Page 1: User Manual
Refrigerator User Manual Model No.: FDG192M15S / FDG222M15S / FDG252M15S *Before operating the appliance, please read this manual and all the safety instructions thoroughly and retain it for future reference. -
Page 2: Table Of Contents
CONTENT PAGE SAFETY INSTRUCTION INSTALLATION INSTRUCTION PARTS DESCRIPTION OPERATION INSTRUCTION MAINTENANCE INSTRUCTION TROUBLESHOOTING SPECIFICATION WARRANTY... -
Page 3: Safety Instruction
SAFETY INSTRUCTION IMPORTANT SAFETY INSTRUCTIONS – READ CAREFULLY AND KEEP FOR FUTURE REFERENCE To avoid electric shock, fire or injury, please read and comply with the user manual carefully before using the appliance and keep it for future reference. This appliance is for household use only. Please use suitable power source. (Please refer to SPECIFICATION) Never immerse the appliance in water or other liquids. - Page 4 NOTICE Contact the authorized service technician for repair or maintenance of the appliance. The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Page 5 Electricity related warnings Do not pull the power cord when pulling the power plug of the refrigerator. Please grasp the plug and pull it out from the socket directly. Do not use the appliance when the power cord is damaged or the plug is worn.
- Page 6 Related warnings for use Unauthorized demolition or renovation of the refrigerator is prohibited. It is forbidden to damage the refrigerant lines and repair of the refrigerator must be carried out by professionals. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid hazards.
-
Page 7: Warnings Related To Placing Items
Warnings related to placing items Do not put flammable, explosive, volatile and highly corrosive items in the refrigerator to prevent damages to the product or fire. Do not place flammable items near the refrigerator to avoid fire. This product is for household use only and shall be only suitable for the storage of foods. -
Page 8: Installation Instruction
INSTALLATION INSTRUCTION Before using the refrigerator, remove all The refrigerator should be placed packaging materials including bottom in a well-ventilated indoor place; cushions, foam pads and tapes inside the the ground shall be flat and stable refrigerator, tear off the protective film (rotate left or right to adjust the on the door and the refrigerator body. - Page 9 Installing and removing the accessories To remove the shelf: Grip the shelf, then lift it straight upward. To reinstall, reverse the procedure. To dismantle the flexible door rail: Pull out the tray first then draw the pedestal of the door rail outward. Do not dismantle the tray and the pedestal at the same time.
-
Page 10: Parts Description
PARTS DESCRIPTION Panel of air duct Freezer Ice cube box compartment Glass shelf Control knob Cool compartment Storage corner Control panel Panel of air duct Fresh food compartment Glass shelf Fruit and vegetables crisper *Photo for reference only. The interior design will be slightly different in different models. Fresh food compartment 1. -
Page 11: Operation Instruction
OPERATION INSTRUCTION Control Panel & Control Knob SET Key Temperature Control Indicator All lights of the control panel will be on for 3 sec for every power on, then the set temperature control indicator will be on. SET Key Press the SET key to set the temperature level. Temperature Control Indicator To display the selected temperature level from left to right: Level 1 (the highest temperature setting/the minimum cooling setting) -
Page 12: Automatic Defrosting
Ice Making Procedure 1. Take the ice cube box out from the freezer compartment. 2. Pour cool water into the ice cube box, then put the ice cube box back into the freezer compartment. 3. Turn over the ice cube box and pour the ice cubes into the vessel under it after the ice is frozen. -
Page 13: Maintenance Instruction
MAINTENANCE INSTRUCTION Please unplug the refrigerator before cleaning. Do not use hard brushes, clean steel balls, wire brushes, abrasives, such as toothpastes, organic solvents (such as alcohol, acetone, etc.), boiling water, acid or alkaline items to clean the refrigerator considering that these may damage the surface and the interior of the refrigerator. - Page 14 Stop using Foods can be preserved for a couple of hours even in summer in case of power failure; it is recommended to reduce the frequency of opening door and do not put fresh foods into the freezer compartment. Please unplug the refrigerator left unused for a long time for cleaning. Keep the door open to avoid bad odour.
-
Page 15: Troubleshooting
TROUBLESHOOTING The following situations are not malfunction: The sides of the refrigerator will be heat up while the condenser is working, but this will not influence the cooling performance. As the temperature of the compartment will be high when the refrigerator is just started, it will take a span of time to decrease the temperature. - Page 16 If any case of malfunction happens, please inspect and dispel it according to the methods shown in the following table: Situation Check point Not refrigerating Check if there is power failure. Check if the power cord is plugged into the power socket. ...
-
Page 17: Specification
SPECIFICATION Model No. FDG192M15S FDG222M15S FDG252M15S Rated Voltage/Frequency 220-240V~/50Hz Rated Current (A) Climate Class Refrigerant, Amount R600a, 45g Fresh Food Compartment Volume (L) Freezer Compartment Volume (L) Net Weight (kg) Gross Weight (kg) 57.5 61.5 Product Dimensions (mm) 550x623x1372 550x623x1522... -
Page 18: Warranty
WARRANTY 1. The product has 3 years warranty from the date of purchase. 2. The warranty shall not apply: A. to any product subjected to misuse, alteration, act of God, improper handling, improper transport, improper testing or unauthorized repair; B. to cosmetic problems or defects which result from normal wear and tear under ordinary use yet not affecting the performance or use of the product;...
