Audiovox TFT2500 User Manual

Model TFT2500
2.5" PORTABLE LCD TELEVISION
USER'S MANUAL
TECHNICAL SPECIFICATIONS
TV SYSTEM
POWER SUPPLY
AC Power Supply:
DC Power input:
Battereries:
Built-In Battery charger:
SCREEN
TV FREQUENCIES
DIMENSIONS (WxHxD)
WEIGHT
CONTROLS, INDICATORS,AND CONNECTIONS
Charge indicator:Illumlinates when battreries are charging
UHF/VHR Select/Power On/Off:Turns power on and off;Selects
UHF/VHF TV band
A/V IN:Allows you to input a composite video/audio signal into
the unit;requires 3.5mm to RCA adaptor (not included)
Earphone:3.5mm earphone jack; provides private listening
Antenna:Extend antenna for better reception
Speaker: voice coil
6V DC:DC input for charging and providing external power to
the TV
Battery Compartment:Holds 4 x AA alkaline batteries or 4 x AA
NiMH rechargeable batteries;Charge switch is located in the
battery compartment
Channel +/-:Tunes the desired channel;press + to go up, - to
go down
Volume:Adjust the audio volume level up and down
Brightness:Adjusts the brightness of the image on the screen
NTSC - M
120VAC 60HZ
6V DC 500mA
4xAA ALKALINE BATTERIES
or 4xAA NiMH BATTERIES
2 Hour Quick Charge
2.5 INCH (112,320 Pixel count)
VHF band:channels:2-13
UHF band:channels:14-69
3 x 5.6 x 1.1 inches
0.44Lbs(without batteries)
Important safety information
WARNING: DO NOT USE THIS PORTABLE SET WHILE
OPERATING A MOVING VEHICLE. THIS IS DANGEROUS,
AND MAY BE ILLEGAL IN SOME AREAS.
WARNING: TO PREVENT TO DAMAGE WHICH MAY RESULT IN
FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS SET TO
RAIN OR MOISTURE.
WARNING: HIGH VOLTAGE PARTS ARE ACCESSIBLE
WHEN THE REAR PANEL IS REMOVED.
WARNING: THIS UNIT HAS A BUILT-IN BATTERY
CHARGER. PLEASE BE SURE TO SWITCH THE CHARGE
SWITCH IN THE BATTERY COMPARTMENT TO "OFF"
WHEN USING NON-RECHARGEABLE BATTERIES.
CHARGING OF NON-RECHAREABLE BATTERIES CAN
RESULT IN DAMAGE OR PERSONAL INJURY.
Care and maintenance
Clean the TV with a cloth occasionally. Do not use
harsh chemicals, cleaning solvents,or strong detergents.
Use only the power sources specified in this manual.
Use only new batteries of the recommended size. Always
remove the batteries if the TV will not be used for several
months as the batteries may leak chemicals that destroy the
TV's circuits.
Handle the TV carefully,dropping it could damage the
circuits or case.
Be extremely careful with the display screen. Avoid placing
the TV in your pocket or purse with objects that could
damage the screen.
Avoid places with extreme humidity, dust, or extremely high
or low temperatures.
Powering UP
AA ALKALINE BATTERIES:
Press the battery cover release tab and gently lift the battery
cover open.
Set the recharge switch located inside the battery
compartment to the "OFF" position
Insert four AA Alkaline batteries observing the
polarity symbols(+ and -) shown inside the battery
compartment.
Close battery cover.
*If using the AC adaptor with Alkaline batteries
installed in the TV, you MUST switch the
Recharge switch to the "OFF" position.
Failure to do so can result in personal injury or
damage.
Technical features
Power input
Display screen
Weight
System
4 x "AA" Batteries
or DC 6V 500mA
2.5" (112,320pixel)
0.44Lbs
NTSC - M
128-7102
