UWS 75 RD
Terrassenstrahler
Chauffage à infrarouge de
terrasse
Bestell-Nr. / Order no.: ba_uws
E L E K T R O G E R Ä T E
Montage- und
Gebrauchsanweisung
Installation and
Operating instructions
Instructions de montage
et d'utilisation
Istruzioni d'uso e di
montaggio
Montage- en
gebruiksaanwijzing
Patio Heater
Radiatore da terrazza
Terrastraler
10/14/C
