Pionetics LINX 140T Owner's Manual

Residential drinking water system with linx technology
Hide thumbs

Advertisement

Quick Links

Download this manual
®
LINX
140T
Residential Drinking Water System
with LINX Technology
®
and Dial-a-Taste
Mineral Level Control
(Software 20.067)
Owner's Manual
Tank and faucet sold separately.
For service related questions call (866) 611-8624 between 8:00 am and 4:30 pm (Pacific time). If you have
problems at other times, then turn off the feed water and unplug the system. The tank should hold enough
water to meet your needs until you can reach technical support.
1
Consumer Install 12.16.2016

Advertisement

loading
Need help?

Need help?

Do you have a question about the LINX 140T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pionetics LINX 140T

Summary of Contents for Pionetics LINX 140T

  • Page 1 ® LINX 140T Residential Drinking Water System with LINX Technology ® and Dial-a-Taste Mineral Level Control (Software 20.067) Owner’s Manual Tank and faucet sold separately. For service related questions call (866) 611-8624 between 8:00 am and 4:30 pm (Pacific time). If you have problems at other times, then turn off the feed water and unplug the system.
  • Page 2 Table of Contents Section 1 Safety Precautions Section 2 Overview of the LINX 140T System System Features Specification Section 3 Installation Section 4 Operation Selecting Feed Water TDS Level Pre-Conditioning Procedure System Operation ® Dial-A-Taste Mineral Level Control Indicator Lights...
  • Page 3  Read and follow all instructions carefully before using the LINX 140T Drinking Water System.  DO NOT open the cell lids or outer enclosure when the LINX 140T system is powered. There is a risk of electrical shock. ...
  • Page 4 *TDS reduction was tested and verified at an independent laboratory: Pace Analytical Services, Inc. **Based on extensive testing by the manufacturer. The LINX 140 and LINX 140T Drinking Water Systems conform to NSF/ANSI 53 for nitrate/nitrite reduction as verified and substantiated by test data. Consumer Install 12.16.2016...
  • Page 5 Section 3. Installation Under the Sink For video instructions, please go to http://linxdrinkingwater.com/installation/ First locate where you want the faucet at your sink. Your sink may come with a pre-drilled hole for a soap dispenser or spray hose. You can use that for the faucet. If not determine which side of the sink you want the faucet located and drill a hole as indicated by the size of the faucet mechanism that will go thru the hole.
  • Page 6 6. Then locate the cold-water supply line, the “P” Trap in the drain and the electrical outlet. 7. Determine the size of your cold-water supply and have the right sized T-Fitting (or Angle Stop) available – it will be either a 1/4, 3/8 or 1/2 inch outside diameter with a 1/4 inch “T” for the tubing that supplies the water to the LINX system.
  • Page 7 In preparation, be certain that you have the following:   A storage tank Heavy duty scissors   A faucet (available through Pionetics or at your local Teflon plumber’s tape  hardware store) Vaseline   An air gap if the faucet doesn’t include one Plumber’s Tape...
  • Page 8 This diagram illustrates plumbing connections using a dishwasher air gap. Feed water is provided from the cold water supply under the sink via an Angle Stop on the cold water valve. Do not use a saddle valve with puncturing needle because it will not provide sufficient flow.
  • Page 9 1. Locate the Angle Stop/Shut Off Valve on the cold-water line and close it 2. Open the cold water faucet at the sink to be certain that the water is off and to relieve pressure in the line 3. Unscrew the water line to the faucet above the Angle Stop/Shut Off Valve   4.
  • Page 10 1. Unpack the LINX unit and be certain that all the items listed on the enclosed Inventory are there. Also, refer to the online “How to Install the LINX 140T” at www.LINXDrinkingWater.com/install. 2. Locate where you want the faucet and install it according to the directions provided. (If you have a granite counter top you may want to hire someone to drill the hole for you.)
  • Page 11 NOTE: After removing the front blue panel and the two blue lid covers, the lid drivers and the two front panel black buttons are now visible. These parts will be addressed later. (See Figure 4 to identify these parts and location.) Figure 4 6.
  • Page 12 9. Insert the filter housings with the filters placed into their appropriate place in the manifold (they are labeled). There is a place for an optional ultra violet light (UV) which should remain empty. Be sure that the threads are aligned so that you get a good seal.
  • Page 13 12. Connect the tubing to the plumbing connections as seen from the back of the LINX 140T system by first removing the “plugs” included for shipping. Then push the tubing into the color-coded collets as far as possible. You should not be...
  • Page 14 Selecting Feed Water TDS Level During installation the LINX 140T system must be configured for low or high feed water TDS using the front panel buttons. Determine your feed water TDS (refer to your water utility annual report) to determine if it is less than or greater than 400 ppm (low or high).
  • Page 15 LINX TDS cartridges, remove the front panel, then press and hold both buttons on the front display. NOTE: On new LINX 140T systems, even if the lights continue to flash back-and-forth after 90 seconds, still press and hold both buttons to assure pre-conditioning has started.

  • Page 16: System Operation

    Whenever installing or replacing the LINX TDS cartridges and sediment/carbon filters, carefully check for leaks from inadequate o-ring seals. At the end of service, remove the top two lid covers and check for water in the lid driver crevices, and examine the filter housing for slow leaks.
  • Page 17 The tank must be emptied and refilled to observe the change. Section 5. Maintenance 5.1 Replacement of LINX TDS Cartridges, Sediment and Carbon Filters The LINX 140T systems include three types of replaceable components:  Two LINX TDS cartridges – under the blue lids ...
  • Page 18 LEAKS Two sensors mounted on the base of the LINX 140T systems detect water leaks. A light indicator and beeper indicate this external leak alarm, and the feed valves immediately close, shutting off water to the majority of the LINX system. Because the feed valves are located after the sediment filter and first flow sensor, a leak from these components will not be stopped.
  • Page 19  Confirm that each housing has an o-ring, whether they need to be replaced (any deformity or defects?), and that they have silicon or Vaseline. Tighten each housing using the filter housing wrench.  Reconnect pressure to the feed water line and reconnect power to the LINX system. Draw water until the dark carbon fines are no longer observed or a total of 5 gallons (Be sure the tank valve is closed during this process to avoid carbon fines collecting in your tank).
  • Page 20  Re-pressurize with feed water and connect power to the LINX system. A,B or C,D lights will flash three times to indicate whether the system is programmed for low or high TDS, then all four lights will flash right-left-right for 90 seconds during which time water will flow from feed to drain to fill the LINX cells.
  • Page 21  LINX Sediment filter, LINX Carbon filter, or LINX TDS cartridges have surpassed Red or Blue light Continuously on their usage volume limits Remedy – Call Pionetics to purchase replacement cartridges and/or filters  LINX Carbon filter missing or exhausted. Objectionable Taste or Odor Remedy –...
  • Page 22 07-000610 Power cord 19-000006 Isolation Drain Valve Retrofit Kit 07-050055 LINX 140T Drinking Water Systems are manufactured by: Pionetics Corporation 151 Old County Road, Suite H San Carlos, CA 94070 USA 866-611-8624 Business Hours. : M-F 8:00 AM to 4:30 PM (PT)
  • Page 23 Consumer Install 12.16.2016...
