SPECIFICATIONS MONITOR Picture Tube 14” Color Horizontal resolution 380 lines at center Camera Capable Up to 4 Quad Speed 30 fps Camera Input 4 DIN / 4 BNC Alarm Inputs/Outputs 4 / 1 Input signal 1 V p-p at 75 ohms terminated Power Source Multi-voltage (AC90V –... -
Page 18: Optional Accessories
OPTIONAL ACCESSORIES The following accessories are available to add to your existing system. CABLE TIME LAPSE VCR NIGHTVISION Weatherproof Night vision Extends viewing length Used to record key events. accessory. Allows you to from Camera to monitor. Select From a 40 hour real see in the dark up to 35-40 Available In 65, 100 and time or 960 Hour time lapse... -
Page 19: Appendix - A Connecting Monitor To Standard Vcr
APPENDIX - A CONNECTING MONITOR TO A STANDARD VCR Please see the diagram below for connecting your VCR to the Monitor. NOTE: Ensure the Standard VCR’s channel is set to A/V Mode in order to ensure reception. Consult your VCR’s Owners Manual to set the VCR to this setting. POWER O F F O N T R IG G E R O U T P U T... -
Page 20: Appendix - B Connecting To Slave Monitor
APPENDIX - B CONNECTING TO SLAVE MONITOR Connections to another monitor (e.g. Slave Monitor) can be made through “MONITOR OUT” as shown in the diagram below POWER O F F O N T R IG G E R O U T P U T A U D IO IN P U T 1 2 3 4 G N D... -
Page 21: Appendix - C Connecting To A Lorex Time Lapse Vcr For Alarm Rec
APPENDIX - C CONNECTING TO A LOREX TIME LAPSE VCR FOR ALARM RECORDING O F F O N POWER T R I G G E R O U T P U T A U D I O I N P U T 1 2 3 4 G N D C H 1... -
Page 22: Appendix - D Connecting To A Lorex Time Lapse Vcr For Normal Rec
APPENDIX - D LOREX TIME LAPSE VCR CONNECTING TO A FOR NORMAL RECORDING O F F O N POWER T R I G G E R O U T P U T A U D I O I N P U T 1 2 3 4 G N D C H 1... -
Page 23: Product Warranty
This warranty does not apply to Bulbs, LED’s and Batteries supplied with or forming part of the product. This warranty is invalidated if other than Sylvania accessories are or have been used in or in connection with the Product or in any modification or repair is made to the Product be other than a service depot authorized by Sylvania. -
Page 24: Care And Maintenance
CARE AND MAINTENANCE Please follow the following instructions to ensure proper care and maintenance of this system Keep your monitor and camera dry. If it gets wet, wipe it dry immediately. Use and store your unit in normal temperature environment. Extreme temperatures can shorten the life of the electronic devices.
