- Page 1 3DAURORA Series 3DAURORA + 3DAURORA570 + 3DAURORA570S GZ-FSCA1-ANS/ANB/ATS/ATB(3DAURORA) GZ-FA1CA-ASS/ASB(570) GZ-FA1CB-AJS/AJB(570S) English User’s Manual...
- Page 2 Thank you for purchasing GIGABYTE Tech. thermal product. GIGABYTE Tech. is dedi- cated to the integration of casing liquid/air-cooling solution technology to provide users with the most optimal solution for thermal dissipation. The five features of the 3DAURORA series casing include state-of-the-art design, cooling technology, liquid/ air cooling support, system security, easy installation and etc.
-
Page 3: Table Of Contents
Installation of 3.5” Front Device Bay Installation of 3.5” Internal Device Bay Application of DIY Projector Bracket 4-10 Application of Security locks 4-11 Application of Foot Supports 4-12 Application of Liquid Cooling System 4-13 Recommended GIGABYTE Tech. Thermal Solution products... -
Page 4: Components Introduction
1. Components Introduction 1-1 Casing’s Internal Structure Power Supply Bay PCI Tool-Free Fastener Motherboard tray and 5.25” Front Device Bay PCI Slot panel... - Page 5 Extension Cablex2 Stand Offx9 / 570 Copper Stand Offx12 c.Securing Runnerx10 d.Key x 2 e.Wire clamp x 2 f.3DAURORA / 570S Moth- g.Power Supply Securing h.DIY Spare Transparent erboard Securing Screw x screw x 4 Projector Panel x 1 (Default “3DAURORA”...
-
Page 6: Front, Rear, And Left Side Panel Structure
Front Panel c-2 Security Lock c-2 Security Lock c-3 Power / Reset c-3 Power / Reset Switches, Front Switches, Front Multi-Media I/O Multi-Media I/O port port c-4 Projector c-4 Projector 3DAURORA 3DAURORA 570 3DAURORA 570S C - Front Panel... -
Page 7: Features
Complete front panel multi-media support, which consists of 2 x USB 2.0, 1 x IEEE1394, 1 x audio jacks (HD & AC97) Full Support of GIGABYTE Tech. thermal solution LCS and Air cooling products lines Support ATX/Micro ATX/Flex ATX motherboard ( 3DAURORA / 3DAURORA 570S ) -
Page 8: Specifications
3.3DAURORA Specification Model : GZ-FSCA1-ANS/ANB/ATS/ATB Case Type : FULL TOWER Size : 205 X 522 X 510 (W X H X D) Front Bezel Material : Aluminum Color : Silver/Black Side Panel : Ventilated mesh (ANS/ANB) / Transparent (ATS/ATB) Body Material : Aluminum(1.0mm) / nickel-plated SECC(1.0mm) -
Page 9: Installation Instruction
Fasten the screws to secure the cross bar after the power supply installed. 4-2 Installation of Motherboard 3DAURORA / 3DAURORA 570S is compatible with the ATX/Micro ATX/Flex ATX motherboards. 3DAURORA 570 is compatible with the ATX/Micro ATX/Flex ATX/CEB/E-ATX motherboards. -
Page 10: Installation Of Add-On Card
F1-F6 CEB(570) E1-E8 E-ATX(570) E1-E12 4-3 Installation of Add-On card 3DAURORA / 3DAURORA 570 / 3DAURORA 570S supports tool-free installation of interface cards, e.g. graphic card or sound card, etc. 4-3-1 Unlock the 4-3-2 Remove the PCI slot re- internally tention lock. -
Page 11: Installation Of Front Multi-Media I/O Ports
4-4 Installation of Front Multi-Media I/O Ports Incorrect connector installation may possibly burn out the motherboard and other components. Be sure to observe the instructions on installation manual. Any loss caused by nonobservance of the proper operation provided is not covered by the warranty. The connector or socket may be different to different motherboards. -
Page 12: Connection Of Cooling Fan Power Lines
4-5 Connection of Cooling Fan power lines 3DAURORA / 3DAURORA 570 / 3DAURORA 570S has one 12cm silent blue LED cooling fan at the front, and two at the rear. There is a cable tidy to connect three fans into one 3-pin connector, place the 3-pin... -
Page 13: Installation Of 5.25" Front Drive Bay
4-6 Installation of 5.25” Front Drive Bay 4-6-1 Open the front panel door and side 4-6-2 Slide-in the 5.25” device through the panel, remove the plastic bezel and alu- front panel to inline with front panel minum EMI plate through internal of the bezels. -
Page 14: Installation Of 3.5" Internal Device Bay
4-9 Application of DIY Projector Bracket Please connect the LED 4-pin power connecter to the 4-pin power connector from power supply unit. 3DAURORA / 3DAURORA 570 / 3DAURORA 570S is provided with extra transparent projector panel, which can be customized into a personalized logo and replaced with the provided “3DAURORA”... -
Page 15: Application Of Security Locks
Insert the key and turn 90° to lock or unlock. 4-11 Application of Foot Supports There are four foot supports for the 3DAURORA 570/570S to ensure the case is firmly seated on the holding surface. Swivel these four feet 90° to change the position. -
Page 16: Recommended Gigabyte Tech.thermal Solution Products
4-13 Recommended GIGABYTE Tech.Thermal Solution products 3DAURORA / 3DAURORA 570 / 3DAURORA 570S is recommended to use GIGABYTE Tech. thermal solution products...
