SPECIFICATION

MODEL: Professional DUAL USB with 9 Effects
(Compatible with USB mass storage device 1.0/1.1/2.0)
DIMENSIONS: 482(W) x 132(D) x 71.6(H) mm
POWER SOURCE: DC 6V, 3A
GENERAL:
Display LCD
Pitch control range within +/-6%, +/-12%, +/-25%
Pitch Bend +/-6%, +/-12%, +/-25%
Pitch accuracy +/-0.15%
AUDIO CHARACTERISTICS
(TEST SIGNAL FORMAT: MP3, 128K bps, load=100K ohm)
ITEM
(1) OUTPUT LEVEL
(2) CHANNEL BALANCE:
(3) FREGUENCY
RESPONSE
(4) CHANNEL
SEPARATION(*2)
(5) THD+N (*1):
(6) S/N (*2):
NOTES：
1. With 20KHz LOW PASS FILTER
2. With 20KHz LOW PASS FILTER, "IHF-A" WEIGHTED
MP3 FORMAT
Applicable file extensions
Disc format
Max. number of Folders
Max number of files
MPEG 1 Layer 3 standard (ISO/IEC
11172-3), which provides for single
channel ('mono') and two – channel
('stereo') coding at sampling rates of
32, 44. 1 and 48khz
MP3
MPEG 2
Format
ISO/IEC13818-3), which provides for
similar coding at sampling rates of 16,
22.05 and 24 kHz.
MPEG 2.5 layer 3 standard, which
provides for similar coding at sampling
rates of 8, 11.025 and 12 kHz.
Electric products must not be put into household waste. Please bring them to a recycling centre. Ask your local authorities or your dealer
about the way to proceed.
The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can be changed without prior
notice.
LIMIT
TYPICAL
1.4V +/-0.5dB 1.4V +/-1dB
WITHIN 0.2dB WITHIN 1dB
17-16KHz +/- 17-16KHz
0.3dB +/-1dB
92dB 85dB
0.0065% 0.01%
92dB 85dB
mp3 MP3 mP3 Mp3
999
max. 999 files
32/40/48/56/80/96/112/128/160/192/
224/256/320kbps
Xing/VBRI VBR
layer 3 standard(
32/40/48/56/64/80/96/112/144/160
Kbps
32/40/48/56/64/80/96/112/144/160
Kbps
CONDITION
1KHz, 0dB (TCD-782
TRK.2)
1KHz, 0dB(TCD-782 TRK.2)
0dB (TCD-781 TRK.1,4&16)
1KHz 0dB(TCD-782 TRK.9,
11)
1KHz 0dB(TCD-782 TRK.2)
1KHz 0dB(TCD-782
TRK.2&8)
