Mediatrix 4100 Series Units in a Nortel MCS SIP
Environment
June 22, 2011
Proprietary
2011 Media5 Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mediatrix 4100 and is the answer not in the manual?

Questions and answers

Related Manuals for Media5 Mediatrix 4100

Summary of Contents for Media5 Mediatrix 4100

  • Page 1 Mediatrix 4100 Series Units in a Nortel MCS SIP Environment June 22, 2011 Proprietary 2011 Media5 Corporation...
  • Page 2 Configuration Notes 289 Table of Contents Introduction ................................... 3 Application Scenario ................................3 Running the Unit Manager Network Software ........................4 Configuring the Mediatrix FXS Unit ............................7 Page 2 of 9...

  • Page 3: Introduction

    Configuration Notes 289 Introduction This document outlines the configuration steps for deploying Mediatrix 4100 series FXS units, i.e., 4124 (24-ports), 4116 (16- ports), 4108 (8-ports), and 4104 (4-ports) in an SIP environment with the Nortel MCS. Application Scenario The following configuration notes are not a substitute for the Mediatrix Administration Documentation for Mediatrix analog products.

  • Page 4: Running The Unit Manager Network Software

    Configuration Notes 289 Running the Unit Manager Network Software The Unit Manager Network (UMN) software is a configuration and management tool for Mediatrix devices. The UMN can be https://support.mediatrix.com/DownloadPlus/Download.asp downloaded from the Mediatrix Support Portal: . It has a default 3-units limit upon installation. This will suffice for most configurations. It is recommended that the administrator uses the UMN to configure the Mediatrix devices.
  • Page 5 Configuration Notes 289 Note: The UMN runs in the Windows background. Mediatrix highly recommends that the administrator stops and restarts the UMN service whenever the IP address of the PC is changed. A restart may be needed depending on your Windows O/S. ...
  • Page 6 Configuration Notes 289 Page 6 of 9...

  • Page 7: Configuring The Mediatrix Fxs Unit

    Configuration Notes 289 Configuring the Mediatrix FXS Unit Step 1: Setting Basic Network Parameters  Once the Mediatrix unit has been auto-detected, it should appear under the Unit Manager level. Right-click the Administration level of the Mediatrix unit and select the Edit menu. ...
  • Page 8 Configuration Notes 289 Step 2: Setting up SIP configuration  Select the page and set the following: Uncheck DHCP. Set the SIP Registrar field and the SIP Proxy field to the domain name of the MCS server. Click in the User Name field next to the port number and type the telephone, fax, or extension number of the Mediatrix 41xx port.
  • Page 9 Configuration Notes 289 Step 4: Set the Outbound Proxy  On the top menu bar, check the Automatic GET option.  Go to iso>org>dod>internet>private>enterprises> mediatrix>mediatrixConfig > ipAddressConfig> ipAddressConfigSipServer > ipAddressConfigSipServerStatic> sipOutboundProxyStaticHost and set this parameter to the PROXY address of the MCS Server. Step 5: Restart the unit Once the unit is in service, you are ready to make voice and fax calls across the VoIP network.
