Summary of Contents for Otto Bock Hubfix II
- Page 1 Hubfix II Bedienungsanleitung...........1 Instruction for use ............12 © Otto Bock HealthCare · 647G154 – 08.03/2 – Printed in Germany...
-
Page 2: Table Of Contents
Instructions for use for the Hubfix II Contents Page 1 Important..............................13 2 Intended use............................... 13 3 Statement of conformity..........................13 4 Service and repairs ........................... 13 5 Safety advisory............................14 6 Technical terms ............................15 7 Unpacking and preparing for use ....................... 15 8 Attaching the mountings for the Robby and size 2 Flipper bathing seats ............. -
Page 3: Important
The HUBFIX bath lift has been designed as a lifting platform for bathing seats. It allows you to quickly and easily lift people into and out of the bathtub. Otto Bock recommends using its Robby and Flipper bathing and care seats. Even agitated children can be tended to without unnecessary back strain, first in the bath lift's upper position at bathtub rim level (straps may be needed), and then lowered to the bottom of the tub. -
Page 4: Safety Advisory
5 Safety advisory Please read the Owner's Manual first. Make sure you are familiar with the device and how to operate it before you first place it in a bathtub. The HUBFIX bath lift must never be operated by the person on the platform. The HUBFIX bath lift must be used indoors and only in a bathtub. -
Page 5: Technical Terms
6 Technical terms Figure 1 Figure 2 Main cover panel Movable panels Cover (A, B, C) Release knob Lifting mechanism Wings: (C) The wings are fixed to the left and right sides of the main cover panel and prevent accidental contact with the folding mechanism. -
Page 6: Attaching The Mountings For The Size 1 Flipper Bathing Seat
Figure 5 Figure 6 Attach the clamps to the movable panels from below using the four equal length screws and the washers Figure 5). The clamps should then be arranged on the cover as in this illustration (Figure 6). 9 Attaching the mountings for the size 1 Flipper bathing seat Figure 7 Figure 8 Attach the clamps in the same way as in the section 'Attaching the mountings for the Robby and size 2 Flipper... - Page 7 The bath lift's 'foot end' should be towards the tub's foot end if it is a standard bathtub. Make sure that the 'wings' point upwards and that the distances to the long sides of the bathtub are reasonably even (Figure 10). Figure 11 Figure 12 Undo the countersunk screws in the main cover panel and pull the movable panels far enough apart so the...
-
Page 8: Changing The Position Of The Release Knob (Authorized Dealer Only)
HUBFIX bath lift, near the bath drain (on a standard bathtub). If this is not the case then it can be repositioned by an Otto Bock authorized technician. To move the release knob from one side to the other, use... -
Page 9: Everyday Use
Everyday use 12 Putting it into the bathtub Figure 21 Figure 22 Take hold of the HUBFIX bath lift on the left and right side of the middle of the main cover panel and carefully place the bath lift in the tub (Figure 21). The 'foot end' of the bath lift should point towards the foot end of the tub (on a standard bathtub). -
Page 10: Raising And Lowering
Figure 25 Figure 26 To remove the bathing seat repeat the above steps in reverse order. Robby bathing seat: Keep the release buttons on the locking joints pressed in as you pull it out (Figure 25). Flipper bathing seat: First fold the Flipper bathing seat's head section completely forward. As you pull it out, fold the rear frame inwards (Figure 26). -
Page 11: Removing It From The Bathtub
Figure 29 Figure 30 When lowering the Hubfix you can alternatively use your palm to hold the release knob and press the release button (Figure 29). Lifting: Put the fingers of one hand around the release knob. (Figure 30). Hold onto the frame of the firmly attached bathing seat with the other hand. Press the release button with your thumb and pull the bathing seat up assisted by the hydraulic spring. -
Page 12: Servicing And Care
If they are worn (and offer insufficient grip) please change them immediately. 17 Guarantee terms & conditions The Otto Bock Warranty applies only when the product is used according to the specified conditions and for the intended purposes, following all manufacturer's recommendations (please also see our general terms of sale, supply and payment). - Page 13 Otto Bock HealthCare GmbH Sälzerstraße 16 · D-56235 Ransbach-Baumbach Otto Bock HealthCare GmbH has been certified by the German Society for the Certification of Quality Assurance Systems (DQS) in accordance with DIN EN ISO 9001 standard, reg. no. 779 (management system)
