Genesis G90 2014 Quick Reference Manual

G90 CUSTOMER DELIVERY CHECK LIST (continued)
Tire Pressure Monitoring System (TPMS)
- Page 33
LOW TIRE PRESSURE INDICATOR: Illuminates if one or more of your
tires is significantly under-inflated. Safely park the vehicle and check
your tires as soon as possible, and inflate them to proper pressure.
NOTE: Tire pressure may vary in colder temperatures causing the
low tire pressure light to illuminate. Inflate tires according to the tire
pressure label located on the driver ' s side door pillar.
TPMS MALFUNCTION INDICATOR: Illuminates when there is a
malfunction with the TPMS system. Have the system checked by an
authorized Dealer of Genesis Brand Products as soon as possible.
LOW TIRE PRESSURE POSITION INDICATOR: lndicates which tire is
significantly under-inflated by illuminating the corresponding position.
NOTE: TPMS is not a substitute for proper tire maintenance. It is the
driver ' s responsibility to maintain correct tire pressure, even if under-
inflation has not reached the level to trigger illumination of the low tire
pressure indicator. Refer to the Owner ' s Manual for further information.
Wiper / Washer
- Page 09
• To activate wipers move the switch down
Faster
to one of three positions (AUTO, LO, HI)
• To adjust " AUTO " speed rotate dial
• To spray washer fluid, pull lever toward you
• Push lever up for a single wiper pass
Slower
DURING DELIVERY
DEMONSTRATE AUDIO SYSTEM OPERATION, INCLUDING PRESETS
DEMONSTRATE HOW TO SET THE CLOCK
EXPLAIN FIRST SERVICE PROCEDURE – PROVIDE SERVICE
– DEMONSTRATE AND SET SERVICE INTERVAL
SCHEDULE FIRST APPOINTMENT USING BLUE LINK
DEMONSTRATE AND PAIR CUSTOMER ' S PHONE
REVIEW AMERICA ' S BEST WARRANTY
ASK IF CUSTOMER HAS ANY QUESTIONS
Sales Consultant Date Sales Manager
Customer
@
Email
MAINTENANCE
Scheduled Maintenance
Engine Oil & Filter (5.0 GDI)
Engine Oil & Filter (3.3 T-GDI)
Tire Rotation
Air Cleaner Filter
Vacuum Hose
Climate Control Air Filter
(For Evaporator and Blower Unit)
Air Conditioning Refrigerant
Brake Hoses & Lines
Drive Shafts & Boots
Exhaust Pipe & Muffler
Front Disc Brake/Pads, Calipers & Rotors
Propeller Shaft
Steering Gear Box, Linkage & Boots,
Lower Arm Ball Joint, Upper Arm Ball Joint
Suspension Mounting Bolts
Brake Fluid
Fuel Filter
Fuel Lines, Fuel Hoses & Connections
Fuel Tank Air Filter
Rear Disc Brake/Pads, Parking Brake
Vapor Hose, Fuel Tank & Fuel Filler Cap
Valve Clearance (3.3 T-GDI)
Drive Belts (Alt, A/C)
Spark Plugs (5.0 GDI)
Spark Plugs (3.3 T-GDI)
Coolant
Automatic Transmission Fluid
*See Owner's Manual for details.
Looking for more detailed information?
Manual. If you require additional information or are unsure of a specific item, you should always refer to the
vehicle's Owner's Manual or contact your authorized Dealer of Genesis Brand Products.
The information contained in this Quick Reference Guide was correct at the time of printing; however,
specifications and equipment can change without notice. No warranty or guarantee is being extended in this
Quick Reference Guide, and Genesis Motors USA reserves the right to change product specifications and
equipment at any time without incurring obligations. Some vehicles are shown with optional equipment.
Specifications apply to U.S. vehicles only. Please contact your Dealer of Genesis Brand Products for current
vehicle specifications.
Date
Date
Normal Usage Severe Usage*
Replace 7,500 or 12 mos. Replace 3,750 or 6 mos.
Replace 6,000 or 6 mos. Replace 3,000 or 6 mos.
Perform 7,500 Perform 7,500
Inspect
7,500
Replace More Frequently
Replace 30,000
Inspect 7,500 Inspect Same As Normal
Replace 15,000 Replace More Frequently
Inspect 15,000 Inspect Same As Normal
Inspect 15,000 Inspect Same As Normal
Inspect 15,000 Inspect 7,500
Inspect 15,000 Inspect Same As Normal
Inspect 15,000 Inspect More Frequently
Inspect 15,000 Inspect 7,500 or 6 mos.
Inspect 15,000 Inspect More Frequently
Inspect 15,000 Inspect Same As Normal
Inspect 30,000 Inspect Same As Normal
Inspect 30,000 Inspect Same As Normal
Inspect 30,000 Inspect Same As Normal
Inspect 30,000 Inspect Same As Normal
Inspect 30,000 Inspect More Frequently
Inspect 30,000 Inspect Same As Normal
Inspect 60,000 or 72 mos. Inspect Same As Normal
1st 60,000 or 72 mos.
Inspect Same As Normal
Addl. Inspect 15,000 or 24 mos.
Replace 105,000 Replace More Frequently
Replace 45,000 Replace More Frequently
1st Replace 120,000 or 120 mos.
Replace Same As Normal
Addl. Replace 30,000 or 24 mos.
No check, No service required Replace 60,000
This Quick Reference Guide does not replace your vehicle's Owner's
NP150-N2014
(Rev 05/22/13)
Printing 05/28/13
G90
Quick Reference Guide
www.genesismotorsusa.com
Roadside Assistance:
Consumer Affairs:
XM ® Radio:
GENESIS Blue Link:
1-800-243-7766
1-800-633-5151
1-800-967-2346
1-855-2BLUELINK
(1-855-225-8354)
