Surveon CAM64 Series User Manual

Speed dome ip camera series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Speed Dome IP Camera Series

User Manual

Release 1.0
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAM64 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Surveon CAM64 Series

Summary of Contents for Surveon CAM64 Series

  • Page 1: User Manual

    Speed Dome IP Camera Series User Manual Release 1.0...

  • Page 2: Copyright Statement

    Product specifications are also subject to change without notice. Trademarks Surveon and Surveon logo are trademarks of Surveon Technology Inc. Other names prefixed with “SMR” and “EMR” are trademarks of Surveon Technology Inc. Microsoft Windows and Windows are registered trademarks of Microsoft Corporation.

  • Page 3: Revision History

    Revision History Version Description Date Initial release January 2016...

  • Page 4: Table Of Contents

    Table of Contents Copyright Statement ................. 2 Revision History ................3 Table of Contents ................4 Safety Precautions ................9 Device Installation/Site Selection ............10 Chapter 1. Product Overview ............. 11 1.1. Network Camera Introduction ........... 11 1.2. Features and Benefits ............. 12 1.3.
  • Page 5 Setting the Camera's IP ..............30 Chapter 5. Configuration through Viewer Window Interface ....... 32 5.1. Overview ................32 5.2. Interface Layout ..............33 5.3. Home Page ................34 Function Items on the Home Page ........... 34 Multiple Languages Support ..............34 Digital Zoom Control.................
  • Page 6 HTTPS ..................42 Create Self-signed Certificate .............. 42 Install Signed Certificate ..............44 Provide the Certificate Information ............44 IP Filter ..................45 Delete IP Address ................47 IEEE 802.1X ................... 47 Network ................. 49 Basic ................... 49 QoS ..................... 52 SNMP ...................
  • Page 7 Device Setting ................77 Disk Cleanup Setting ................. 77 Recording List ................77 Recording ................79 File Location (Snapshots and Web Recording) ........81 Factory Default ................. 83 Software Version ............... 84 Software Upgrade ..............84 Maintenance ................85 5.5. Streaming ................85 Video Format .................
  • Page 8 Cruise Setting ................. 91 Cruise Run ..................92 Auto Pan ................. 92 Auto Pan Setting ................92 Auto Pan Run ................. 92 Sequence ................93 Sequence Setting ................93 Sequence Run ................. 93 Home ..................94 Home Setting ................. 94 Tilt Range ................

  • Page 9: Safety Precautions

    Safety Precautions Electric Shock Warning This equipment may cause electric shocks if not handled properly. Access to this equipment should only be granted to trained operators  and maintenance personnel who have been instructed of, and fully understand the possible hazardous conditions and the consequences of accessing non-field-serviceable units such as the power supplies.

  • Page 10: Device Installation/Site Selection

    Device Installation/Site Selection The device should be installed according to specifications. This device should be operated at a site that is: Clean, dry, and free of excessive airborne particles.  Well-ventilated and away from heat sources such as direct sunlight and ...

  • Page 11: Chapter 1. Product Overview

    Chapter 1. Product Overview 1.1. Network Camera Introduction Speed Dome Camera series are professional network cameras that use Internet Protocol (IP) to transmit video streams and control signals over networks. Capable of operating over both LANs and WANs, they provide a complete budget-conscious remote surveillance solution that are ultra clear and highly integrated.

  • Page 12: Features And Benefits

    1.2. Features and Benefits Speed Dome IP camera is a cutting-edge digital video transmission device. It can compress and transmit real-time images of outstanding quality using a reasonable amount of bandwidth through a standard TCP/IP network. The following features make this IP camera an outstanding choice when building an intelligent IP surveillance system: High Video Quality ...
  • Page 13 Tampering Detection  This is an intelligent video analytics application available only in selected network cameras in the market. When a camera is manipulated in any way (e.g. accidental redirection, blocking, defocusing, spray-painted, covered or damaged), it can automatically trigger recording and alert notifications. Power-over-Ethernet ...

  • Page 14: Technical Specifications

    1.3. Technical Specifications CAM6471EZ 3 Megapixel 30x Zoom D/N Outdoor Speed Dome Network Camera Specifications for CAM6471EZ CAM6471EZ Model Name Description 3 Megapixel 30x Zoom D/N Outdoor Speed Dome Network Camera 1/2.8" megapixel Sony Progressive CMOS Image Sensor f4.4 - 132 mm autofocus lens, F1.4 (wide) - F4.7 (tele) Lens 50dB Day/Night ICR...
  • Page 15 Supported Protocols PPPoE, UPnP, IGMP, SNMP, QoS, ARP, ONVIF RJ-45, 1Gbps Ethernet Ethernet microSDXC (64GB) Local Storage RS-485 Surveon SDK 2.0 Microsoft Windows 7/8 IE 6.x or above, Firefox, Chrome, Safari Browser Surveon VMS 2.5 Software Operation: -40°C~ 50°C (-40°F~122°F)

  • Page 16: Chapter 2. Hardware Overview

    Chapter 2. Hardware Overview 2.1. Overview Bottom View 1. LAN Connector 2. Alarm In/Out Connector 3. Power Connector Slot 4. MicroSDHC Card Slot 5. Reset Button 6. Audio In/Out Connector...

  • Page 17: Dimensions

    2.2. Dimensions Unit: mm (inches)

  • Page 18: Camera Setup

    2.3. Camera Setup Preparation for Dome Camera Setup 1. Unpack the dome package and take out the dome body. 2. Remove the plastic wrapping on the dome cover. 3. Remove the Styrofoam sheet from the inside of the dome cover. 4.

  • Page 19: Camera Cable Connections

    7. Gently pressure the dome cover downward with two hands on the side of it. 8. Use one M3 Screw and the original two screws to screw the dome cover and camera body together. Camera Cable Connections Connecting Power Pin definitions of the power connector: Definition Color of Power Wire Connected AC 24-...
  • Page 20 1. Connect the power wires of AC adapter with the power connector. Please check the colors of the power wires carefully, and screw them with the connector properly. Warning: When done connecting the cables to the connector, please check for LIVE WIRES! Do not leave “LIVE WIRES”...

  • Page 21: Connecting Power With Optional Ac Adapter

    Connecting Power with Optional AC Adapter Adjust the power selector according to the practical local power voltage, and connect the power cord with the adapter and power outlet. Note: Contact your dealer for purchasing the adapters. Connecting LAN Cable 1. Connect one end of the LAN cable to the LAN connector of the network Speed Dome Camera, and the other end of the cable to the network switch or PC.

  • Page 22: Applying Audio (Optional)

    Definition Definition ALARM_OUT_COM_2 ALARM_OUT_NO_1 ALARM_OUT_NC_1 ALARM_IN_4 ALARM_OUT_COM_1 ALARM_IN_3 ALARM_IN_2 ALARM_OUT_NO_2 ALARM_OUT_NC_2 ALARM_IN_1 Applying Audio (Optional) Set up the audio according to the audio pin definition. Definition LINE_OUT LINE_IN Inserting and the Micro SDHC Card (Optional) 1. Make sure the golden finger of the Micro SDHC card is facing downwards. 2.

  • Page 23: Chapter 3. Installation

    Chapter 3. Installation 3.1. Ceiling Mounting Package Contents of Ceiling Mounting Kit M8x12 Screw x1 Spring Washer-8 x1 Pendant Tube Washer x1 Rubber Washer-8 x1 Sponge x2 Items Needed Waterproof Rubber x1 (provided with the package of the camera) M5 Screw x1 (provided with the package of the camera) Screws and Screw Anchors for fixing the Straight Tube onto the ceiling (provided by users) Tools Needed...
  • Page 24 3. Fix the Straight Tube to the ceiling with screws and screw anchors. 4. Fit the Waterproof Rubber to the Straight Tube. (You may turn the Waterproof Rubber inside out, which is shown in the picture below, to make the fitment easier.) 5.
  • Page 25 6. After threading the cables, please block the cable entry hole with the supplied sponge(s) to avoid insects entering the tube. 7. Fix the Outdoor Flange to the Straight Tube with the supplied screw (M8x12) and washers. Then adjust the Waterproof Rubber. 8.

  • Page 26: Wall Mounting

    3.2. Wall Mounting Package Contents of Wall Mounting Kit M8x12 Screw x1 Spring Washer-8 x1 Pendant Tube Washer x1 Rubber Washer-8 x1 Sponge x1 Items Needed Waterproof Rubber x1 (provided with the package of the camera) M5 Screw x1(provided with the package of the camera) Screws and Screw Anchors for fixing the Pendant onto the wall (provided by users) Tools Needed Electric Drill...
  • Page 27 2. Fix the Pendant on the wall with screws and screw anchors. 3. Fit the Waterproof Rubber to the Pendant. (You may turn the Waterproof Rubber inside out, which is shown in the picture below, to make the fitment easier.) 4.
  • Page 28 7. Mount the Dome Camera to the Outdoor Flange. Rotate the dome body and make sure the thread holes on the Lock Screw Plate and Outdoor Flange are aligned. Then screw the M5 Screw.

  • Page 29: Camera Deployment

    3.3. Camera Deployment 3.4. Before You Start Please prepare a PC with Windows (XP or above) and web browsers (Internet Explorer 6.0 or above) installed.

  • Page 30: Chapter 4. Connecting To The Network Camera

    Chapter 4. Connecting to the Network Camera 4.1. Accessing the Camera Setting the Camera's IP The network speed Dome camera’s default IP address is: 192.168.0.250. Therefore, to access the camera for the first time, set the PC’s IP address as 192.168.0.XXX;...
  • Page 31 Installing Active X Components in Internet Explorer (Optional) After connecting to the camera, the request for installing the ActiveX control will appear just below the URL bar. Right Click on the information bar, and click Install ActiveX Control… to permit ActiveX control installation. In the pop-up security warning window, click Install to start downloading DC Viewer software on the PC.

  • Page 32: Chapter 5. Configuration Through Viewer Window Interface

    Chapter 5. Configuration through Viewer Window Interface Overview 5.1. The Full HD Speed Dome IP Camera transmits digital video and audio data using wire connection. Live video can be monitored and recorded from window-based computer via network. The video encoder supports real-time Main Profile H.264 Full HD resolution. Simultaneous dual streams, H.264/H.264 and H.264/MJPEG, are available for various network applications via speeding or limited bandwidth.

  • Page 33: Interface Layout

    Interface Layout 5.2. This section demonstrates the layout of the network Speed Dome Camera’s main interface. The five setting tabs on the interface are: 1. Home: Users can monitor live video of the targeted area. 2. System: The Administrator can set host name, system time, root password, network related settings, etc.

  • Page 34: Home Page

    5.3. Home Page Click on the tab Home to access the home Page. There are several function buttons on the Home pate. Detailed information of each item is as described in the following chapter. Function Items on the Home Page Multiple Languages Support Multiple languages are supported, including German, English, French, Italian, Korean, Simplified Chinese, Russian, etc.

  • Page 35: Snapshot Button

    Snapshot Button Click on the button and the JPEG snapshots will automatically be saved in the appointed place. The default place of saving snapshots is: C:\. To change the storage location, please refer to File Location for further details. Note: For users with Windows 7 operating system, it is required to log on as an Administrator to implement the Web Recording function.

  • Page 36: Pan& Tilt Direction Control

    Pan& Tilt Direction Control The <Pan and Tilt Direction Control> on the control panel allows uses to control the camera with browser viewers other than IE. Iris Control (Auto Iris / Iris+ / Iris-) Click on the buttons (Auto ExpComp / Increase Exposure / Decrease Exposure) to adjust the value of Exposure Compensation.
  • Page 37 Manual button Click on the <Manual> button, and users can adjust focus manually via Near / Far buttons. Near / Far buttons Click on the <Manual> button first, and users can adjust focus manually via <Near> and <Far> buttons. The foxus status will also be displayed above the live video pane.

  • Page 38: System

    5.4. System Under the System tab, there are categories as the table below: System Security Network DDNS Mail HTTP Application Motion Detection Tampering System Storage Management Recording File Location View Log File View User Information View Parameters Factory Default Software Version Software Upgrade Maintenance Note: The System Configuration page is only accessible by the Administrator.

  • Page 39: System

    System The System Setting can be found under the path: System > System. Host Name The name is for camera identification. If alarm function is enabled and is set to send alarm message by Mail/FTP, the host name entered here will display in the alarm message.
  • Page 40 NOTE: The synchronization will be done every time the camera boots up. Click on <Save> to confirm the setting.

  • Page 41: Security

    Security The Security Setting can be found under this path: System > Security. Click the Security category, there will be a drop-down menu with tabs including User, HTTPS, IP Filter, and IEEE 802.1X. User The User setting can be found under this path: System > Security > User. Admin Password Change the administrator’s password by inputting the new password in both text boxes.

  • Page 42: Https

    Manage User Delete User Pull down the <User name> drop-down list and select the username that is wished to be deleted. Click on <Delete> to remove the selected name. Edit User Pull down the <User name> drop-down list and select the username. Click on <Edit> and a popup window will appear.
  • Page 43 Click on Create Button under Create Self-signed Certificate and provide the requested information to install a self-signed certificate for the IP Camera. Please refer to the last part of this section: Provide the Certificate Information for more details. Note: The self-signed certificate does not provide the same high level of security as when using a CA-issued certificate.

  • Page 44: Install Signed Certificate

    Install Signed Certificate Click on the Create Certificate Request Button to create and submit a certificate request in order to obtain a signed certificate from CA. Provide the request information in the create dialog. Please refer to the following Provide the Certificate Information for more details.

  • Page 45: Ip Filter

    Organization Unit Enter the name of the organizational unit to which the entity identified in Common Name belongs. Common Name Indicate the name of the person or other entity that the certificate identifies (often used to identify the website). Valid days Enter the period in days (1~9999) to indicate the valid period of certificate.
  • Page 46 Step 1: Convert 192.168.2.81 to binary numbers. The binary numbers are 11000000.10101000.00000010.01010001. Users can refer to Appendix B: IP Addresses from Decimal to Binary for converting the IP addresses to binary numbers. The number “30” after the slash is referring to the first 30 digits of the binary numbers. Step 2: Convert a few IP addresses before and after 192.168.2.81 to binary numbers.

  • Page 47: Delete Ip Address

    c. Repeat the same procedure in “a” with the IP addresses after 192.168.2.81. Stop when the situation occurs in “b” happened. Namely, the 30th digit of the binary numbers of IP address 192.168.2.84 is different, and will not be filtered. As a result, the IP addresses 192.168.2.80 to 192.168.2.83 will be filtered when entering 192.168.2.81/30.
  • Page 48 Enter the user identity associated with the certificate. Up to 16 characters can be used. Private Key Password Enter the password (maximum 16 characters) for your user identity. Enable IEEE 802.1X Check the box to enable IEEE 802.1X. Click on Save to save the IEEE 802.1X/ EAP- TLS setting.

  • Page 49: Network

    Network The Network setting can be found under this path: System > Network. Click on the Network category, there will be a drop-down menu with tabs including Basic, QoS, SNMP, and UPnP. Basic The Basic setting can be found under this path: System > Network > Basic. Users can choose to connect to the IP Camera with fixed or dynamic (DHCP) IP address.
  • Page 50 Use fixed IP address Select the item and insert the new IP address, ex. 192.168.7.123. Note that the inserted IP address should be in the same LAN as the PC’s IP address. Then go to the Default gateway (explained later) blank and change the setting, ex. 192.168.7.254. Click on <Save>...
  • Page 51 Use PPPoE For the PPPoE users, enter the PPPoE Username and Password into the fields, and click on the Save Button to complete the setting. Advanced Web Server port The default web server port is 80. Once the port is changed, the user must be notified the change for the connection to be successful.

  • Page 52: Qos

    IPv6 Address Configuration With IPv6 support, users can use the corresponding IPv6 address for browsing. Enable IPv6 by checking the box and click on Save to complete the setting. The QoS (Quality of Service) setting can be found under this path: System > Network >...

  • Page 53: Snmp

    SNMP The SNMP (Simple Network Management Protocol) setting can be found under this path: System > Network > SNMP. With Simple Network Management Protocol (SNMP) support, the IP Camera can be monitored and managed remotely by the network management system. SNMP v1/ v2 Enable SNMP v1/ v2 Select the version of SNMP to use by checking the box.
  • Page 54 There are two encryption types available: DES and AES. Select <AES> for a higher security level. Encryption Password The minimum length of the encryption password is 8 characters and the maximum length is 512 characters. The input characters / numbers will be displayed as dots for security purposes.

  • Page 55: Upnp

    Trap Option Warm Start A Warm Start SNMP trap signifies that the SNMP device, i.e. IP Camera, performs software reload. Click on Save Button when complete. UPnP The UPnP setting can be found under this path: System > Network > UPnP. UPnP Setting Enable UPnP When the UPnP is enabled, whenever the IP Camera is presented to the LAN, the...

  • Page 56: Ddns

    DDNS The DDNS setting can be found under this path: System > DDNS. Dynamic Domain Name System (DDNS) allows a host name to be constantly synchronized with a dynamic IP address. In other words, it allows those using a dynamic IP address to be associated to a static domain name so others can connect to it by name.

  • Page 57: Ftp

    The FTP setting can be found under this path: System > FTP. The Administrator can set as sending alarm message to a specific File Transfer Protocol (FTP) site when an alarm is triggered. Users can assign alarm message to up to two FTP sites.

  • Page 58: Alarm Setting

    Alarm Setting Alarm Switch The Administrator can enable or disable the alarm function. Alarm Type Select an alarm type, Normal Close or Normal Open, that corresponds with the alarm application. Triggered Action (Multi-option) The Administrator can specify alarm actions that will take at an alarm occurrence. All options are listed as follows: Enable Alarm Output 1/2 Select these items to enable alarm relay outputs.
  • Page 59 uploading by E-mail when the alarm input is triggered. The setting range is from 1 sec. to 99999 sec. Select <Upload during the trigger active> to make the images keep being uploaded to E-mail during the trigger active until the alarm is released. Set the Image frequency as the upload frame rate.
  • Page 60 PTZ Function Assign a camera function: Preset, Sequence, Autopan or Cruise, and specify a Preset Point/Sequence Line/Autopan Path/Cruise Line for the camera to perform at an alarm occurrence. Note: Please refer to the sections through Preset to Sequence for details of Preset Point/Cruise Line/Autopan Path/Sequence Line setups.
  • Page 61 File Name Enter a file name in the File name field, ex. image.jpg. The uploaded image’s file name format can be set in this section. Please select the one that meets your requirements. Add Date/Time Suffix File name: imageYYMMDD_HHNNSS_XX.jpg Y: Year, M: Month, D: Day H: Hour, N: Minute, S: Second X: Sequence Number Add Sequence Number Suffix (No Maximum Value)

  • Page 62: Motion Detection

    Motion Detection The Motion Detection setting can be found under this path: System> Events> Motion Detection. Motion Detection function allows the camera to detect suspicious motion and trigger alarms when motion volume in the detected area reaches / exceeds the determined sensitivity threshold value.

  • Page 63: Motion Detection Setting

    Motion Detection In each set of Motion Detection Setting, the default setting for the Motion Detection function is <Off>. Enable the function by selecting <On>. Users can also activate the function according to the schedule previously set in the <Schedule> setting page.

  • Page 64: Triggered Action (Multi-Option)

    Triggered Action (Multi-option) The Administrator can specify alarm actions that will take when motion is detected. All options are listed as follows: Enable Alarm Output 1/2 Check the item and select the predefined type of alarm output to enable alarm relay output when motion is detected.

  • Page 65: File Name

    Pre-trigger buffer recording function allows users to check what happened to cause the trigger. The pre-trigger buffer time range is from 1 sec. to 3 sec. Select <Upload for __ sec> to set the recording duration after motion is triggered. The setting range is from 1 sec.

  • Page 66: Network Failure Detection

    Network Failure Detection The Network Failure Detection setting can be found under this path: System> Events> Network Failure Detection. Network Failure Detection allows the camera to ping another IP device (e.g. NVR, VSS, Video Server, etc.) within the network periodically and generates some actions in case of network failure occurs, for instance, a Video Server is somehow disconnected.

  • Page 67: Periodical Event

    The administrator can select whether to send an alarm message by FTP and/or E-mail when an alarm is triggered. Save Click on the <Save> button to save all the settings mentioned above. Periodical Event The Periodical Event setting can be found under this path: System> Events> Periodical Event.
  • Page 68 Upload Image by E-Mail Select this item and the administrator can assign an E-mail address and configure various parameters. Images will be uploaded to the appointed E-mail address periodically. The <Pre-trigger buffer> function can define how many images to be uploaded before the triggered moment.
  • Page 69 Manual Trigger The Manual Trigger setting can be found under this path: System> Events> Manual Trigger. With Manual Trigger setting, the current image(s) or video can be uploaded to the appointed destination, such as an FTP site or an E-mail address. The administrator can specify the triggered actions that will take when the users switched the Manual Trigger button to ON.
  • Page 70 NOTE: Make sure the FTP configuration has been completed. Refer to section FTP for further details. Upload Image by E-Mail Select this item and the administrator can assign an E-mail address and configure various parameters. When the alarm is triggered, event images will be sent to the appointed E-mail address.
  • Page 71 Send HTTP notification Check this item, select the destination HTTP address, and specify the parameters for event notifications by <Alarm> triggered. When an alarm is triggered, the notification can be sent to the specified HTTP server. For instance, if the custom parameter is set as “action=1&group=2”, and the HTTP server name is “http://192.168.0.1/admin.php”, the notification will be sent to HTTP server as “http://192.168.0.1/admin.php? action=1&group=2”...
  • Page 72 Save Click on <Save> to save all the settings mentioned above.
  • Page 73 Audio Detection The Audio Detection setting can be found under this path: System> Events> Audio Detection. Audio Detection function allows the camera to detect audio and trigger alarms when audio volume in the detected area reaches / exceeds the determined sensitivity threshold value.
  • Page 74 Upload Image by FTP Select this item and the administrator can assign an FTP site and configure various parameters. When audio is detected, event images will be uploaded to the appointed FTP site. <Pre-trigger buffer> function allows users to check what happened to cause the trigger.
  • Page 75 __sec> and enter the duration in the blank.The images of the duration will be uploading by E-mail when the audio event occurs. The setting range is from 1 sec to 99999 sec. Select <Upload during the trigger active> to make the images keep being uploaded to E-mail during the trigger active until the event stops.
  • Page 76 Add sequence number suffix up to # and then start over File Name: imageXX.jpg X: Sequence Number The file name suffix will end at the number being set. For example, if the setting is up to “10”, the file name will start from 00, end at 10, and then start all over again. Overwrite The original image in the FTP site will be overwritten by the new uploaded file with a static filename.

  • Page 77: Device Information

    Device Information When users insert the Micro SD/SDHC card, the card information such as the memory capacity and status will be shown at Device Information section. When the memory card is successfully installed, the memory card status shall be shown at Device Information section in the Storage Management page. Device Setting Click on the Format Button to format the memory card.
  • Page 78 Download To open/download a video clip, select the file first, and then click on the Download Button below the Recording List field. The selected file window will pop up. Click on the AVI file to directly play the video in the player or download it to a specified location.

  • Page 79: Recording

    Recording List Each video file on the Network Share will be listed in the Recording list. The maximum file size is 60 MB/per file. When the recording mode is set as <Always> (consecutive recording) and the NAS recording is also allowed to be enabled by events triggered, once events occur, the system will immediately implement events recording to the memory card.
  • Page 80 Recording Storage Select a recording storage type, <SD Card> or <Network Share>. Activating the Recording Schedule Two types of schedule mode are offered: <Always> and <Only during time frame>. Users can select <Always> to activate microSD / SDHC Card or Network Share Recording all the time.

  • Page 81: File Location (Snapshots And Web Recording)

    Setting Schedules To set a schedule, select a time frame from the time frame list first. Then check the weekday boxes below to choose the specific weekdays. At last, select a time mode, Day, Night or Time. Under Time mode, specify the start time (hour:minute) and the time duration (hour:minute) to activate the schedule triggered features.

  • Page 82: View Information

    View Information The View Information function can be found under this path: System> View Information. Click on the category: <View Information>, there will be a drop-down menu with tabs including <Log File>, <User Information>, and <Parameters>. Log File The Log File function can be found under this path: System> View Information>...

  • Page 83: Factory Default

    User Information The User Information function can be found under this path: System> View Information> User Information. The administrator can view the login information and privileges of each added user (refer to section Security). Get User Information All users in the network will be listed in the <User information> zone as shown below. User: 4321 It indicates that one user’s login username is “User”, and the password is “4321”.

  • Page 84: Software Version

    Partial Restore Click on <Partial Restore> to recall the factory default settings. The camera system will restart in 30 seconds. Refresh the browser page after the camera system is restarted. NOTE: The IP address will not be restored to default. Reboot Click on <Reboot>...

  • Page 85: Maintenance

    100%, the upgrade process is finished. After the upgrade process is finished, the viewer will return to Homepage. 4. Close the video browser. 5. Go to Start, activate Control Panel, and then double click on Add or Remove Programs. In the Currently Install Programs list, select DCViewer and click on the Remove Button to uninstall the existing DC Viewer.

  • Page 86: Video Format

    Video Format The Video Format setting can be found under this path: Streaming> Video Format. Video Resolution Under Video Resolution section, the available video resolution formats are including MJPEG and H.264. Please refer to Appendix D: Video Resolution for more combination details.

  • Page 87: Text Overlay Settings

    Text Overlay Settings Users can select the items to display data including date/time/text on the live video pane. The maximum length of the string is 20 alphanumeric characters. Click on Save to confirm the Text Overlay setting. Video Rotate Type Users can change video display type if necessary.

  • Page 88: Video Compression

    Video Compression The Video Compression setting can be found under this path: Streaming > Video Compression. Users can select a proper MJPEG/H.264 compression mode on the video compression page, depending on the application. MJPEG Q (Quality) Factor Higher value implies higher bit rates and higher visual quality. The default setting of MJPEG Q factor is 35;...

  • Page 89: Video Ocx Protocol

    Video OCX Protocol The Video OCX Protocol setting can be found under this path: Streaming > Video OCX Protocol. In the Video OCX protocol setting page, users can select RTP over UDP, RTP over TCP, RTSP over HTTP or MJPEG over HTTP, for streaming media over the network. In the case of multicast networking, users can select the Multicast mode.

  • Page 90: Server Gain Setting

    In the Full-duplex mode, the local and remote sites can communicate with each other simultaneously, i.e. both sites can speak and be heard at the same time. Half-duplex (Talk or Listen, Not at the Same Time) In the Half-duplex mode, the local/remote site can only talk or listen to the other site at a time.

  • Page 91: Ptz

    Under the tab <PTZ>, there are categories including: <Preset>, <Cruise>, <Auto Pan>, <Sequence>, <Home>, <Tilt Range>, <Privacy Mask>, <Camera- Exposure>, <Camera- WB>, <Camera- Misc1>, <Camera- Misc2>, <Camera- Profile>, and <Camera- Default>. Preset The Preset Programming can be found under this path: PTZ > Preset. Totally 256 Preset Points can be programmed for the IP Camera.

  • Page 92: Cruise Run

    programming, click on the Set Button of Record End to quit. Then this Cruise Path will be automatically recorded. Cruise Run Select the specified Cruise Path from the drop-down list, click on the Run Button, and then the camera will start touring around as recorded. To view the camera touring around in full screen mode, please move the cursor onto the live view pane, right-click and left-click to select Full Screen.

  • Page 93: Sequence

    To view the camera panning in full screen mode, please move the cursor onto the live view pane, right-click and left-click to select “full screen”. Then users can view the camera navigation in full screen. To stop running an Auto Pan Path, simply move the cursor to the live view pane and move the camera in any direction.

  • Page 94: Home

    To view the camera executing a Sequence Line in full screen mode, please move the cursor onto the live view pane, right-click and left-click to select Full Screen. Then users can view the camera navigation in full screen. To stop running the Sequence Line, simply move the cursor to the live view pane and move the camera in any direction.

  • Page 95: Tilt Range

    Tilt Range The Tilt Range Setting can be found under this path: PTZ > Tilt Range. The IP Camera’s tilt angle is adjustable from minimum -10° to maximum 190°. Please enter the desired minimum and maximum tilt angle into the corresponding fields respectively.

  • Page 96: Camera - Exposure

    Color Setting Select a desired color from the <Color> drop-down list for the specified Privacy Mask. Click on <Set> to apply the Privacy Mask’s color properties. Mask Number (1~16) Specify the number of the programmed Privacy Mask in the corresponding field. The numbers of Privacy Masks vary with camera models.
  • Page 97 NOTE: For Full HD Ultra-WDR Speed Dome IP Camera, this mode will not be shown when video format with “WDR” is selected under <TV System>. P-Iris Mode In this mode, the minimum iris opening is limited to affect the exposure. The minimum iris opening can be adjusted from F4.8 to F19.

  • Page 98: Camera - Wb (White Balance)

    Iris Priority Mode In this mode, it is the iris that has the premier priority in control of the exposure. The value of iris is adjustable from F1.6 to F28. The minimum shutter speed range is configurable from 1/30 sec. to 1 sec. (NTSC) or 1/25 sec. to 1 sec. (PAL). Manual Mode In this mode, users can change the Shutter Speed, Iris, and Gain manually.
  • Page 99 suitable for environments with light source having color temperature in the range roughly from 2500K to 10000K. One Push With One Push function, white balance is adjusted and fixed according to the scene the camera sees at the moment. This function is best for situations with minimal scene changes and continuous lighting.

  • Page 100: Camera - Misc 1 (Miscellaneous Setups Menu 1)

    Camera - Misc 1 (Miscellaneous Setups Menu 1) The Miscellaneous Setting Menu 1 can be found under this path: PTZ > Camera- Misc In the Camera- Misc (Miscellaneous) Setup Menu 1, users can set various camera parameters including Backlight Compensation (BLC), Sharpness, Exposures Compensation (ExpComp), Image Flip, Digital Zoom, Speed by Zoom and Day/Night Function.

  • Page 101: Camera - Misc 2 (Miscellaneous Setups Menu 2)

    Click on <Set> to confirm the setting. Digital Zoom Select <On> to enable the Digital Zoom function. Click on <Set> to confirm the setting. Speed by Zoom This function allows the camera to adjust the pan/tilt speed automatically by the internal algorithm when the zoom ratio is changed.
  • Page 102 NOTE: The WDR function and the Auto Defog function are mutually exclusive. Thus, once the WDR function is enabled, the Auto Defog function will be disabled. Inverse (Full HD Ultra-WDR Speed Dome IP Camera Only) When the Image Inverse function is activated, the image will be inversed vertically and horizontally.
  • Page 103 The following table shows the available video formats for different types of models. The supported video formats for each model are marked by “v”. Full HD Ultra-WDR Full HD Speed Model Speed Dome Dome IP Camera Video Format IP Camera 1080p 60 fps NTSC 3M 30 fps...

  • Page 104: Camera- Default

    Step 8. Follow the steps above to set the rest of the profiles. Now, the camera will automatically switch profiles according to the schedule. Alternatively, manually select a number from the Num drop-down list. Then, click on <Load>, the camera will load and applied the setting of the profile. NOTE: If users wish to set the camera parameters to factory default setting, select <Normal>...

  • Page 105: Logout

    5.6. Logout Click on the Logout tab on the top of the page, and the login window will pop up. This enables login with another user name. 5.7. Appendix Appendix A: Install UPnP Components Please follow the instructions below to install UPnP components. 1.

  • Page 106: Appendix B: Ip Addresses From Decimal To Binary

    Appendix B: IP Addresses from Decimal to Binary Follow the example below to convert the IP addresses to binary numbers. Use the calculator on the computer for conversion. The calculator can be found under this path: Start> All Programs> Accessories> Calculator. For Windows XP and Windows Vista, click <View>...
  • Page 107 Click on the category <Autotracking>, the <Autotracking> and <Insert Key> tabs will be shown in the drop-down menu. Enter the setting menu by clicking the <Autotracking> tab. Autotracking The default setting of the Autotracking function is <Off>. Select <On> to enable the function.
  • Page 108 Enable tilt limit Tick the box to enable the tilt limit setting. Get U Tilt / D Tilt Please click and drag the PTZ pointer in the view window to the desired up or down tilt position. Then click on the <Get U Tilt> / <Get D Tilt> button to get the boundary values.
  • Page 109 NOTE: Repeat the steps from <Sequence line> to <Guard Time> for setting other preset points. Home Setting This function allows users to set the main monitoring area as the home position for the camera. In addition, maximum time can also be set for defining the time for the camera to keep watching a stopped tracking object.
  • Page 110 Guard Timer Setting This function allows users to set the main monitoring area as the guard position, and set the duration of time for the camera to track an object. NOTE: <Preset Setting> must be <Off> in order to configure the <Guard Timer Setting>...
