Hunt CCTV HCR-HD SERIES User Manual

Stand-alone digital video recorder 4, 8, 16 channel models
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Stand-alone Digital Video Recorder
HCR-HD DVR
4, 8, 16 Channel Models
User`s Manual
MADE IN KOREA
M2126QCR
Q3
This document contains preliminary information and is subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HCR-HD SERIES and is the answer not in the manual?

Questions and answers

Related Manuals for Hunt CCTV HCR-HD SERIES

Summary of Contents for Hunt CCTV HCR-HD SERIES

  • Page 1 Stand-alone Digital Video Recorder HCR-HD DVR 4, 8, 16 Channel Models User`s Manual MADE IN KOREA M2126QCR This document contains preliminary information and is subject to change without notice.
  • Page 2 FCC Compliance Statement Notice to Users This equipment has been tested and found to comply with the limits for a Class A digital device. Pursuant to Part 15 of the FCC Rules, these limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 3 Cautions This product has free voltages (100V and 240V). See installation instructions before connecting to the power supply. This product uses a Lithium battery. To avoid any risk of explosion, do not replace the battery on the main board by anything other than a Lithium battery. Dispose of used batteries according to the manufacturer’s instructions.
  • Page 4 12. Servicing Do not attempt to service this equipment yourself. Refer all servicing to qualified service personnel. 13. Damage Requiring Service Unplug this equipment from the wall outlet and refer servicing to qualified service personnel under the following conditions: ① When the power-supply cord or the plug has been damaged. ②...
  • Page 5 The List of Configuration All Type DVR Set 16CH CD (CMS Software/Manual) Remote Controller Manual Screws HDD Brackets Data Cable Rack Braket Power Cable Adapter (Only for A and B Type)

  • Page 6: Operation Precautions

    Operation Precautions Power Off Do not turn DVR off, or plug off the power adapter while DVR is in operation (record/playback). Otherwise, it may cause permanent damage to the equipment. Please click ( ) SETUP>SYSTEM>Shutdown sequentially and then remove the power after DVR is shutdown completely.

  • Page 7: Table Of Contents

    Table of Contents Server 4.4.2 Camera / PTZ .............. 37 4.4.3 Audio ................38 PRODUCT FEATURES ............10 4.4.4 Alarm In ............... 38 4.4.5 Alarm Out ..............39 4.4.6 Serial In ............... 39 Unpacking ................10 RECORD ................40 Service ................. 10 4.5.1 Setting .................
  • Page 8 MENU ..................66 12.6 Audio Volume Control ............. 90 SETUP ..................67 13. SEARCH ................. 91 Local Setup - Device ............67 13.1 Overview ................. 91 9.1.1 Remote Site Connection Setup ........67 9.1.1.1. New Device Register ..........67 13.2 Time Bar Search .............
  • Page 9 18.2 Live Monitor Menu ............112 20.5.3 Site Configuration ............149 18.2.1 Full Screen On ............112 20.5.4 Connection ..............150 18.2.2 Instant Playback ............113 20.5.5 Uninstall ..............151 18.2.3 PTZ Control ..............114 18.2.4 Screen Capture & Print ..........114 Application 18.2.5 Audio On/Off ..............

  • Page 10: Product Features

    1. Product Features 1.1 Unpacking This equipment is an electronic appliance, so it should be handled with special care. After unpacking, please check if all the following items are included. - DVR Main body A and B Type:: Power Supply Adapter (DC 12V, 6.67A) and Power Supply Cable C and D Type: Power Supply Cable - Remote Control With 2 AAA batteries...
  • Page 11 B Type – 4/8/16channel Series HCR-HD DVR...
  • Page 12 C Type – 4/8/16channel Series HCR-HD DVR...
  • Page 13 D Type – 16 channel Series Hybrid HCR-HD2H14EDVR...

  • Page 14: Installation

    2. Installation 2.1 Hard disk and DVD-RW Installation 2.1.1 SATA Port Main substrate of this DVR has five SATA ports: they are indicated as SATA 1, 2, 3, 4 and SATA 5. Please mount DVD-RW at the SATA 4 port. Up to five SATA devices (hard disk and DVD-RW) are able to be connected to the SATA ports in order.

  • Page 15: Hdd Installation

    2.1.4 HDD Installation Securely fix a hard disk by using bracket and screws provided herewith. Please do not use any different hard disk cables (data cable and power supply cable) other than ones we provide. Otherwise, it may cause damage to the hard disk. CAUTION Install hard disk after DVR power is off.

  • Page 16: Monitor Connections (Video Out, Vga And Spot)

    Type D Connect cameras to ‘HCR-HD IN’ to channel 1 and 2. Connect cameras to ‘VIDEO IN’ to channel 3 to 16. If user wishes to link camera input to another device, please connect the camera to ‘LOOP OUT’ Assure the ‘VIDEO IN’ and ‘LOOP OUT’ connections are connected properly, not oppositely. (NOTE) Only D Type model support LOOP OUT connection 2.2.2...

  • Page 17: Rs-485/422 Connections

    2.2.7 RS-485/422 Connections PTZ Camera connector. Please use TX+, TX-, RX+ and RX- terminals. 2.2.8 USB Connections There are four identical USB ports in front and in rear. It is possible to connect a USB memory stick to archive data or a mouse to control the device.

  • Page 18: Input Device And Screen Icons

    3. Input Device and Screen Icons 3.1 Key and LEDs KEYS PTZ KEY Operating mode Setup mode •Up/Down/Left/Righ ▲, ▼, ◄, ► • Control Pan/Tilt rotation of up/down/left/right in PTZ mode t on screen cursor control 1 ~ 16 • Camera select keys : (4/8/16 channel DVR) DISPLAY •...

  • Page 19: Camera Select Keys For 16 Channel Dvr

    3.2 Camera Select Keys for 16 Channel DVR A,B,C and D Type Below shows how to select camera channel for 16 channel DVR - Select Camera No. 1~10: use 1~10 direction key - Select Camera No. 11~16: press key and use 1~6 direction key 3.3 Front Panel A, B, C and D Type 3.4 Using a Remote Controller...

  • Page 20: Screen Icon

    Same as front key Cancel Cancel Function key menu Same as front key 3.6 Screen Icon Icon Description Icon Description Continuous recording mode In Audio recording Event recording mode CMS access indication/ No. of accesses (Alarm In/Motion) (up to 4) In recording In channel sequencing PTZ registration / PTZ mode...

  • Page 21: Setup

    4. Setup 4.1 Login / Logout At the default setting of DVR, user has to input the password to enter the set up menu. Please press SETUP key to enter the setup menu and the following screen will appear. In order to use all functions and privileges, login is as ID: admin. Default Password is “1111”.

  • Page 22: System

    4.2 SYSTEM 4.2.1 Information Please click ( ) SYSTEM>Information and the following screen will appear. Status Site Description Decide name of DVR. Please click ( ) keyboard icon on Site Description frame and the following virtual keyboard will appear. Please click ( ) desired letters (characters) on the virtual keyboard to input. Use to erase one character every time.
  • Page 23 Import: Copy the Menu setup stored in USB memory stick into DVR. Please plug in the memory stick and then click ( ) Import. Export: Store the Menu setup of DVR in USB memory stick. Please plug in the memory stick and then click ( ) Export. When user is on Default, Import or Export process, a message box will ask the progress and click the confirmation icon, then a message box will show whether its success or failure.
  • Page 24 User shall designate the total recording days from 1 day to 30 days and unlimited. User may set for beeping or notifying messages that notify the used percentage of disk. Check Disk Overwrite and user may activate the overwrite function. - This function makes restart the recording from the beginning when the HDD is full.

  • Page 25: Admin

    4.2.2 Admin Please click ( ) SYSTEM>Admin and the following screen will appear. Date This menu will allow user to adjust the settings. Please follow the procedure below for time adjustment. ① Click ( ) items (Y, M, D) to change. A designated item will be highlighted in a box (Y: Year, M: Month and D: Date). ②...
  • Page 26 Time Format Set time indication format. Please click ( ) Time Format frame to select a format from the list. When user complete Date/Time input, please click ( ) NTP and the following screen will appear. This menu is for accurate setting of time of day clock in DVR. User may check only one of Run as Server and Use NTP.
  • Page 27 Using E-SATA port will allow users to connect up to maximum 12 HDD +1 DVD-RW. When user installs full storage device and DVD-RW including two e-SATA storage, then following procedures will be listed as below: - 1. Internal SATA 1~4 Ports - 2.

  • Page 28: Account

    Choose ‘OK’ to confirm the setting. 4.2.3 Account Please click ( ) SYSTEM>Account and the following screen will appear. New Group Please click ( ) New Group and the following screen will appear. Click ( ) keyboard icon on the right-hand side of Group Name frame. Then, the virtual keyboard will show. Please click ( ) desired characters (up to 8 characteristics) on the virtual keyboard.

  • Page 29: New User

    New User Please click ( ) New User and the following screen will appear. Click ( ) the keyboard icon on the right-hand side of User Name frame and the virtual keyboard will appear. Click desired characteristics (up to 8 characteristics) on the virtual keyboard. Input Password and Confirm.

  • Page 30: System Log

    key if wish to erase password on keyboard. 4.2.4 System Log Please click ( ) SYSTEM>System Log and the following screen will appear. System Log displays diverse events as below events by specifying the user account that actually has accessed the DVR. - Setup (Menu) Enter/Exit - Playback Mode Enter/Exit - Network Access Enter/Exit...

  • Page 31: Shutdown

    4.2.6 Shutdown Shutdown is a function to help user safely turn the DVR off. Please use the proper shut down procedure to avoid damaging to our DVR system. Do not remove the power during shut down. CAUTION DO NOT TURN DVR OFF WITHOUT USING THE PROPER SHUT DOWN PROCEDURE. OTHERWISE, IT MAY CAUSE DAMAGE TO DVR.

  • Page 32: Main Monitor

    display as the Progressive Scan and shows the better picture quality. Transparency The Transparency menu will allow user to alpha-blending of OSD menu on the monitor. Transparency is the quality that an object or substance has when user can see through it. Transparency range is between 0 and 100;...

  • Page 33: Spot Monitor Control On Display Mode (D Type)

    This menu will allow adjust interval of channel sequencing of Spot monitor. Click ( ) Spot Select to choose Spot monitor to be set up. Check (check box next to the camera that wish to include in sequencing. Any camera with unchecked check box will be excluded from channel sequencing.

  • Page 34: Devices

    HD-SDI DVR displays and records differently with previous NTSC or PAL methods. Analog Output will help users to select its video output between NTSC and PAL Once it has changed, it will ask to reboot for the new recognition of video out method The default value is NTSC CAUTION ALTHOUGH USERS TURN ITS SYSTEM SETTING TO DEFAULT, THE ANALOG OUTPUT WILL STAY PREVIOUS OUTPUT METHOD...
  • Page 35 Network Type Please click ( ) Network Type. Every time click ( ), it changes to Static (fixed IP) and DHCP (floating IP). In Static, user must manually set the static IP address for use. - Set IP Address, Subnet Mask and Gateway. Please ask your network administrator for more details. - To input address, please click ( ) and execute the keyboard icon on the right-hand side of each frame.
  • Page 36 (domain name) instead of IP address (numbers). DDNS automatically recognizes ever changing, floating IP addresses, so it will allow easy Internet access. Check a checkbox of Use DDNS to use DDNS function. As for DDNS Server, dvrdomain.com name will be showing as default. As for Port, 95 is shown by default.

  • Page 37: Camera / Ptz

    CAUTION ONCE PORT NUMBERS ARE CHANGED, IT MUST BE CHANGED THE PORT NUMBERS OF CMS (Central Monitoring Station) PROGRAM AS WELL. Choose ‘OK’ to confirm the setting. Notification Please click ( ) Notification and the following screen will appear. The Notification menu will allow user to set transmission of Event occurred in DVR via E-Mail. Click ( ) the keyboard icon on the right-hand side of Add E-Mail item then the virtual keyboard will appear.

  • Page 38: Audio

    If users click (Default), proper number of selected PTZ will appear automatically. Please choose ‘OK’ to confirm the setting. Menu, Tour and Pattern help user to use OSD function of PTZ camera. - PTZ camera itself supports OSD menu, use the setup value to more easily enter and use the OSD menu even in DVR. - If OSD enter command is 95 + PSET for example, designate 95 for Menu item, - If shortcut key to use Tour function is 71 ~79 + PSET, designate 70 for Tour item and - If shortcut key to use Pattern function is 81 ~ 89 + PSET, designate 80 for Pattern item.

  • Page 39: Alarm Out

    The Alarm In menu will allow user to give title and to select the type of Alarm input. Click ( ) the keyboard icon on the right-hand side of each frame on Title column and the virtual keyboard will appear. Then, please register the title of Alarm input.

  • Page 40: Record

    4.5 RECORD Please click ( ) RECORD and the following screen will appear. 4.5.1 Setting A, B, C and D Type Please click ( ) RECORD>Settings and the following screen will appear. There are three kinds of recording mode. - Continuous: record continuously. - Event: record only when Sensor or Motion calls.
  • Page 41 16 Channel DVR 480(400) 480(400) 480(400) C Type 360x 240(288) 720x240(288) 720x480(576) 1280 x 720 1920 x 1080 4 Channel DVR 120(100) 120(100) 120(100) 8 Channel DVR 240(200) 240(200) 240(200) 16 Channel DVR 480(400) 480(400) 480(400) D Type HD-SDI Input (CH 1~2) 360x 240(288) 720x240(288) 720x480(576)
  • Page 42 B Type 360x 240(288) 720x240(288) 720x480(576) 1280 x 720 1920 x 1080 4 Channel DVR 120(100) 120(100) 120(100) 8 Channel DVR 240(200) 240(200) 240(200) 16 Channel DVR 480(400) 480(400) 480(400) C Type 360x 240(288) 720x240(288) 720x480(576) 1280 x 720 1920 x 1080 4 Channel DVR 120(100) 120(100)
  • Page 43 360x 240(288) 720x240(288) 720x480(576) 1280 x 720 1920 x 1080 4 Channel DVR 120(100) 120(100) 120(100) 8 Channel DVR 240(200) 240(200) 240(200) 16 Channel DVR 480(400) 480(400) 480(400) B Type 360x 240(288) 720x240(288) 720x480(576) 1280 x 720 1920 x 1080 4 Channel DVR 120(100) 120(100)

  • Page 44: Schedule

    1080P 25, 1080P 30, 1080P 50, 1080P 60. When the HD-SDI input changed manually, DVR will start restart to apply changed resolution. D Type User shall adjust its resolution for HD-SDI camera input depending on its camera supports. User can select the input standard from 720P 24, 720P 25, 720P 30, 720P 50, 720P 60, 1080I 50, 1080I 60, 1080P 24, 1080P 25, 1080P 30, 1080P 50, 1080P 60.

  • Page 45: Pre Alarm

    - Click ( ) a square box (top-left side between ‘S’ and ‘00’) and all the rows/columns will be registered. Repeat the procedure for Camera Nos. 2 to 16. If user wants every camera to have the same mode, please click ( ) Copy to All Camera.

  • Page 46: Motion Detection

    Click ( ) each frame on Frames column to select recording rate of a corresponding camera. Recording rate varies by camera. Below lists the maximum recording rate of each camera. camera. Below lists the maximum recording rate of each camera. A Type 360x 240(288) 720x240(288)

  • Page 47: Holiday

    The Motion Detection menu will allow user to set Motion detection alarm. Press SETUP key (or right mouse button) and the SETUP menu will appear. SETUP menu descriptions. - Camera: select camera for setup. - Sensitivity: select sensitivity (Low, Normal and High) - Reverse Vert: activate the entire column at the cursor’s position.

  • Page 48: Alarm In

    The LINK menu will allow user to set recording modes of all kinds of alarms (Sensor, Motion Event, Video loss, System Event, etc.), alarm output, e-mail notification and the like. 4.6.1 Alarm In Please click ( ) LINK>Alarm In and the following screen will appear. Select cameras for recording while the motion sensor is in operation and alarm outputs and set up E-mail addresses for notification.

  • Page 49: Video Loss

    Select cameras for recording while the motion sensor is in operation and alarm outputs and set up E-mail addresses for notification. Link Notification displays E-mail addresses registered in DEVICES>Network>Notification. Please follow the setup procedures below. ① Click ( ) Motion Event frame and select Motion Event 1. ②...

  • Page 50: Popup Link

    Select recording cameras and alarm outputs while Emergency recording using EMERGENCY key and set E-mail addresses for notification. Link Notification displays E-mail addresses registered in DEVICES>Network>Notification. Please follow the setup procedures below. ① System Event frame displays Emergency, which user does not have to change. ②...

  • Page 51: Operation Instruction

    5. Operation Instruction 5.1 Viewing 5.1.1 First Image Power on DVR and the following live video will appear, while viewing and recording at the same time. The screen will display date/time and icons below. Icon Description Continuous recording mode Event recording mode (Alarm In/Motion) In recording PTZ registration/PTZ mode In Audio recording...

  • Page 52: Digital Zoom

    - Channel Sequencing: Please press SEQUENCE key to display images in sequencing view format periodically. This automatic sequence function is not limited to the full screen format, but can be used in any view mode. In 8 channel DVR, 4-camera sequencing view mode is possible and in 16 channel DVR, 4 or 9-camera sequencing view modes are possible. 5.1.3 Digital Zoom Select a Channel and make it into Full Screen.

  • Page 53: System Log

    To use a mouse in Pan/Tilt mode, please move the cursor to the lower portion near the center of the screen. To use front button in Pan/Tilt mode, please push setup button. A key pad control will show as follows: To save current camera number, select Preset No and button click.

  • Page 54: Emergency Recording

    5.1.8 Emergency Recording When user presses EMERGENCY key, recording starts right away regardless of preset recording mode. Emergency recording is not operated while SETUP. Press Emergency key one more time to stop the emergency recording. 5.2 Search This involves searching recorded video to playback the wanted video of a specific date and time. Press SEARCH key on the viewing screen, or Click Search menu at “Function Keys”...

  • Page 55: Event Search

    Dates and Time with recorded data available will be high-lighted. Follow the procedure below to search video by calendar. ① Select Year and Month by using the arrow buttons in the calendar. : search subsequent ‘Year’ : search previous ‘Year’ : search subsequent ‘Month’...

  • Page 56: Playback

    ① Designate Event Search start time. ② Designate Event Search end time. ③ Select camera (video) to search data. ④ Check a check box (Motion / Alarm In / Emergency / Serial In) Check box. ⑤ Click on Search Index button to recorded search event data. 5.3 Playback This involves searching recorded video to playback the wanted video of a specific date and time in search mode.

  • Page 57: One-Touch Playback

    (NOTE) Using a mouse: Double click to view the corresponding camera image in full view format and click one more time to back to Split Screen. Move the cursor of the mouse and the keypad control will appear at the bottom near the center of the screen. Every time user presses the PLAY/PAUSE key during playback mode, it is changed to ‘1X PLAY’...

  • Page 58: Archive

    5.6 Archive The Backup function will allow user to copy the recorded video (moving images and still images) from a storage device (USB memory stick, DVD-RW). Please execute Backup Live or playback. Follow the backup procedure. ① Press ARCHIVE key. In case of using a mouse, please press the mouse right button and click in Archive. Then, the following screen will appear.

  • Page 59: Menu Bar

    5.7 Menu Bar Menu bar enables users to control all function as front button on the OSD screen. Move the mouse cursor to bottom around Date and Time indication then Menu bar will show up on the live screen. Each icon functions as below; : Exit the Menu Bar : Safely turn off the DVR : Enter Archive mode...

  • Page 60: Alarm Out Control

    (NOTE) THIS FUNCTION IS ENABLED ONLY WHEN LIVE MODE AND 1 CHANNEL MODE If user clicks (Default), proper number of Color Control or HSTART/VSTART will appear automatically. Please choose ‘OK’ to confirm the setting. Click ( ) ▲, ▼ direction buttons on the right-hand side of Brightness/Contrast/Saturation to set adjust color of the screen (i.e.

  • Page 61: Cms Pro

    Professional Central Monitoring Software CMS Pro Full-featured Enterprise Class Surveillance Solution User`s Manual This document contains preliminary information and is subject to change without notice.

  • Page 62: Features

    6. Features 6.1 Introduction The CMS Pro is a central surveillance system solution that monitors multiple sites with video, audio and event signals from DVR over networks. The software supports different windows of live viewer, playback player, interactive map viewer, various search panes and event signal monitoring panes.

  • Page 63: Installation

    7. Installation 7.1 Software Installation Please follow the program installation procedures below. ① If an old version of CMS Pro program was installed, completely uninstall or delete the old version. CAUTION USERS SHOULD COMPLETELY REMOVE CMS PRO PROGRAM OF AN OLD VERSION BEFORE INSTALLING NEW VERSION IN ORDER TO REDUCE COLLISION.

  • Page 64: Login

    ⑧ When the following screen appears, click “Finish” to complete the installation. CAUTION If the PC has a previously installed CMS Pro, the installer asks whether to overwrite the existing DB or not. The DB contains setting values on the program. If desired to maintain the existing values, click ‘No’ button. If the Os is Windows 7, then users have to run the program as “Run as an administrator.”...
  • Page 65 Administrator may change the password in the program. (NOTE) Users may change the password in [Setup] – [Change Password] menu. For the detailed information, please refer to the ‘4.4.3 Change Password’ page. The CMS Pro archives settings and layouts on the program of the current user when the program is closed.

  • Page 66: Menu

    8. Menu Below shows the brief explanation of each part on the screen. Application View set Setup menu Help menu Server list pane Display windows Health check pane Map list pane Screen split selection icons Audio control bar Remote device system log pane Remote device event log pane CMS system log pane Sequencing...

  • Page 67: Setup

    9. Setup 9.1 Local Setup - Device Please make sure the network setting of DVR has been done properly prior to the remote connection setting. 9.1.1 Remote Site Connection Setup Click Setup – Local Setup – Device to enter the setup and a dialog will pop up as below picture. 9.1.1.1.

  • Page 68: Edit Registered Site

    Choose a camera name between DVR and CMS setting or both. - By DVR setting: Display camera name of DVR. - By CMS setting: Display Camera name of CMS. - Both: Display both as [DVR name]-[CMS name]. Type the name of each camera in “Camera Name” item. Users will be able to type not only in English but also their own languages.

  • Page 69: New Grouping Setting

    9.1.2.1. New Grouping Setting Please click “New” to set up the Group Name, select Division (from 4 to 144), and type the Description. Select the site from the server list in the left-hand side of the window. Right mouse click and click “connect” on the site or double clicking the device will show the tree of cameras and here users can extract the channel they want.

  • Page 70: Viewer

    9.2.2 Viewer 9.2.2.1. Audio Users are able to control the Audio volume. 9.2.2.2. Video Display Users are able to control the Audio volume. Users can adjust and set the environment of the Display window. The Display option will be applied after program restarts and the contents are as below. - Display Mode: It shows the format of display and YUV Mode is the default and it is not adjustable.

  • Page 71: Setup

    (NOTE) Please refer to Chapter 7.2.4 for Zoom In Screenshot 9.2.4 Setup Select save directory: Users can select the save directory of setup data or log data by designating the folder in the PC or other storage device and the change of the directory will be applied only after clicking “OK” button and exit. Select Data: Select data which users would like to save in the storage devices.

  • Page 72: Local Setup - Account

    Instant Playback is displayed from the last preset time. (1, 3, 5, 10, 15, 30Min, 1, 3Hour, Default is 3Min) For example, if 5 Min is set as a playback period, then users are able to see the last 5 minute’s data from the current time. 9.2.6 Auto Sequence Auto Sequence: Users are able to switching the camera view and setup the dwelling time between the different camera views.

  • Page 73: Edit User Account

    Type: Select one of the two types of user account, Manager and User from the drop-down menu. While Manager Account allows all of the authorization to be controlled, User Account is permitted to set only Search, PTZ control, and Emap functions. Create a User name and Password and then type Description of the account.

  • Page 74: Local Setup - E-Map

    9.4 Local Setup – E-map Users are able to create various E-maps and it enables monitoring both Live and Playback screen. 9.4.1 Registering a New E-map Click “New” Tab to set up the E-Map. In order to load an image of the map, click “Load Map Image” that users would like to use as an E-Map. Users should select the image format between BMP and JPG.
  • Page 75 Select Size: Size of the icon varies from 24*24, 32*32 to 48*48. Edit Name: Type the name of the icon and click the “Apply” to change the name. Reposition: The icons which are set up on the map can be repositioned into the right place even if the map size is changed (enlarged/reduced).

  • Page 76: Remote Device Setup

    9.4.2 Remote Device Setup Select one among the connected devices and click “OK”. Then the setup window appears same as the one in the DVR. Click “OK” to save and exit 9.4.3 Change Password Users are able to change the password of the ID. - Password: input the current password.

  • Page 77: Help

    9.5 Help 9.5.1 About The version of CMS Pro can be checked here.

  • Page 78: View

    10. View The viewer of this program is composed with 5types of different panes. - Server List, Remote Device System Log, Remote Device Event Log, CMS System Log and Health Check. 10.1 Server List When the device is registered, then it is displayed on the Server List. If uncheck “Visible”...
  • Page 79 Check “Visible” in the Remote Device Event Log menu to see the menu or uncheck “Visible” in order not to see the menu. Users can select the registered device from the drop down box menu. Alarm In / Motion / Video Loss / Alarm Out can be selected separately as Event. (More than 2 events can be selected at the same time.) And by clicking “Event log On/Off”...

  • Page 80: Cms System Log

    10.4 CMS System Log This is the log menu where users can check the log information of the CMS program. Check “Visible” in the CMS System Log menu to see the menu or uncheck “Visible” in order not to see the menu. Click the “Update Log”...
  • Page 81 Check “Visible” in the Health Check to see the menu or uncheck “Visible” in order not to see the menu. Left mouse click on the device in the server list to see the information of health check. HDD Status HDD is not connected and cannot be added. HDD is connected.

  • Page 82: Show All Windows

    Alarm In is not activated currently but can be added later. Alarm Out Status Alarm Out is not activated and cannot be added. Alarm Out is being activated. Alarm Out is not being activated but can be added later. Motion Status Motion is not activated and supported.

  • Page 83: Application

    11. Application 11.1 Search There are five different types of search menu; Timebar, Event, POS/ATM, Thumbnail and Smart Search The detailed information and directions is described in chapter 8. 11.2 Exit If users wish to exit the program, then click the “Exit” in the Application menu.

  • Page 84: Live (Live Video Monitoring System)

    12. Live (Live Video Monitoring System) 12.1 Overview This program is to display live video from multiple channels in customized screen format. The program is based on user friendly interface. Users may configure the entire program and open or close the panes and screens in the program.

  • Page 85: Instant Playback

    12.2.2 Instant Playback Instant playback is available in both Live1 and Live2 pane, but screen capture is available in either live1 or live2. After right mouse click, move the mouse cursor to “Instant Playback”. Then, play and setup menu will appear. - Play: The recorded video of the pre-setup time will be displayed in the playback viewer.

  • Page 86: Ptz Control

    12.2.3 PTZ Control After right mouse click on the channel that PTZ camera is connected, select “PTZ control”. Users can designate the certain area and set the name by using “Preset” function. Up to 255 presets can be designated. Zoom Zoom in Zoom out Focus...

  • Page 87: Audio On/Off

    Users are able to choose the folder in which they wish to store the image by clicking and then click “Save” button. Click “Show Captured Image” to show the captured images. Users can even recapture the part of the captured image by dragging the place users want. Click “Print”...

  • Page 88: Mike On/Off

    Audio On/Off function is applied to only individual channel. 12.2.6 Mike On/Off Click right mouse button to on/off Mike. Users can deliver the audio through the speaker connected to DVR by sending the audio from PC where CMS Pro is activated. 12.2.7 Instant Recording Click right mouse button to activate the Instant Recording.

  • Page 89: Display Option

    “Open folder” will allow users to select the recorded files and play them. 12.2.8 Display Option Users can set up the display of camera name and time in “Display Option”. After right mouse click, check the “Show Camera Name” to display the camera name or uncheck the menu to hide it. After right mouse click, check the “Show Time”...

  • Page 90: Sequencing

    12.5 Sequencing Click the to switch the channel according to setup made in auto sequence in Local setup – Environment. It is only supported one channel 12.6 Audio Volume Control Users can control the audio volume using the bar controller at the bottom of the screen.

  • Page 91: Search

    13. Search 13.1 Overview There are five different types of search function and users are able to search the recorded data by using a suitable search function of the five in accordance with their purpose. (NOTE) Search window cannot be closed during playback. Please close the window after stop the playback. Playback more than 2 channels at the same time is available only in time bar search.

  • Page 92: Event Search

    (NOTE) Check the “Show Channel Toolbar Always” in the setup menu> Local setup – Environment > viewer > Video display > Display option “Playback” and “Archive” menu appears when right mouse click on the time bar. In the playback menu, users are able to decide to search the data from the beginning of the day or from the cursor position. Or just simply click on the time line users want, and then click “...

  • Page 93: Pos/Atm Search

    To check the event that is detected on the right side of the search window, double click the event that users want. 13.4 POS/ATM Search Click the “connect” after right mouse clicking on the device and select the “POS/ATM Search”. Type the text that users want to find in the “POS / ATM”...

  • Page 94: Smart Search

    13.6 Smart Search Click the “connect” after right mouse clicking on the device and select the “Smart Search”. This search function provides the users with the smart search option. Users can select the area in an individual channel by dragging the certain area in “setting” menu. (More than 2 areas can be designated in the setting pane.) If the movement is detected in the area, it will automatically display the video clip in the search window.

  • Page 95: E-Map

    14. E-Map 14.1 Overview The ‘Map Viewer’ program is to display event signals over map images so that users may acknowledge event status with geographical information. Users may perceive event occurrence status with visual notifications on icons over the map image and audible notifications on speaker system of a PC.

  • Page 96: Alarm In/Out Control

    14.2.2 Alarm In/Out Control The Alarm In icon on the map will be light on when the Alarm In equipment like sensor or detector is activated in the site. If users click the Alarm Out icon, the light is on the icon and the alarm equipment such as siren and buzzer will be activated in the site.

  • Page 97: Uninstalling Cms Pro

    15. Uninstalling CMS Pro Please click the “Uninstall” file in the CMS Pro folder in the PC. Click the uninstall file and the following message box will pop up. Click “OK” to remove the program and its components. If an uninstallation is complete successfully, the following message will pop up.

  • Page 98: Others

    16. Others 16.1 Viewer The Format of archive file is .exe(executable file). Please double click on the icon to execute the program. PLAY • Playback mode: 1X PLAY • Playback mode: PAUSE PAUSE • Frame-by-frame backward still image BACKWARD playback •...
  • Page 99 Please click on the icon to load the image file. To move the icon just drag and drop. You can also rotate the icon. Please click on the icon and input the name of the E Map file to save and execute. Please click on the icon to exit program.

  • Page 100: Watermark Check System

    16.3 Watermark Check System Mouse double click WCS.exe program in the CMS program folder (Default: C:\Program Files\CMS\WCS.exe). To open the check .exe or .jpg or .bmp file just click Load File button. To click the check button, user will get following message; - Result: - Verification OK ! - Corrupted or Modified...
  • Page 101 Click “File Open” and choose an Archived file(EXE format). Click “EXE to AVI File” and select a directory to save the converted AVI file. Select a channel to convert (Only one channel can be converted at once). Select a Video Encoder between Microsoft and DIVX encoder. Click “Save”...
  • Page 102 CMS Web Client Pro CMS Web Client Pro User`s Manual This document contains preliminary information and is subject to change without notice.

  • Page 103: Cms Web Client Pro

    17. CMS Web Client Pro 17.1 Setup and Login MS Explorer web browser is required for installation and using this program. Open a browser and type the IP address of DVR. It is required to install ActiveX in the first connection. Basically, Explorer limits automatic ActiveX installation.

  • Page 104: Setup

    Connect Disconnect Application View set Setup menu Help menu Display windows Health check pane Screen split selection icons Audio control bar Remote device system log pane Remote device event log pane Web Client Pro system log pane 17.3 Setup 17.3.1 Local Setup - Enviornment This enables users to adjust the default setting for user’s convenience.

  • Page 105: Record

    Users can adjust and set the environment of the Display window. The Display option will be applied after program restarts and the contents are as below. - Display Mode: It shows the format of display and YUV Mode is the default and it is not adjustable. - Default Division: Users can select the number of division of display channels when the program initially displays the screen.

  • Page 106: Instant Playback

    (NOTE) Please refer to Chapter 18.2.3 for Zoom In Screenshot 17.3.4 Instant Playback Instant Playback: Users are able to see the recorded data easily by using instant playback function. Set the time from which the recorded data is displayed. Instant Playback is displayed from the last preset time. (1, 3, 5, 10, 15, 30Min, 1, 3Hour, Default is 3Min) For example, if 5 Min is set as a playback period, then users are able to see the last 5 minute’s data from the current time.

  • Page 107: Help

    Click “OK” to save and exit 17.4 Help 17.4.1 About The version of Web Client Pro can be checked here. 17.5 View The viewer of this program is composed with 4 types of different panes. - Remote Device System Log, Remote Device Event Log, Web Client Pro System Log and Health Check. 17.5.1 Remote Device System Log Users can check the system log of the device in this menu.

  • Page 108: Remote Device Event Log

    The contents in the parenthesis show the name of the device. Ex) [Demo] Check “Visible” in the Remote Device System Log menu to see the menu or uncheck “Visible” in order not to see the menu. 17.5.2 Remote Device Event Log Check “Visible”...

  • Page 109: Web Client Pro System Log

    17.5.3 Web Client Pro System Log This is the log menu where users can check the log information of the Web Client Pro. Check “Visible” in the Web Client Pro System Log menu to see the menu or uncheck “Visible” in order not to see the menu. Click the “Update Log”...
  • Page 110 Check “Visible” in the Health Check to see the menu or uncheck “Visible” in order not to see the menu. Left mouse click on the device in the server list to see the information of health check. HDD Status HDD is not connected and cannot be added. HDD is connected.

  • Page 111: Show All Windows

    Alarm In is not activated currently but can be added later. Alarm Out Status Alarm Out is not activated and cannot be added. Alarm Out is being activated. Alarm Out is not being activated but can be added later. Motion Status Motion is not activated and supported.

  • Page 112: Live (Live Video Monitoring System)

    18. Live (Live Video Monitoring System) 18.1 Overview This program is to display live video from multiple channels in customized screen format. The program is based on user friendly interface. Users may configure the entire program and open or close the panes and screens in the program.

  • Page 113: Instant Playback

    18.2.2 Instant Playback After right mouse click, move the mouse cursor to “Instant Playback”. Then, play and setup menu will appear. Users can move and change the size of the instant Playback window as they wish. - Play: The recorded video of the pre-setup time will be displayed in the playback viewer. - Setup: The time of instant playback can be setup in this menu, from 1minute to 3hours.

  • Page 114: Ptz Control

    18.2.3 PTZ Control After right mouse click on the channel that PTZ camera is connected, select “PTZ control”. Users can designate the certain area and set the name by using “Preset” function. Up to 255 presets can be designated. Zoom Zoom in Zoom out Focus...
  • Page 115 The brightness, contrast and saturation can be adjusted to store in users’ taste and can be printed directly in the menu. Creat a name of captured image and select the image type between BMP and JPG Users are able to choose the folder in which they wish to store the image by clicking and then click “Save”...

  • Page 116: Audio On/Off

    18.2.5 Audio On/Off Click right mouse button to on/off audio in the channel. Audio On/Off function is applied to only individual channel. 18.2.6 Mike On/Off Click right mouse button to on/off Mike. Users can deliver the audio through the speaker connected to DVR by sending the audio from PC where CMS Pro is activated. 18.2.7 Display Option Users can set up the display of camera name and time in “Display Option”.

  • Page 117: Change Division Display

    18.4 Change Division Display Various combination of channel display is provided by clicking the icon at the bottom of the screen. 18.5 Audio Volume Control Users can control the audio volume using the bar controller at the bottom of the screen.

  • Page 118: Search

    19. Search 19.1 Overview There are five different types of search function and users are able to search the recorded data by using a suitable search function of the five in accordance with their purpose. (NOTE) Search window cannot be closed during playback. Please close the window after stop the playback. Playback more than 2 channels at the same time is available only in time bar search.

  • Page 119: Event Search

    “Playback” and “Archive” menu appears when right mouse click on the time bar. In the playback menu, users are able to decide to search the data from the beginning of the day or from the cursor position. Or just simply click on the time line users want, and then click “ ”...

  • Page 120: Pos/Atm Search

    To check the event that is detected on the right side of the search window, double click the event that users want. 19.4 POS/ATM Search Click the “connect” after right mouse clicking on the device and select the “POS/ATM Search”. Type the text that users want to find in the “POS / ATM”...

  • Page 121: Smart Search

    The video will be displayed in the “video display” panel at the bottom of the search window. Users can move the panel around the screen and adjust the size of the panel as users want. 19.6 Smart Search Click the “connect” after right mouse clicking on the device and select the “Smart Search”. This search function provides the users with the smart search option.

  • Page 122: Cms Mobile Viewer

    CMS Mobile Viewer CMS Mobile Viewer User`s Manual This document contains preliminary information and is subject to change without notice.

  • Page 123: Cms Mobile Viewer

    20. CMS MOBILE VIEWER 20.1 iPhone Mobile 20.1.1 System Requirements There are no other requirements to run this program because it is specialized to perform on iPhone interface. 20.1.2 Installation Turn on the iPhone then connect to App Store. Move to search menu and type “mviewer” then click “ ”.
  • Page 124 Select “ ” program which is offered from dvrdomain by free. When user clicks a “ ” button, it will be turned to “ ” Click “ ” to start installation. If user already has a iTunes account, then input user’s account to download the program. If user does not have the account, then click “...

  • Page 125: Site Registration

    When user registered the account, the program will be automatically installed. 20.1.3 Site Registration Click “ ” icon on iPhone menu then below will show. Move to “ ” and enter site information which are same as CMS site registration. Enter Site Name, IP or DDNS address.

  • Page 126: Connection

    Enter ID/Password. Click “ ” to save the setting. 20.1.4 Connection On “ ” window, click one of the registered site and click “ ”. Click “ ” to connect the DVR to the iPhone. To select other channels, click the channel bar below the Site Name. If users wish to change the channel among 9~16, then click “...

  • Page 127: Search

    20.1.5 Search Users are able to search the recorded data in the mobile CMS program. Click “ ” to use search function of the application. click “ ” for date setting. If users click “ ”, then the month with recorded data will show up.
  • Page 128 Choose the month that wish to search and click “ ”. Click “ ” to select the date in the month and click “ ” Click “ ” to select the time of the date of the recorded data. And then search the data with the playback buttons on the search menu. If users wish to change the search speed, then click “1x 아이콘”...

  • Page 129: Ptz Control

    20.1.6 PTZ Control Users are able to control PTZ with iPhone by touching the screen. Touch and drag upside on the center of the screen to zoom out. Touch and drag downside on the center of the screen to zoom in. Touch sides and corners of the screen to change the direction as user want.

  • Page 130: Disconnection

    20.1.8 Disconnection When disconnecting, please click “ ” and exit the mobile viewer program. 20.1.9 Uninstallation Click the “ ” icon and hold for a while until the program icon shows x mark on the top-left side. Click the “ ”...

  • Page 131: Android Phone

    20.2 Android Phone 20.2.1 System Requirements This program is designed and applied only for Android OS(version 1.6 or higher) based Smart phones. 20.2.2 Installation Turn on the phone then connect to Android Market. Move to search menu and type “mviewer” then select “ ”...

  • Page 132: Site Registration

    Click “ ” then “ ” to start installation. The program will be automatically installed in user’s application menu. 20.2.3 Site Registration Click “ ” icon on application menu then below will show. Move to “ ” tab and enter site information which are same as CMS site registration. Enter Site Name, IP or DDNS address.

  • Page 133: Connection

    Enter Admin/Stream port value. Enter ID/Password. Click “ ” to save the setting. 20.2.4 Connection Click “ ” icon and select one of the registered site and click “ ”. Move to “ ” tab and click “ ” icon. To change the display mode, click the “...

  • Page 134: Audio

    Users are able to search the recorded data in the mobile CMS program. Click “ ” to use search function of the application. click “ ” to select the month, the date and the time in order. Click “ ” to select the month, the date and the time in order. Users can adjust the speed of playback from x1 to x 64 or extreme.

  • Page 135: Information

    Touch sides and corners of the screen to change the direction as user want. Touch right side of the screen to move right and left side to move left. Touch up side of the screen to move up and down side to move down. In the same way, touch any corners to change the directions.

  • Page 136: Uninstallation

    When disconnecting, please click " ” and exit the mobile viewer program. 20.2.10 Uninstallation Move to Setup > Application > Manage Applications then select “ ”. Click “ ” icon then it will ask to delete the program. Click “ ”...

  • Page 137: Site Registration

    Click “search” icon and type “DVR Viewer” program. Select the “DVR viewer” which is offered from dvrdomain by free and start to install the program by clicking the icon. 20.3.3 Site Registration After downloading the program, click “ ” icon in the download folder or applications folder and the following screen will be shown.

  • Page 138: Connection

    Enter Site Name and IP/Domain. Enter Admin and Stream port. Enter ID and Password. Click “Add” to save the setting. 20.3.4 Connection If the site is registered appropriately, the following screen will be shown. Click “Menu>Connect” to connect the site. Users can select the display mode from 1, 4, 9 and 16 multi view.

  • Page 139: Ptz Control

    20.3.5 PTZ Control Users are able to control PTZ by blackberry phone. Press volume up button on the right side of the phone to zoom in. Press volume down button on the right side of the phone to zoom out. Press 1~9 number buttons to change directions as user want.

  • Page 140: Symbian Mobile

    20.4 Symbian Mobile 20.4.1 System Requirements This program is designed and applied only for Symbian OS based Smart phones. 20.4.2 Installation Turn on the phone then connect to ovi store. Move to “Search all items” and Type “dvr viewer” then click “Search” Select “DVR Viewer “...
  • Page 141 When user clicks a DVR Viewer icon, it will be changed to login page. If user does not have the account, then click “create a Nokia account” and it is registered by free. Type e-mail address and password and select country and type the identified text shown at the below, then you can click “OK”...

  • Page 142: Site Registration

    When users registered the account, then click “download” When downloading has been completed, Click “Launch” to complete the installation. 20.4.3 Site Registration Click “DVR Viewer” icon on Symbian menu then below will show.

  • Page 143: Connection

    Click options and select “New”. Enter the information which is similar as CMS site registration. Enter site Name, IP. Enter Admin/Stream port value. Enter ID/Password Click “Submit” to save the setting. 20.4.4 Connection Click one of the registered site and then select “options” to click “Connect” to choose connection.
  • Page 144 Choose available connection and it will start connecting the DVR to the Symbian. Choose required channel to display. Selected channel will be displayed.

  • Page 145: Ptz Control

    20.4.5 PTZ Control Users are able to control PTZ with Symbian by touching the screen. Touch sides and corners of the screen to change the direction as user want. Touch right side of the screen to move right and left side to move left. Touch up side of the screen to move up and down side.

  • Page 146: Information

    20.4.6 Information Click “Options” and select “About” to check the information of the application. 20.4.7 Disconnection When disconnecting, please click “Disconnect” and exit the mobile viewer program. 20.4.8 Uninstallation Click “option” and select “Remove” to uninstall the program. Click “Yes” button to successfully uninstall the program.

  • Page 147: Windows Mobile

    20.5 Windows Mobile 20.5.1 System Requirements OS : Windows Mobile Professional 6.1 or higher version. Memory : 512Kb or Higher. Device : Smartphone Network : Available all wireless networking method. I.e. Wi-fi, HSDPA, Wibro. 20.5.2 Installation Prepare ActiveSync program to user’s PC. - Available download at following link.
  • Page 148 Click accepting the license agreement, then click “Finish” button. Installation box will appear. Click [OK] to start installation. When installation completed, following pop-up will appear. Click [OK]. If following message appeared, it has successfully installed. (NOTE) Depending on mobile device, successful installation message may not appear. Click [OK] when license agreement message appear.

  • Page 149: Site Configuration

    20.5.3 Site Configuration Click [Add] to appear following screen. Fill in correct information. - Site Name : Insert the name of site. - IP/Domain : Insert the IP address or Domain name of the site. - ID : Input the registered ID of the site. - Password : Input the password of the registered ID.

  • Page 150: Connection

    Correct items then click [Save]. Delete Select a site and click [Del]. Confirmation message will pop up. Click [Yes] then the site information will be removed. 20.5.4 Connection Select a site then click [Connect]. Live display screen of the site will appear if it is successfully connected.

  • Page 151: Uninstall

    Users are able to select a camera by clicking camera button. Click [Disconnect] then, live display screen will be closed and Site list box will appear. 20.5.5 Uninstall Move to [Program Menu> System] then click [Remove Programs]. The currently installed list will show up. Choose Mobile CMS on the list and click [Remove].
  • Page 152 Keyboard Controller Keyboard Controller CP1200A User`s Manual This document contains preliminary information and is subject to change without notice.

  • Page 153: Keyboard Controller

    21. KEYBOARD CONTROLLER 21.1 Connection User may connect cameras and Keyboard through DVR in various ways. Below shows the major probable connection methods through RS-485; 21.1.1 Configuration Diagram I Single system configuration (1 Camera, 1 DVR) DVR PTZ Port RS485 RS485 Tx1+ Tx1-...

  • Page 154: Configuration Diagram Iii

    21.1.3 Configuration Diagram III Multiple system configuration (Multi Cameras, Multi DVRs) Max 16 camera RS485 RS485 RS485 RS485 … … … … Multi port Max 16 DVR DVR 1 DVR 2 … … Multi port Please make sure to connect “Tx to Rx “or “Rx to Tx” with positive polarity. (+ to +) and (- to -). 21.2 Keyboard Setup in DVR Enter “Setup>SYSTEM>Information: System ID”...

  • Page 155: Keyboard Configuration

    21.3 Keyboard Configuration 21.4 Operation 21.4.1 DVR/PTZ Mode conversion Press System ID number (For example, ID: 001 press Num Pad ) with button. OSD will show “KBD:1” in right-bottom side that the keyboard is on DVR mode as below picture; Then, user should be able to operate the DVR functions by the keyboard controller.

  • Page 156: Ptz Control Mode

    the PIP channel. In case of 4 or 9 channel screen, it changes the screen to a next one in the sequence. - FREEZ: freeze a current image. - SETUP: pop up Setup window. - PLAY/PAUSE: play/pause recorded data in play mode. - SEARCH: pop up Search window, or switches play mode to search mode.
  • Page 157 Serial In (POS / ATM) Serial In (POS / ATM) User`s Manual This document contains preliminary information and is subject to change without notice.

  • Page 158: Serial In (Pos/Atm)

    22. SERIAL IN (POS/ATM) 22.1 Usage of Serial-In Function Enables to record/search/display all transactions on monitoring screen by connecting POS/ATM/Cash Register. User can choose the data whether to record/display on their taste without limitedly designated protocols. 22.2 Connection Method Four ATM/POS channels are available as a default. Connect the USB slot of DVR by using USB to RS-232 Converter Cable and it is available to connect up to 4 serial-in devices by using the converter.

  • Page 159: Link

    22.4 Link 22.4.1 Link Setup Click “Setup>Link>” then shows as below. (NOTE) The above menu is only available on the DVR model with Serial-In function. Click “Serial In” to appear following screen. Select POS/ATM port by clicking ‘Serial In’ button. Assign the port to display/record channel by clicking a “Link Camera”.

  • Page 160: Setup

    Tick the box(□) item Alarm In. Click the Time/Date that wishes to activate ATM/POS function on schedule. It is possible to activate all the time by clicking top-right side of table. Click “OK” to save the schedules. (NOTE) Please do not select the Alarm In and Motion simultaneously on schedule setup. Otherwise, POS/ATM text will be displayed improperly.

  • Page 161: Osd Display

    22.5.3 OSD Display OSD items are to decide whether to display the information from the serial port connected to the rs232 port on OSD screen. They have 4 menus as followings: - None : displays nothing on the OSD screen. - Live : displays incoming information from the serial port in real time on the OSD screen.
  • Page 162 Input a certain repeated string to “Line Delimiter”. Decide the number of minimum characters in “MCPL” item to hide data under the designated number of characters. Input the pattern of dummy data to Discard Pattern. Choose the data which willing to display and enter the Start Pattern and End Pattern.

  • Page 163: Search

    Then tick the Auto box off in order to make the DVR recognizes the data between the Start and End patterns. Finally, test again and adjust data to remove missed dummy data. 22.6 Search Using event search function. Please click ( ) the “Search>Event Search” menu on the pop-up menu of the wallpaper, then user will see the following screen.
