Service Manual
Product information
• This product meets the requirements regarding
interference suppression on radio and TV.
• After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
• Voltage
• Frequency
• Power consumption
• Stand-by power consumption : <0,5 W
• Color setting
• Cups at the same time
• Brewing time one cup
• Capacity water tank
• Cord length
• Max.cup height
• Pump pressure
• Brewing time for a jug
• Dimensions (W x D x H)
º Packaging
º Product
• Weight
º Incl. packaging
º Product
Published by Philips Consumer Lifestyle
16/06
: 220 - 240 V
: 50 Hz
: 1400 W
: Deep Black
: 2 to 7
: 30 sec
: 1 L
: 0.8 m
: 130 mm
: 1 bar
: 8.5 min
: 466 x 242 x 322 mm
: 150 x 400 x 270 mm
: 2.4 kg
: 1.75 kg
Printed in the Netherlands
Senseo® Switch
• Materials
º Podholder
º Podholder handle
º Top collector, Podholder spouts
º Housing, Driptray cover, Back plate : ABS
º Water container
º Water container lid, Driptray
º Brewchamber bottom
º Lid cover, Baseplate
º Buttons
º Lever
• Consumer Replaceable Parts
º CP9068/01 Insulated jug
º CP9069/01 Insulated juglid
º CP0397/01 Padholder assy Switch 1-cup
Deep black
º CP0398/01 Padholder assy Switch 2-cup
Deep black
º CP0399/01 Top collector Deep black
º CP0400/01 Driptray cover Deep black
º CP0401/01 Driptray Deep black
º CP0402/01 Filter holder + Lid
º CP0403/01 Coffee spoon
º CP0404/01 Water container transparent + Lid
Deep black
Optional (accessories)
• No specific issues
© Copyright reserved
HD7892/60
HD7892/61
: Stainless steel
: PP
: POM
: SAN
: PP
: PA
: ABS
: TPE
: PC
Subject to modification
Advertisement
Table of Contents
Related Manuals for Philips HD7892/60
Summary of Contents for Philips HD7892/60
- Page 1 º CP0404/01 Water container transparent + Lid º Incl. packaging : 2.4 kg Deep black º Product : 1.75 kg Optional (accessories) • No specific issues Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification 16/06...
- Page 2 Technical information HD7892/60 /61 General coff ee specifi cations: In-cup volume (mL) 1-cup (ml) 2-cup (ml) General version French version Temperature indication (°C) cup temperature and further cup temperature General version (122 ml) > 74 °C > 76 °C French version (100 ml) >...
- Page 3 Disassembly- and Reassembly advice HD7892/60 /61 Make sure the appliances cordset is disconnected from the mains! To open the appliance, remove all detachable parts: Water container, driptray and cover, pod holder and collector. 1. To reach the brew chamber. 1.1. Open the top cover.
- Page 4 Disassembly- and Reassembly advice HD7892/60 /61 2.3. Remove the housing. To remove the housing, start at the back side and undo the clicks (1) on either side of the back plate, next undo the snaps on the front of the housing (2), undo them with a fl athead screwdriver. Make sure that none of the snaps snap back.
- Page 5 Repair instruction HD7892/60 /61 Descaling Scale builds up inside the machine during use. It is essential to descale the SENSEO® coff ee machine when the CALC Light goes on. If the descaling procedure is not performed correctly, scale residue remains behind in the machine. This causes scale to build up more quickly and may cause permanent and irreparable damage to the machine.
- Page 6 Repair instruction HD7892/60 /61 Manual pump adjustment 1. Keep the 1-cup and 2-cup button pressed while connecting the appliance to the mains. 2. The buttons can be released when the 1-cup and 2-cup LEDs are switched on. You entered automatically the 1-cup pump time adjusting step.
- Page 7 Repair instruction HD7892/60 /61 Test procedure: The test procedure allows you to check the basic functions of the appliance. 1. Test step 1: Enter the test procedure: a. Keep the 2-cup button pressed while connecting the appliance to the mains.
-
Page 8: Parts List
Parts list HD7892/60 /61 Service code Description Remark 4222 259 65942 Padholder assy Switch 1-cup Deep black Padholder 1-cup Coff ee spout 1-cup Deep black 4222 259 65952 Padholder assy Switch 2-cup Deep black Padholder 2-cup Coff ee spout 2-cup... - Page 9 Parts list HD7892/60 /61 Service code Description Remark 1720 Lid spring 1730 Hose 1740 Lever Deep black 1750 Lever frame 1760 Rod (2x) 1770 Slider left 1780 Slider right 1790 Slider spring 17100 Lid frame 17110 4222 240 05991 Ejector pin (2x)
- Page 10 Exploded view HD7892/60 /61 10-15...
- Page 11 Exploded view HD7892/60 /61 11-15...
- Page 12 Exploded view HD7892/60 /61 1010 1020 1030 1040 1050 1060 1070 12-15...
- Page 13 Exploded view HD7892/60 /61 1410 1420 1430 1440 1450 1460 1510 1520 1530 13-15...
- Page 14 Exploded view HD7892/60 /61 1710 1720 1730 1740 1750 1760 1770 1780 1790 17100 17110 17120 17130 17140 14-15...
- Page 15 Exploded view HD7892/60 /61 3010 3020 3030 3040 3050 3060 Restrictor 15-15...
