- Page 1 Fast Ethernet Switch 5/8-Port 10/100Mbps User Manual HN05S/HN08S www.hamletcom.com...
- Page 2 Italian Legislative Decree 2005/151 and EMC Directive 2004/108/EC for the following standards: EN 55022: 2006, Class B EN 61000-3-2: 2000 + A2: 2005, Class A (for HN05S) EN 61000-3-2: 2006, Class A (for HN08S) EN 61000-3-3: 1995 + A1: 2001 + A2: 2005...
- Page 3 Moreover, Green Ethernet and Pre-IEEE 802.3az Energy Efficient Ethernet (HN05S only) is supported to save power consumption. The switch is plug and play without any software to configure and also fully compliant with all kinds of network protocols.
-
Page 4: Package Contents
(IEEE 802.3x) • Wire-speed packet filtering and forwarding rate • Store-and-forward architecture filters fragment & CRC error packets • Supports extensive indicators network diagnostics • Supports Green Ethernet function and pre-IEEE 802.3az standard (HN05S only) for power saving... - Page 5 LEDs definition Please refer to the following table for LEDs definition. 5-port switch 8-port switch Status Operation Steady Green The switch is powered on Power The switch is powered off Steady Green Valid port connection The port transmitting or Link/Act Blinking Green receiving data.
- Page 6 Station connection Connect each station to the switch by twisted-pair cable. Plug one RJ-45 connector into a port of the switch and plug the other RJ-45 connector into the station’s network adapter. Connect the power adapter supplied with the product to the power input on the back of the switch and then to a wall electrical outlet.
-
Page 7: Specifications
Specifications Standard IEEE802.3 10BASE-T IEEE802.3u 100BASE-TX IEEE802.3x full duplex flow control IEEE802.3az draft (HN05S only) Interface 5x 10/100 Mbps RJ-45 ports (HN05S) 8x 10/100 Mbps RJ-45 ports (HN08S) Network 10/100 Mbps Auto-negotiation Data Rate Transmission 10/100Mbps: Full-duplex, Half-duplex Mode Buffer Memory 384K bits (5-port) - Page 8 FCC Certifications This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
