- Page 1 Router ADSL2+ Modem/Router Router ADSL2+ Switch 4 Porte Quick Start Guide www.hamletcom.com...
-
Page 2: Package Contents
For more detailed instructions on configuring and using the ADSL2+ Modem/Router, please refer to the on-line manual. Package Contents ADSL2+ Modem/Router CD-ROM containing the on-line manual RJ-11 ADSL/telephone Cable Ethernet (CAT-5 LAN) Cable AC-DC power adapter (12VDC, 1A) for (Wireless) ADSL Router with 4-port Switch AC-AC power adapter (12VAC, 1A) for ADSL Modem/Router with Single Ethernet Port This Quick Start Guide Do not use the ADSL2+ Modem/Router in high humidity or high... -
Page 3: The Front Leds
Quick Start Guide The Front LEDs ADSL2+ Router with 4-port Switch ADSL2+ Modem/Router with Single Ethernet Port Meaning PPP : Lit steady when there is a PPPoA / PPPoE connection. ADSL: Lit when successfully connected to an ADSL DSLAM (“linesync”). Lit when connected to an Ethernet device. -
Page 4: The Rear Ports
The Rear Ports HRDSL512P4 HRDSL512 Port Meaning Power Switch Power ON/OFF switch Connect the supplied power adapter to this jack. After the device is powered on, press it to reset the device or restore to factory default settings. RESET 0-3 seconds: reset the device 6 seconds above: restore to factory default settings (this is used when you can not login to the router, e.g. - Page 5 Quick Start Guide Connect ADSL2+ Modem/Router 1. Connect the Router to a LAN (Local Area Network) and the ADSL/telephone (LINE) network. HRDSL512P4 HRDSL512 2. Power on the device. 3. Make sure the PWR and SYS LEDs are lit steadily and that the relevant LAN LED is lit.
-
Page 6: Configuring Pc In Windows Xp
Configuring PC in Windows XP 1. Go to Start / Control Panel (in Classic View). In the Control Panel, double-click on Network Connections 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties. -
Page 7: Configuring Pc In Windows 2000
Quick Start Guide Configuring PC in Windows 2000 Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties. 4. -
Page 8: Configuring Pc In Windows 98/Me
Configuring PC in Windows 98/Me 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2. Select TCP/IP -> NE2000 Compatible, or the name of your Network Interface Card (NIC) in your PC. 3. - Page 9 Quick Start Guide Configuring PC in Windows NT4.0 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click OK.
- Page 10 This number is the default IP address for this router. Press Enter. 2. A username and password window will appear. The default username and password are admin and Hamlet Press OK to proceed. 3. You will get a status report on web page.
- Page 11 Dear Customer, thanks for choosing Hamlet. Please carefully follow the instructions for its use and maintenance and, once this item has run its life span, we kindly ask You to: dispose of it in an environmentally friendly way, by putting it in the separate bins for electrical/electronic waste, or to bring it back to your retailer who will collect it for free.
