Service Manual 1. Precautions and notices BEFORE SERVICING THE LCD TV, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. WHEN REPLACEMENT PARTS ARE REQUIRED, BE SURE TO USE REPLACEMENT PARTS SPECIFIED BY THE MANUFACTURER. Proper service and repair is important to the safe, reliable operation of all Hisense Electric Co., Ltd Equipment.
undertaken any such broad evaluation. Accordingly, a serviceman that uses a service procedure or tools, which are not recommended by Hisense, must first satisfy himself thoroughly that neither his safety nor the safe of the equipment will be jeopardized by the service method selected. Hereafter throughout this manual, Hisense Electric Co., Ltd will be referred to as Hisense.
Page 5
All ICs and many other semiconductors are susceptible to electrostatic discharges (ESD). Careless handling during repair can reduce life drastically. When repairing, make sure that you are connected with the same potential as the mass of the set by a wristband with resistance.
Page 6
-The insulation of the mains lead should be checked for external damage. 1.1.6 (1) Do not touch Signal and Power Connector while this product operates. Do not touch EMI ground part and Heat Sink of Film Filter. (2) Do not supply a voltage higher than that specified to this product. This may damage the product and may cause a fire.
cause electric shock. (8) Do not damage or modify the power cable. It may cause fire or electric shock. (9) If the power cable is damaged, or if the connector is loose, do not use the product: otherwise, this can lead to fire or electric shock. (10) If the power connector or the connector of the power cable becomes dirty or dusty, wipe it with a dry cloth.
Page 8
been turned off. • While the main power is on, do not touch any parts or circuits other than the ones specified. If any connection other than the one specified is made between the measuring equipment and the high voltage power supply block, it can result in electric shock or activation of the leakage-detection circuit breaker.
Page 9
original routing and fixing configuration when servicing is completed. All the wires are routed far away from the areas that become hot (such as the heat sink). These wires are fixed in position with the wire clamps so that the wires do not move, thereby ensuring that they are not damaged and their materials do not deteriorate over long periods of time.
2.2 This service manual includes TV Main board & power Model Panel Mode LVDS(Main-Panel) board RSAG2.908.6374-01\ROH LHD32K220TWAM HD315DH-B12 HX2-2×20KLB90P\90.0\无\ROH LTDN40K221TWAM HS*HD396DF-E01 HX2-2×20KLB150P\150.0\无\ROH RSAG2.908.6374\ROH 2.3 TV Front and Rear TV Front - 13 -...
3. Factory/Service OSD Menu and Adjustment 3.1 How to enter the Factory OSD Menu With user’s RC Power on the TV. 1. Press “Menu” button and call up User OSD Menu. 2. Select “ Sound” -> “Balance” item. 3. Press number key 1->9->6 ->9 in sequence when “Balance” item is focused. Note: If necessary, re-do number keys.
Page 17
Version: 3.2.2、Design Menu Note : The above “Factory/Service OSD Menus” are reference only, please refer to the actual unit to determine the appearances. - 17 -...
4. Software updating Software updating includes Mboot write and main software update. Usually first write Mboot to nand flashWith (MSTV_Tool.exe) then can update main software With SecureCRT. 4.1 Updating main board with SecureCRT 4.1.1 Hardware connecting You can update the software through a special tool (as following) Connect the Debug board to the TV use the RS232 (4 pin), the other USB port to the PC.
Page 19
For MTK chassis,the bebug boad set as following. MTK chassis connector to the second.position.from left. 4.1.2 First use Mstar bebug Tools,and you have to install drive software for bebug board. If your PC is Windows XP system: 1、First install FTCUNIN.EXE of FTC100103(MSTAR) rar file in your PC. This is a drive software of Mstar Another: If your PC is Win7 system, you will have to install CDM20802_Setup_WIN7 rar file,...
Please follow these steps: a) Copy the USBUpgrade.bin to the root directory of an USB disk. Insert the USB disk to the board. b) Connect the board with your PC via the debug tool. Open the software of SecureCRT in your PC. c) AC power on the board while pressing the Enter key of your PC. d) Check that there is a “nugget#” in the SecureCRT window. e) Input “usb start 1” and press Enter key. Note: If it says “Error” like below picture, please input “usb start 0” and press Enter key. f) Input “ustar” and press Enter key. g) It will be upgraded automatically and restart. ...
Page 21
b) Set I2C parameters. Click I2C‐> Set I2C to open the window of below and adjust the I2C Speed to 30. c) Load the Mboot files. Click View‐>Eagle/Nugget NAND Program to open the window below. - 21 -...
Page 22
Load the 3 files to the window as below. d) Click Program button above and it will write Mboot files to the Nand flash. e) When you see the Status become to “Status: Success, Please reset power”, please wait for 2 minutes and then close the MSTV_Tool. f) AC power off the board. Now you can upgrade the USBUpgrade.bin file with serial command following the steps in section 1.
4.3 Upgrading with the USB disk 4.3.1 TV in normal state 1. Copy the “USBUpgrade.bin” file that MBoot and main software named to the root directory of two USB disks respectively. 2. Insert the USB disk into the USB slot of the TV SET. 3.
6. After update succeeds, TV SET will restart automatically. 7. First update the Boot software, second update the main software. In order to convenience, prepare two USB disks to save different software respectively. 5.Troubleshooting 5.1 Troubleshooting for Remote Control Remote control does not work Try new batteries Replace battery Replace RC...
5.2 Troubleshooting for Function Key Buttons does not work Check solder connections and Check switches see if any switches are stuck. Replace Key BD Check key board Check Key BD cable Change Key BD Replace main board - 25 -...
Page 26
5.3 TV won’t Power On TV won’t power on Make Sure Power Check Power source is live light? Output Replace Check Power BLUE Power Cord Cord Check/replace IR Only BD or Keypad one works Try Power on by Check signal RC and Button Panel Bright Source...
5.4 Troubleshooting for Audio No sound Reconnect Check connecter Replace speaker wire Check speaker wire Replace speaker set Check speaker set Replace main board Power Supply Board - 27 -...
Page 29
5.5 Troubleshooting for TV/VGA/HDMI input No picture on the screen Check Signal Source Make sure signal source is available Reconnect Check connect Replace cable Check cable Replace main board - 29 -...
5.6 Troubleshooting for YPbPr input No picture on the screen Check Source work or not Check Source Device Reconnect Check connect Check Wires (Green Blue, Red) Replace wires Replace main board - 30 -...
5.7 Troubleshooting for Video input No picture on the screen Check Source work or not Check Signal Source Reconnect Check connect Replace Cable/Wires Check Cable/ Wires Replace main board 6. Circuit instruction 6.1 Power assign and signal block diagram - 31 -...
Page 48
Date Change List 20150203 Release 1.增加N24及外围电路; 20150316 2.增加主芯片DEMOD部分1.2V和3.3V的供电 Hisense Electric Co.,Ltd. Hisense Electric Co.,Ltd. Hisense Electric Co.,Ltd. No.11,Jiangxi Road,Qingdao,China No.11,Jiangxi Road,Qingdao,China No.11,Jiangxi Road,Qingdao,China WWW.HISENSE.COM WWW.HISENSE.COM WWW.HISENSE.COM Title Title Title Hisense MSD6308RT Hisense MSD6308RT Hisense MSD6308RT Size Size Size Schematic Name Schematic Name Schematic Name <Doc>...
