Clas Ohlson C156-B Instruction Manual

Cross-Cut Paper Shredder
Art.no 44-1734 Model C156-B
Please read the entire instruction manual before using the product and
then save it for future reference. We reserve the right for any errors in
text or images and any necessary changes made to technical data.
In the event of technical problems or other queries, please contact our
Customer Services.
Safety
• Place the machine as close to a wall outlet as possible.
• Always remove the plug from the wall socket before moving or
cleaning the shredder.
• Always remove the plug from the wall socket before emptying
the waste collector bin. Empty the collector bin regularly in order to
avoid jamming the machine because of the container being over full.
• Never open the casing. If you should have problems with
the shredder, contact Customer Services.
• The product is designed exclusively for domestic use.
The machine is not designed for commercial use.
Warning symbols
General warning symbol.
Read the instructions before use.
Keep your hands away from the feeder opening.
Keep your hair away from the feeder opening.
It may be pulled in and injure you.
Keep loose hanging objects, like clothes, ties, etc away from
the feeder opening. They may be pulled in and damaged.
Keep loose hanging jewellery away from the feeder opening.
They may be pulled in and damaged.
Remove all paper clips and staples before running
documents through the shredder.
GREAT BRITAIN - CUSTOMER SERVICE contact number: 020 8247 9300 e-mail: customerservice@clasohlson.co.uk
English
This product is not a toy and must not be used by children.
Never leave the shredder unattended when in operation.
DO NOT use sprays when cleaning the interior or exterior
of the shredder. DO NOT use flammable substances
near the product. DO NOT spray directly into or near to
the feeder opening.
Getting started
1. Place the shredder unit onto the waste bin. There is a safety
interlock switch under edge of the shredder unit which is pressed
in when the shredder is placed correctly onto the waste bin.
The switch must be pressed in for the shredder to operate.
2. Place the waste bin on a firm, level surface.
3. Plug the shredder into a wall socket which supplies power
at the same voltage as that marked on the rating plate of
the product.

Operating instructions

Note:
• Bear in mind that
paper and CDs/
DVDs/Credit cards
must be fed into
the shredder through
different openings. Paper
• Do not feed paper, CDs, DVDs or credit cards into the shredder at
the same time. Feed different kinds of materials into the shredder
separately.
• Let the shredder cool down for 30 min after it has been used
continuously for 2 min (2 min is the maximum length of time that
the shredder should be used continuously).
• Empty the waste bin regularly. If the bin is full it is difficult or
impossible to continue feeding the shredder.
Capacity
• The shredder can process up to 10 sheets (A4, 80 g) at one
time. If you run thicker paper stock the number of sheets
the shredder can process is reduced. The maximum width of
the paper should be 22 cm (A4).
• If you want to shred smaller sheets of paper, you should feed them
in the centre of the feeder opening. Otherwise, the shredder will
not start automatically.
Avoiding overloading and jamming
The shredder is equipped with an overload safety cut-off. The safety
cut-off is tripped and the shredder is switched off if:
• The shredder is run at maximum capacity for too long. Example:
If paper, CDs/DVDs or credit cards are fed into the shredder
continuously for over 2 minutes.
• If the maximum paper capacity is exceeded by feeding more than
10 sheets of paper into the shredder at the same time, or if it is
not fed in straight.
To reset the shredder after the overload safety cut-off has tripped:
1. Remove the plug from the wall socket and let the shredder cool
for 30 min. Clear the blades of any paper remnants.
2. Connect the plug to a wall socket and set the control switch to
REV mode. Excess paper remnants will exit through the feeder
opening. Remove the plug from the wall outlet and remove any
paper remnants from the blades.
3. Set the switch to AUTO mode.
Care and maintenance
CD/DVD/Credit card
• Always unplug the appliance from the wall socket before cleaning.
• Feed sheets of lubrication paper (Clas Ohlson art.no 36–4038)
into the shredder at regular intervals to keep the machine running
smoothly.
• Clean the product by wiping it with a dry cloth.
• Clear the blades from paper remnants using a sharp object.
• Empty the waste bin regularly. A full waste bin can contribute to
a diminished shredder performance.
Disposal
Follow local ordinances when disposing of this product.
If you are unsure of how to dispose of this product,
please contact your municipality.

Specifications

Rated voltage
Type
Capacity
Feed entry width
Shredding speed
Waste bin capacity 21 l
Size (W × H × D)
internet: www.clasohlson.co.uk
230–240 V AC, 50 Hz
Cross-cut 5 × 18 mm
10 sheets (80 gsm) at a time,
1 CD/DVD/credit card at a time
Paper: 220 mm, CD/DVD: 120 mm
1.5 m/min (10 sheets)
35 × 44 × 22 cm (shredder mounted onto waste bin)
