Page 1: Table Of Contents
– Composer Pro Configuration, page 15 – Power and Battery Management, page 15 • Battery Instructions, page 15 • Power Off the Device, page 16 – Americas Headquarters: Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA...
Page 2 Cleaning the Touchscreen and Docking Station, page 16 • Troubleshooting, page 16 • Specifications, page 18 • Regulatory/Safety Information, page 19 • Related Documentation, page 19 • Warranty, page 20 • Service and Support, page 21 • Cisco Smart+Connected Portable Tablet Reference Guide OL-27364-01...
Page 3: Overview
Since the Cisco Portable Tablet supports Wi-Fi networking, it can be carried throughout the residence for convenient access to the Cisco Smart+Connected Residential features and services. The included docking station has a built-in Ethernet connection that supports Power over Ethernet (PoE), allowing the device to receive power directly from the Ethernet cable while eliminating the need for a separate power connection.
Page 4: Package Contents
Before you begin to install this Cisco Portable Tablet, you’ll need to make a few decisions: Will the Cisco Portable Tablet be used as a portable device (docking station not attached) or with the docking station attached? See “Portable or Tabletop Installation Options” and “Power Management Best Practices”...
Page 5 If the battery power is critically low, you can still turn on the device as long as the docking station • is plugged into the power adapter or a Power over Ethernet (PoE) switch. Cisco Smart+Connected Portable Tablet Reference Guide OL-27364-01...
Page 6: Device Illustrations And Descriptions
Camera. Used for video intercom with another compatible device in another room. Programmable Buttons (4). Used to program various automation activities in Composer Pro programming. Power Button. Used to power the Cisco Portable Tablet on or off. See the “Understanding the Touchscreen Modes” section on page Touchscreen.
Page 7: Top View
Camera LED Indicator. Indicates if the camera is on. Green indicates the camera is on. Power LED Indicator. Indicates if the power is on. 10 Microphones. Used to speak into the Cisco Portable Tablet when the intercom is used. Top View...
Page 8: Right Side View
Device Illustrations and Descriptions Right Side View Figure 1-5 Right Side View Back View Figure 1-6 Back View Cisco Smart+Connected Portable Tablet Reference Guide OL-27364-01...
Page 9: Portable Or Tabletop Installation Options
(2) included screws. Using the Cisco Portable Tablet as a Portable Device Note You must set up for Wi-Fi if the Cisco Portable Tablet will be used as a portable device. See “Configure the Network Settings.” Procedure Place the docking station on a flat surface.
Page 10: Using The Cisco Portable Tablet As A Tabletop Device
1-7). Plug the power cord into a wall outlet. To use Ethernet, plug the RJ-45 connector into the PoE connector (such as a Cisco SF302-08P Switch) and then into the Ethernet jack on the back of the docking station (see Figure 1-7).
Page 11 Portable or Tabletop Installation Options You can attach the Cisco Portable Tablet to the docking station using the screws provided to prevent the Step 3 Cisco Portable Tablet from becoming disconnected and nonfunctional every time it is removed from the docking station.
Page 12: Understanding The Touchscreen Modes
To configure the network settings for this device: Step 1 If using a wireless network, ensure that the Wi-Fi WAP is on the same network as the Cisco Controller in the system. Gather the following wireless network information from your WAP: Step 2 •...
Page 13 Select each field and use the keyboard to enter the IP Address, Subnet Mask, Default Gateway and DNS server(s). Tap Done when each field is complete. Tap OK to return to the Network page. You can now connect to a Director (a Cisco Controller running on the network). Cisco Smart+Connected Portable Tablet Reference Guide OL-27364-01...
Page 14: Connect To Director From The Cisco Portable Tablet
Note If the subsystem buttons are not lit, and no default room displays on the touchscreen, you are not connected to a Cisco Controller. Ensure that the devices are added to Composer Pro and identified in the project. See the “Composer Pro Configuration”...
Page 15: Composer Pro Configuration
In the IP Network Connections list (center pane), highlight Portable 7” Touch Screen V2, and then click Identify. When prompted, go to the Cisco Portable Tablet and press the bottom button on the right side, as indicated on the Identify screen in Composer Pro, to identify the device to the network.
Page 16: Power Off The Device
Cleaning the Touchscreen and Docking Station Power Off the Device To power off the Cisco Portable Tablet, press and hold the Power button for at least five (5) seconds, and then wait a few more seconds for the device to turn off.
Page 17 Make sure you’ve provided the required network configuration information described in the • “Configure the Network Settings” section on page Ensure that the same key is being used on the Cisco Portable Tablet and at the wireless access point • (WAP).
Page 18: Specifications
Power over Ethernet IEEE802.3af AC 100V-to 240V, 50~60Hz Power over Ethernet (PoE) Battery Suspend Mode 20 hours Typical Use 12 hours (default setting) Charge Time 6 hours Other Audio G.722 Wideband Audio Environmental Cisco Smart+Connected Portable Tablet Reference Guide OL-27364-01...
Page 19: Regulatory/Safety Information
Regulatory/Safety Information To review regulatory information, go to www.cisco.com/go/smartconnectedresidential/docs. Related Documentation For more information about the Cisco Smart+Connected Residential products, go to the following URLs: For more information about the Cisco Smart+Connected Residential products, see the following documents and websites:...
Page 20: Warranty
Composer Pro User Guide http://www.control4.com/documentation/Com poser_Pro_User_Guide/index.htm For information about third-party hardware and software, see the manufacturer’s product documentation Note and/or website. Warranty A Cisco 1-year warranty applies. Go to the following URL for more information: www.cisco.com/go/smartconnectedresidentialwarranty Cisco Smart+Connected Portable Tablet Reference Guide OL-27364-01...
Page 21: Service And Support
Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other countries. A listing of Cisco's trademarks can be found at www.cisco.com/go/trademarks. Third party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company.
Page 22 Service and Support Cisco Smart+Connected Portable Tablet Reference Guide OL-27364-01...
