G-Tek PWG-500 Quick Manual

Hide thumbs Also See for PWG-500:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
PWG-500 Q
Congratulations on your purchase of the PWG-500, a VoIP (Voice over Internet
Protocol) and GSM (Global System for Mobile communications) phone that also
functions as your personal wireless gateway for connecting to wireless networks.
Read this user manual carefully to understand how to operate the product and
take advantage of its useful features.
The PWG-500 enables you to make phone calls using GSM or VoIP networks.
Moreover, you can also connect to Wi-Fi (Wireless Fidelity) (802.11b) or GPRS
(General Packet Radio Service) networks using the PWG-500 as a modem or
using Bluetooth.
About the PWG-500

Front view

Menu / Select
Up arrow
Down arrow
Send / Answer
Display
Microphone
G
UICK
UIDE
Menu
Select
ABC
GHI
JKL
PQRS
TUV
Speaker
Wi-Fi On/Off
Wi-Fi
On/Off
VoIP / GSM
VoIP
GSM
Clear / Delete
End / Reject
DEF
Keypad
MNO
WXYZ
Menu
Wi-Fi
Select
On/Off
VoIP
GSM
ABC
DEF
GHI
JKL
MNO
PQRS
WXYZ
TUV
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PWG-500 and is the answer not in the manual?

Questions and answers

Related Manuals for G-Tek PWG-500

Summary of Contents for G-Tek PWG-500

  • Page 1: Front View

    Read this user manual carefully to understand how to operate the product and take advantage of its useful features. The PWG-500 enables you to make phone calls using GSM or VoIP networks. Moreover, you can also connect to Wi-Fi (Wireless Fidelity) (802.11b) or GPRS (General Packet Radio Service) networks using the PWG-500 as a modem or using Bluetooth.

  • Page 2: Side Views

    PQRS WXYZ Power button USB port Volume up Earphone Reset button Volume down Power in Display indicators In standby mode, the PWG-500 screen displays the following icons: VoIP / GSM VoIP Wi-Fi mode bandwidth signal strength signal strength Battery charge...

  • Page 3: Using The Menu

    Wi-Fi Select On/Off VoIP The G-Tek PWG-500’s menu lets you access the product settings and set up the PQRS WXYZ device according to the network conditions. The menu is set up in a simple and easy-to-understand manner. Follow these steps to access the menu and menu items.

  • Page 4: Inserting The Sim Cards And Battery

    Inserting the SIM cards and battery Menu Wi-Fi Select On/Off VoIP 1. Push the tab on the back to 5. Place the SIM card holder PQRS WXYZ remove the battery cover. back in place. 2. Move the desired SIM card 6.

  • Page 5: Charging The Battery

    Wi-Fi Select On/Off VoIP The PWG-500 is provided with a rechargeable Li-ion battery with 4 hours talk PQRS WXYZ time and 72 hours standby time. To charge the battery, connect the battery charger to the Power in slot and insert the power connector into a power outlet.

  • Page 6: Setting The Time And Date

    Setting the time and date Menu Wi-Fi Select On/Off VoIP The clock settings enable you to set the time and date on the PWG-500. Press PQRS WXYZ Menu/Select and select Settings, Clock to view the clock settings. The following options are available: •...

  • Page 7: Adjusting The Volume

    Adjusting the volume While talking on the PWG-500, use the Volume up/down keys to increase or decrease the volume according to your preference. You can also adjust the ring tone using the keys when not talking on the phone.

  • Page 8: Using The Phone Book

    Menu Wi-Fi Select On/Off VoIP The phone book is an important component of the PWG-500 for storing contact PQRS WXYZ information about your friends, relatives, and colleagues. This eliminates the need for you to memorize important phone numbers. Note: The storage capacity of the phone book depends on the SIM card memory.

  • Page 9: Voip Settings

    • Select Wi-Fi Connectivity and select Automatic to connect to a wireless network in the vicinity automatically. The PWG-500 scans for wireless hotspots automatically. Alternatively, select Manual to connect to a wire- less network manually. A list of hotspots is displayed. Select a hotspot to connect to the corresponding wireless network.

  • Page 10: Gsm Settings

    GPRS is a network service that allows you to use your phone for sending and receiving data over an IP network. The GPRS settings enable you to set up the PWG-500 for GPRS mode. Press Menu/Select and select Settings, GPRS to con- figure the GPRS settings. The following options are available: •...

  • Page 11: Connecting To The Pc

    The WIM application is a useful interface that lets you set up and configure the PWG-500 from your PC or PDA. You can select GSM, VoIP, GPRS, and Wi-Fi pro- files and personalize them according to your network specifications. You can also use the application to download ringtones, configure SOS numbers for the phone, and make any setup changes for the phone.
  • Page 12 Double-click the WIM icon to start the application from your PC or PDA. Menu Wi-Fi Select On/Off VoIP PQRS WXYZ Click the tabs on the interface to access various functions and features of the application. Phone book Use the Phone Book to store your address and contact details.
  • Page 13 Messages Menu Wi-Fi Select On/Off VoIP To send an SMS, click the Messages but- PQRS WXYZ ton. The SMS screen is displayed. Use the Edit option to write text messages. Config. Stat To configure WIM, click the Config.Stat button. This brings up the WIM configuration util- ity.

  • Page 14: Browsing The Internet From The Pc

    Wi-Fi Select On/Off VoIP You can use the PWG-500 to browse the Internet or check e-mails using a Wi-Fi PQRS WXYZ network or a GPRS network. If Wi-Fi has been enabled and a wireless hotspot is available in the vicinity, then Internet connectivity is automatically achieved through the Wi-Fi network.

  • Page 15: Connecting To A Pda

    PWG-500 can be paired with an unlimited number of Bluetooth devices. You can pair the PWG-500 with your PDA by adding the PWG-500 to the list of paired devices using the Bluetooth manager. For pairing, you have to enter the pass-key or PIN (Personal Identification Number).

  • Page 16: Using Gprs To Browse The Internet

    Using GPRS to browse the Internet Menu Wi-Fi Select On/Off VoIP In order to use GPRS to connect to the Internet, you have to first set up a dial-up PQRS WXYZ connection to the GPRS network. GPRS settings differ for different area net- works.
  • Page 17 3. Click Next. 4. In the My Connection screen, enter the Menu Wi-Fi Select On/Off VoIP country code, area, code, and phone PQRS WXYZ number to connect to the GPRS number. Consult your service provider for this information. Click Next | Finish to com- plete creating the connection.
  • Page 18 A login screen is displayed. 7. Enter the user name and password for the GPRS network and click OK. The PWG-500 connects to the GPRS net- work and the PDA in turn is also con- nected. After you are connected to the network, you can browse the Internet or check e-mails as needed.

  • Page 19: Using Wi-Fi To Browse The Internet

    PQRS WXYZ on the PWG-500. This can be done directly from the PWG-500 as described in the user manual under “Wi-Fi settings” or from the PDA using the WIM configu- ration utility. Set up the wireless connection mode, security settings, and authen- tication parameters such as user name, password, and ESSID from the PWG-500.
