21.3 Keyboard Configuration
21.4
Operation
21.4.1 DVR/PTZ Mode conversion
Press System ID number (For example, ID: 001 press Num Pad
OSD will show "KBD:1" in right-bottom side that the keyboard is on DVR mode as below picture;
Then, user should be able to operate the DVR functions by the keyboard controller.
21.4.2 DVR Control Mode
In DVR control mode, all buttons are operated according to texts written underneath of each button. The functions are same
as Front buttons of DVR as follows:
- DISPLAY: change channel split screens in sequence of 1>4>9>16>1.
- SEQ: turn on/off Sequence function.
- SPOT: change the channel of a screen connected to the Spot monitor.
- ARCHIVE: pop up Archive window.
- AUDIO/ESC: shut down window when Setup window appears. Otherwise, it activates the AUDIO function. Any setup
changes during shutdown are not saved.(same as Cancel)
- EMERGENCY: turn on/off Emergency record function.
- EVENT: pop up a window to see System Log.
- PIP: turn on/off PIP screen in case of 1 channel screen. If PIP function is on, user number key(s) + ENT
) with
button.
155
key to change
