7.3 Signal Status

The eight LEDs above the terminal block indicate the state of the
digital signal present on each input / output.

7.3.1 High Side Version

Signal LED is
Green
Orange
Red
Tabelle 6: LED for Signal Status / High Side

7.3.2 Low Side Version

Signal LED is
Green
Orange
Red
Tabelle 7: LED for Signal Status / Low Side
MicroControl Version 2.00
To indicate
Digital high-signal at terminal ( Input )
Terminal configured as output, output has been
switched on
Terminal configured as output, short-circuit on
output driver
To indicate
Digital high-signal at terminal ( Input )
not applicable
Terminal configured as output, output has been
switched on
