- Page 1 FPE1908 19” HD FLAT PANEL LCD TV OWNER’S MANUAL FOR ASSISTANCE CALL CUSTOMER SERVICE AT 1-800-645-4994 OR VISIT US AT WWW. AUDIOVOX.COM 128-8060 E - 1 English.indd 1 6/11/2008 12:36:03 PM...
-
Page 2: English.indd
SAFETY PRECAUTIONS WARNING : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”... -
Page 3: Table Of Contents
IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 4: Quick Installation
When you turn on your television set for the first time, be sure to place it on a solid stable surface. To avoid danger, do not expose the TV to water, or a heat source (e.g. lamp, candle, radiator). Do not obstruct the ventilation grid at the rear and be sure to leave sufficient gaps around the unit as shown. -
Page 5: Accessories
ACCESSORIES Please check and identify the supplied accessories. Remote Control (with batteries) ... x 1 USING THE REMOTE CONTROL • Point the remote control at the remote sensor located on the unit. • When there is a strong ambient light source, the performance of the infrared remote sensor may be degraded, causing unreliable operation. -
Page 6: Control Reference Guide
CONTROL REFERENCE GUIDE REMOTE CONTROL 1. FUNCTION Button Press to switch between TV / AV In / YUV In / PC In. 2. Number (0 - 9) Buttons [dot] Button Press to enter digital sub-channels (i.e. 11.3 or 12.7) 4. EXIT Button Press to exit the TV SETUP menu and return directly to normal viewing. - Page 7 CONTROL REFERENCE GUIDE FRONT AND SIDE VIEWS Button Press to turn the unit on and off. 2. MENU Button Press to enter the on-screen TV menu. 3. FUNCTION Button Press to select TV / AV in / YUV in / PC in. CH / CH Buttons Press to select a TV channel...
-
Page 8: Connections
CONNECTING A TV ANTENNA / CABLE / SATELLITE To view television channels correctly, a signal must be received from one of the following sources: - An indoor or outdoor aerial antenna - A cable system - A satellite system Connecting a Digital Antenna The tuner in this TV receives ATSC TV signals from an antenna. -
Page 9: Connecting Devices With A Composite (Yellow Rca-Type) Video Output
CONNECTING DEVICES WITH A COMPOSITE (YELLOW RCA-TYPE) VIDEO OUTPUT To connect A/V devices such as a VCR, video game system or camcorder. Connecting to a VCR / Video Game System / Camcorder Connect the AUDIO / VIDEO cable (not included) as shown. Make sure you connect the cable from the other equipment (AUDIO and VIDEO OUT) to this unit (AUDIO and VIDEO IN). -
Page 10: Connecting A High-Definition (Hd) Source
CONNECTING A HIGH-DEFINITION (HD) SOURCE High-Definition (HD) Devices with component video output must be connected to the YUV input. Connect the component video cable and audio cable (not included) as shown. Make sure you connect the component video cable and audio cable from the other equipment (COMPONENT VIDEO OUT and AUDIO OUT) to this unit (COMPONENT VIDEO IN and AUDIO IN - YUV IN). -
Page 11: Connecting An Audio Amplifier
CONNECTING AN AUDIO AMPLIFIER This connection allows you to use an audio amplifier and external speakers. Connect the AUDIO cable (not included) as shown. Make sure you connect the cable from the other equipment (AUDIO IN) to this unit (AUDIO OUT). -
Page 12: Installation
INSTALLATION REMOVING THE BASE STAND WARNING: The LCD Display is very fragile, and must be protected at all times when removing the base stand. Be sure that no hard or sharp object, or anything that could scratch or damage the LCD display, comes into contact with it. -
Page 13: Tv Setup
Note: Some setting items on the menu screen may not activate depending on what mode the unit is currently in (TV/AV in/YUV in/PC in). PICTURE MENU 1. Press the MENU button. 2. Press the button to enter PICTURE settings. 3. Use the button to select the options (Picture Mode, Contrast, Brightness, Sharpness, Tint or Color). -
Page 14: Time Menu
TIME MENU 1. Press the MENU button. 2. Use the button to select TIME, then press the button to enter the TIME settings. 3. Use the button to select the options (OSD Duration, Sleep Timer, Time Zone or Day Saving Time). -
Page 15: Parental Menu
PC Set Up (in PC mode only) - Resolution : 1,440 x 900 max - Refresh Frequency : 60Hz max H - Pos : Center the image by moving it left or right. V - Pos : Center the image by moving it up or down. Clock : Adjusts the display clock to change width of the image. - Page 16 Parental 1. Use the button to select various Parental settings. Adjust them using the button, or press the to go into the detailed settings. 2. Press the MENU button to return to the previous menu. 3. Repeat steps 1 - 2 to adjust other options. 4.
-
Page 17: Tv Menu
TV MENU (For TV Mode Only) 1. Press the MENU button. 2. Use the button to select TV, then press the button to enter the TV settings. 3. Use the button to select the options (Antenna, Auto Scan, Auto Scan Add CH, Channel Skip, Channel No. -
Page 18: Maintenance
CLEANING THE UNIT • Be sure to turn the unit off and disconnect the AC power cord before cleaning the unit. • Wipe the unit with a dry soft cloth. If the surfaces are extremely dirty, wipe clean with a cloth that has been dipped in a weak soap-and-water solution and wrung out thoroughly. - Page 19 Unit : INCH 10 15/16 E - 19 English.indd 19 6/11/2008 12:36:58 PM...
