LabJack UE9 User Manual page 76

Command:
Byte
0 Checksum8
1 0xF8
2 0x01
3 0x0E
4 Checksum16 (LSB)
5 Checksum16 (MSB)
6 0x00
7 bits[0:6] BlockNum 0-7
bit 7: 1 = ReadCurrent
Response:
Byte
0 Checksum8
1 0xF8
2 0x11
3 0x0E
4 Checksum16 (LSB)
5 Checksum16 (MSB)
6 Errorcode
7 0x00
8-39 Data
5.4 - Low-Level Errorcodes
Following is a list of the low-level function errorcodes.
Defaults Map
Block Number Byte Offset
0 0-3
0 4 FIO Directions
0 5
0 6 EIO Directions
0 7
0 8 CIO Directions
0 9
0 10 MIO Directions
0 11
0 12-15
0 16 Config Write Mask
0 17 NumOfTimersEnabled
0 18 Counter Mask
0 19
0 20-31
1 0 (32) Clock_Source
1 1 (33)
1 2-15 (34-47)
1 16 (48) TMR0 Mode
1 17 (49) TMR0 Value L
1 18 (50) TMR0 Value H
1 19 (51)
1 20 (52) TMR1 Mode
1 21 (53) TMR1 Value L
1 22 (54) TMR1 Value H
1 23 (55)
1 24 (56) TMR2 Mode
1 25 (57) TMR2 Value L
1 26 (58) TMR2 Value H
1 27 (59)
1 28 (60) TMR3 Mode
1 29 (61) TMR3 Value L
1 30 (62) TMR3 Value H
1 31 (63)
2 0 (64) TMR4 Mode
2 1 (65) TMR4 Value L
2 2 (66) TMR4 Value H
2 3 (65)
2 4 (68) TMR5 Mode
2 5 (69) TMR5 Value L
2 6 (70) TMR5 Value H
2 7-15 (71-79)
2 16-17 (80-81) DAC0 (2 Bytes)
2 18-19 (82-83)
2 20-21 (84-85) DAC1 (2 Bytes)
2 22-31 (86-95)
3 0-15 (96-111)
3 16-31 (112-127) AIN BP/Gain
4 0-15 (128-143)
4 16-31 (144-159)
Description Nominal Values
Not Used 0x00
0x00
FIO States 0xFF
0x00
EIO States 0xFF
0x00
CIO States 0xFF
0x00
MIO States 0xFF
Not Used 0x00
0x00
0x00
0x00
Pin Offset 0x00
Not Used 0x00
0x02
Divisor 0x00
Not Used 0x00
0x0A
0x00
0x00
Not Used 0x00
0x0A
0x00
0x00
Not Used 0x00
0x0A
0x00
0x00
Not Used 0x00
0x0A
0x00
0x00
Not Used 0x00
0x0A
0x00
0x00
Not Used 0x00
0x0A
0x00
0x00
Not Used 0x00
0x0000
Not Used 0x0000
0x0000
Not Used 0x00
AIN Res 0x12
0x00
AIN Settling 0x00
Not Used 0x00
