Before starting installation, please read installation guide carefully!
1.
Safety references
General
This installation instruction contains fundamental references, which are to be considered for
mounting and start-up. It is to be read therefore absolutely before assembly and start-up from the
mechanic as well as the responsible user, too. It should be at the installation site. This installation
guide refers to the tracking system ETATRACK 1500 active. There is not only under this section of
"safety references" the specified to consider general safety reference but also into other sections
inserted, special safety reference.
Reference markings
Attention
Advice
www.lorentz.de
ETATRACK active 1500
Installation guide
Safety references marked with this symbol can cause endangerments of
persons.
Safety references marked with this symbol can cause damages on
machines or its function.
Advices and information to facilitate working and secure perfect operational
sequences.
Release 070402
Errors excepted and possible alterations without prior notice
Page 1/15
