Combustion Research reflect-o-ray eds 3.5 Installation Operation & Maintenance

Oil fired low intensity infrared vacuum vented infrared heating systems
Hide thumbs
Table of Contents

Advertisement

Quick Links

FOR YOU SAFTEY
If you have a Fuel Oil leak:
Open windows
1.
DO NOT try to light any appliance.
2.
DO NOT use electrical equipment.
3.
Shut off Fuel Oil supply.
4.
Leave the building.
5.
Immediately call your local Fuel Oil
6.
supplier after leaving the building.
Follow Fuel Oil supplier's
instructions.
If you cannot reach your Fuel Oil
7.
supplier, call the Fire Department.
WARNING
!
Fire Hazard
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
Some objects will catch fire or explode
when placed near this heater.
Failure to follow these instructions can
result in death, injury or property
damage.
!
Read and understand these installation,
operating and maintenance instructions
thoroughly before installing or servicing
this equipment. Only trained, qualified gas
installation and service personnel may
install or service this equipment.
Please take time to read and understand these
instructions prior to any installation. Installer must
give a copy of this manual to the owner.
Keep this manual in a safe place in order to provide
your serviceman with the necessary information.
Combustion Research Corp.
2516 Leach Rd.
Rochester Hills, MI 48309-3555
Telephone: 248.852.3611
Fax: 248.852.9165
www.combustionresearch.com
Issue Date: 4/12/1997
COMBUSTION RESEARCH CORPORATION
Reflect-O-Ray
Oil fired, Low Intensity Infrared Vacuum
WARNING
Installer
Owner
Revision Date: 10/28/08
Oil Fired EDS 3.5
Vented Infrared Heating Systems
Installation, Operating, Maintenance
Rev. 9
and Parts Manual
TM
Bulletin RL3597102
®
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the reflect-o-ray eds 3.5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Combustion Research reflect-o-ray eds 3.5

Summary of Contents for Combustion Research reflect-o-ray eds 3.5
