Anti-shock compact disc player

Advertisement

Anti-Shock
Compact Disc Player
GCD709RS/GCD709RB/GCD711K
Instruction Manual
Programme Play .................................................... Up to 20 tracks
Line output ............................................................. 0.5 0.1V RMS
Earphone output .................................................... 18mW 0.2
Power requirement ................................................ DC 6V external and battery 3V
Dimension
............................................................. Approx. 136(W) x 31.5(H) x 151.5(D)mm
Weight ................................................................... 230g not including battery (Main Unit)
For improvement purposes, specification and design are subject to change without notice.
Goodmans Product Information Helpline 02392-391100
+
-
+
mW
-
("AA" Cell x 2)
(L R6 or Ni-Cd rechargeable battery)
IMPORTANT NOTES
1. This product does not contain a separate Power On/Off switch. After inserting a disc and
installing batteries / AC adaptor, simply press the Play button to switch on and play a disc.
2. In order to maximize battery life and provide optimum playing time this product
incorporates an Auto Power Off function.
The power to the player will automatically switch off approximately 30 seconds after a disc
has finished playing .
3. The ASP function is automatically engaged when playback starts. For more information,
see section 14 of these instructions.
Helpline No: 02392 - 391100
WARNING
1. To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
2. To avoid electrical shock, do not open the
cabinet. Refer servicing to qualified
personnel only.
3. Do not put anything in the safety slot. If you
do, the laser diode will be ON when the lid
is still opened.
LOW BATTERY ALERT
When the BATT indicator flashes in the LCD display, this means that the batteries are losing their
charge. In this case the CD player will not function properly and the batteries must be replaced. In
the case that rechargeable batteries are being used follow the instruction on how to recharge the
batteries detailed in this owner's manual.
4. If the unit is not to be used for a long period
of time, make sure that all power sources
are disconnected from the unit. Remove
all batteries from the battery compartment,
and unplug the AC adaptor from the wall
outlet. Make it a practice to remove the AC
adaptor by grasping the main body and
not by pulling the cord.
5. The unit employs a laser. The use of
controls or adjustments or performance of
procedures other than those specified
herein may result in exposure to
hazardous radiation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GCD709RS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Goodmans GCD709RS

  • Page 1 ("AA" Cell x 2) (L R6 or Ni-Cd rechargeable battery) Dimension ............. Approx. 136(W) x 31.5(H) x 151.5(D)mm Weight ..............230g not including battery (Main Unit) For improvement purposes, specification and design are subject to change without notice. Goodmans Product Information Helpline 02392-391100...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY PRECAUTIONS 1. POWER SOURCES NORMAL BATTERIES/AC ADAPTOR Power Sources Normal Batteries/AC adaptor..1 1. As the laser beam used in this compact Battery Power Operation AC Operation disc player is harmful to the eyes, do not Charging and Use of Rechargeable Batteries..
  • Page 3: Charging And Use Of Rechargeable Batteries

    2. CHARGING AND USE OF RECHARGEABLE BATTERIES 3. EARPHONE AND HI-FI CONNECTION Rechargeable Battery Operation Listening with the earphone Connecting to component audio systems Connect the plug of the stereo earphones (included) or headphones (not included) Connect a stereo connection cable (not This unit can fully recharge the specified rechargeable batteries, in approximately 15 hours.
  • Page 4: Player Maintenance

    4. PLAYER MAINTENANCE 5. DISC CLEANING AND TROUBLESHOOTING GUIDE Cleaning the Cabinet Cleaning the Disc When a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the centre out. Wipe with a soft cloth. If the cabinet is very dirty, dampen the cloth with a weak solution of neutral detergent and water, and then wipe clean.
  • Page 5: Product Specifications

    6. PRODUCT SPECIFICATIONS 7. BASIC DISC PLAY PICK-UP 1. Slide the OPEN button to open the CD compartment lid. Connect the earphones System Compact disc digital audio system to the earphone socket. Laser diode material: GaAIAs 2. Adjust the VOLUME to minimum. Properties Wavelength: =780nm...
  • Page 6: Location Of Controls

    8. LOCATION OF CONTROLS 9. LCD DISPLAY INFORMATION When the is pressed at initial start up. the disc will begin to spin and after several seconds, the total number of tracks and total playing time will be shown on the display , then it will 1.
  • Page 7: Skip Function

    10. SKIP FUNCTIONS 12. REPEAT PLAY MODES Locating a particular track Press the P MODE button once or twice. The corresponding repeat appears in the display window. To go back to the beginning of the Press lightly and repeatedly. current or a previous track To go to the beginning of the following Press lightly and repeatedly.
  • Page 8: Digital Anti Shock Operation

    13. INTRO SCAN AND PROGRAMMED TRACK PLAY 14. DIGITAL ANTI SHOCK OPERATION This player incorporates the latest electronic digital anti shock circuit, which prevents interruption of P MODE (Continued) the sound output when the unit is subjected to shock or vibration during disc playback. If in use the player is likely to be subjected to shock or vibration (i.e.
  • Page 9: Car Adaptor Kit

    15. CAR ADAPTOR KIT 15. CAR ADAPTOR KIT PRECAUTIONS WHEN USING COMPACT DISC CASSETTE ADAPTER Use this set only with the supplied The Car Cassette Adapter allows you to Cigarette Lighter Adapter. Use with other use your CD player with your car stereo Cigarette Lighter Adapters could damage cassette system or portable audio cassette the set.
  • Page 10: Important Notes

    Average city traffic, alarm clock buzzer at 2 feet, food mixer. 90dB Motorcycle, heavy goods vehicle, petrol lawn mower. Pneumatic drill, chain saw, garbage truck, discotec / night-club. Rock band concert, thunderclap. PERMANENT LOSS OF HEARING THRESHOLD OF PAIN Gunshot 2 feet away. Rocket Launching pad. IB01354-CD27G-G(ESP)-GOODMANS-E 8HIC 06/13/02...
