WARNING – To prevent fire or shock hazard, do not expose this unit to moisture. CAUT ION This symbol is intended to alert the user to the presence of uninsured “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
Page 3
- Consult the dealer or an experienced radio/TV technician for help NOTE: Record Model Number and Serial Number in the space provided below. Refer to these numbers if you need to call your AUDIOVOX dealer regarding this product. MODEL No. _____________________ SERIAL No.
IMPORTANT SAFETY INFORMATION Read Instructions – All the safety and operating instructions should be read before the product is operated. Retain Instructions – The safety and operating instructions should be retained for future reference. Head Warnings – All warnings on the product and in the operating instructions should be adhered to.
Page 5
13. Power-Cord Protection – Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product. 14.
Page 6
21. Replacement Parts – When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards. 22.
Table Of Contents Before You Begin Installation Remote Control Functions Modes of Operation Technical Specifications Troubleshooting Check List Introduction... 1 Important Safety Information... 3 Table of Contents ... 6 Contents of package ... 7 Under Cabinet Installation... 8 Countertop/Desktop Installation... 9 Front Panel Controls...
CONTENTS OF PACKAGE 1. VE705 TV 2. Hardware bag A. 3/4” Mounting screws (4) B. 1-1/4” Mounting screws (4) C. 1-1/2”Mounting screws (4) D. Foot (4) E. Hole cap (4) 3. Remote Control 4. Multi Height Spacer (4) P W R...
The spacers and mounting holes are stepped to achieve different mounting heights from .5” to 1”. Adjusting the mounting height is done by lifting and rotating the spacer in the mounting hole. Choose a spacer height, which will allow the VE705 to clear the edg e molding.
COUNTERTOP/DESKTOP INSTALLATION TE: Use caution to avoid damaging the LCD screen and the main unit when con is unit from an under-counter unit to a countertop unit. Leave the protective plastic screen until this procedure is completed. Place the unit (with the screen facing up) on a soft padded surface. Pivot the screen so that it is perpendicular to the front of the unit and then turn it sideways.
Insert the rubber pieces (#6) (Foot, Mounting Cap - please refer to the illustration above) into the unit. Install the blank cover on the unused port. FRONT PANEL CONTROLS ON/OFF ON/OFF BUTTON – Power ON/OFF. SET BUTTON – Press this button to set the ADD BUTTON –...
AC LINE CORD – Connects to AC power outlet FM ANTENNA – Allows the VE705 to be connected to a 75-Ohm the reception of FM broadcast signals. AM ANTENNA - Allows the VE705 to be connected to an external antenna for the reception of AM broadcast sign als.
BATTERY INSTALLATION 1) Turn the Remote Control face down. Place a fingernail, or coin in the open slot, slide battery holder out. 2) Install the CR2025 battery into its proper slot. (Note: Be sure to observe the correct polarity when inserting the battery). 3) Slide the battery holder in until it clicks.
REMOTE CONTROL FUNCTIONS 1. POWER ON/OFF (PWR) Press this button to turn the VE705 on. Press the button again to turn the VE705 off. 2. ENTER (ENT) This button not used on the VE705 3. CHANNEL UP/DOWN ( Press these buttons to advance to the next higher or lower channel.
The sc reen may also be rotated from side to side. Do not force t The VE705 is now ready for use. Pressin g the PWR button on the unit or the remote will turn the system on or off. Rem e unit off and pivot the s creen to the closed position when not in use.
ETTING and ACTIVATING ALARM NOTE: The VE705 must be turned “OFF” when performing the following procedure. 1) Press the SET button twice to enter the alarm mode, press the P3 button to toggle between the active and deactivated mode. NOTE: If a series of dashes appear (--: --), the Alarm is DEACTIVATED.
SETTING THE AIR TV MODE 1) Press the SET button three times to enter the TV/Cable configuration mode. 2) Press the SEEK button to select the AIR mode. Press the POWER button to confi TING THE PRESETS (IN AM, FM OR TV MODES) Tune the desired channel/station.
TECHNICAL SPECIFICATIONS ERAL Power Supply Operating Temperature Operating Humidity Body Size Weight DISPLAY Illumination Backlighting Life Expectancy Resolution Screen MISC TV Channels TV System Radio Frequency Range Audio output AC100-240V ~50/60 Hz 40watts 0°~40°C / 32°~104°F 10% ~ 75% 394 X 259 X 47mm / 15.5” x 10.2” x 1.9”Inches 1.8 Kg / 3.97Lbs CCFL Edge Lit Tube 10,000Hrs...
Poor Reception Remote control will not function Black and White Reception Solution • Verify Tuner setting matches Antenna/Cable broadcast system. • Verify that the sensor on the VE705 is not obstructed. • erify that infrared transmitter is not obstructed. •...
