Summary of Contents for oticon Amigo T20
- Page 1 I N S T R U C T I O N S F O R U S E Amigo T20/T21...
-
Page 2: Table Of Contents
Choosing and changing channels booklet before using your Amigo T20/T21. The booklet Synchronising Amigo receivers contains various statements, safety instructions and important Synchronising other manufacturers’ receivers information about the use and handling of the Amigo T20/T21 About channels Using the TT-function (T21 only) -
Page 3: Introduction
Congratulations on your decision to take the next step in improving classroom FM. LED/Display legend With the Amigo T20 and T21, you will experience all the benefi ts that comes with a Microphone options product family that is designed to meet the needs that arises through everyday use. -
Page 4: Typical Package Content
Typical package content Overview of the T20/T21 LED status indicator SYNC acts as the “ENTER” button ON/OFF/Mute “C” acts as the “CLEAR/EXIT” button. 2.5 mm microphone jack High resolution LCD display Team teaching (T21 only) T20/T21 Charger AA battery Clear entered values Synchronise receiver/enter 3.5 auxiliary audio input jack “MiniB”... -
Page 5: Preparing Your Amigo System
Remove the battery lid on the back of the transmitter and insert the rechargeable battery - remember to position the battery according to the markings (+/ -) on the label. The Amigo T20/T21 uses one AA rechargeable NiMH battery, which must be charged for 14 hours before being used for the fi... -
Page 6: Selecting Language And Country
If you do not have time to charge the battery that came with the T20/T21, you can Select language and country (fi rst time only) replace the battery with any of the following: Turn the transmitter on by pressing and holding the On/Off button for two seconds. Press ▲... -
Page 7: The Amigo Receivers
The Amigo Receivers Changing the pin orientation If the pins on the Amigo receiver do not match the holes on the audio shoe, they can be rotated in steps of 90°. LED status indicator Simply pull the tab on both sides of the receiver back simultaneously, move the pins and push the tab back in. -
Page 8: Attaching Universal Amigo To A Hearing Instrument
Attaching universal Amigo receivers to Using Amigo with the Sumo receiver • Sumo detects the receiver and disables a hearing instrument the telecoil if the receiver is on Amigo R1 and R2 receivers are attached to the hearing instrument via an audio shoe. •... -
Page 9: Choosing And Changing Channels
Choosing and changing channels Synchronising Amigo receivers To change the transmitting channel on the Amigo transmitter, press and hold either the Connect the receiver to a hearing instrument, and turn it on. Check that the receiver ▲ button or the ▼ button for two seconds to select one of the predefi ned lists of switch is set to the correct mode, i.e. - Page 10 When the receiver’s LED is on, it confi rms that: • The hearing instrument battery is ok • The receiver is on • The transmitter and receiver are working in perfect harmony • The child is on the right channel...
- Page 11 Warnings Amigo parts can be dangerous if swallowed: • The Amigo system is not a toy and therefore should be kept out of the reach of children and anyone else who might swallow parts or otherwise cause injury to themselves. Special attention should be paid to the smaller components in order to prevent children from swallowing them and choking.
- Page 12 Battery use: Risk of harm caused by unintentional noise that may • Always use NiMH rechargeable batteries or alkaline batteries. muffl e important signals • Always use batteries recommended by your Hearing Care Professional. System dysfunctions: The Amigo system will cease to function if the batteries have run out. The system may •...
-
Page 14: Synchronising Other Manufacturers' Receivers
Synchronising other manufacturers’ receivers The T20/T21 are compatible with most other manufacturers’ receivers. However, Amigo receivers can only be synchronised wirelessly by Amigo transmitters. To ascertain whether an FM signal is present you must ensure that both the transmitter and the receiver are on the same channel. Find out which channel the receiver is operating on, and change the channel on the T20/T21 by pressing either the ▲... -
Page 15: About Channels
About channels Using the TT -function (T21 only) Your Amigo system is a radio device, and like any other radio, it communicates on Enable the TT-function on the T21 by pressing the button. specifi c channels. Your transmitter and receiver must be on the same channel to work together. - Page 16 To change this channel press ▲ or ▼. To change the team teaching channel press Connecting external audio sources (TV, MP3 etc.) followed by either ▲ or ▼ to move up or down the channel list. To go back to the primary channel press .
-
Page 17: T20 And T21 Special Functions
Feature How to T20 and T21 special functions Feature How to One-touch Team Teaching (T21 only) Press the TT button. This will provide access to the primary and team teaching Mute the transmitter One quick press on the On/Off button channels. - Page 18 Feature How to LED / Display legend The LED on the T20/T21 indicates the following: Press the “C” button and the ▲ button. You Flip display 180° can reverse the rotation by pressing both LED: Display Meaning: buttons again. Steady red On and transmitting Automatic mute The T20/T21 constantly scans for the...
-
Page 19: Microphone Options
The T20/T21 is moisture repellent, making it very easy to clean with a damp cloth. T20/T21 and attach the microphone either Oticon recommends cleaning on a regular basis. to your clothes or to the lavaliere cord. This allows you to wear the microphone around your neck. -
Page 20: Appendix A: Troubleshooting
Problem Solution Appendix A: Troubleshooting Interference If interference is encountered on a channel, change to another channel. Press ▲ or ▼ to Problem Solution change channel. The battery will not charge Check that it is positioned correctly. Make sure that it is the “silver-sleeved” recharge- able type of battery, as this is the only type the T20/T21 will charge (for safety reasons). -
Page 21: Appendix B: Manufacturers' Warranty
• Batteries. Appendix B: Manufacturers’ warranty • Instruments connected, installed, used or adjusted in a manner contrary to the The manufacturer, Oticon, issues a one-year limited warranty to the original consumer instructions provided. of this product. • Consequential damages and damages resulting from delay or loss of this instrument. - Page 22 Amigo serial numbers: consult your point of purchase for further information. Microphone: Hereby Oticon declares that this Amigo is in compliance with the essential require- ments and other relevant provisions of Directive 1999/5/EC. Declaration of conformity Receiver left: is available at...
