- Page 1 Integrated Fridge Freezer FF250IHE Instruction Manual...
-
Page 2: Safety Information
Important: Please read these instructions thoroughly before using your appliance. Keep them in a safe place for future reference. SAFETY INFORMATION x This integrated fridge freezer is intended for normal household use. x The appliance is designed for indoor use only. x Wait at least 2 hours before first powering up the appliance to allow the cooling system to settle after transportation. -
Page 3: Prior To Installation
x Warning! The light bulb supplied with this appliance is a “special use bulb” which is usable only with this appliance. It must not be used for domestic lighting. x Warning! Do not touch the light bulb, if it has been on for a long period, as it will be hot. -
Page 4: Reversing The Door Opening
REVERSING THE DOOR OPENING The appliance is delivered with the doors opening from the left hand side. To change the opening direction, please follow these instructions. Note: Ensure that the appliance is unplugged and empty before reversing the doors. 1. Unscrew the top hinge and then lift off the upper door and place it on a padded surface to avoid scratching it. - Page 5 3. Remove the bottom hinge pin from the right hand side and transfer it to the left. 4. Re-position the lower door onto the bottom hinge pin and locate the middle hinge pin into the top of the lower door. 5.
-
Page 6: Installation
INSTALLATION 1. Slowly and carefully slide the appliance into the kitchen cabinet. Ensure that the opening side is as close to the cabinet wall as possible. 2. Screw a guide to the side of the appliance door, using 2 short screws. Insert a slider into the guide then fully open and close the appliance and cabinet doors together to check that the... - Page 7 7. Double check that the doors can close and open smoothly and that the appliance is sealed well. If not, slightly adjust the unit. Fix the bottom bracket to the kitchen cabinet with 2 long screws. 8. Fix the top bracket to the kitchen cabinet with short screws.
-
Page 8: Operation
OPERATION BEFORE USING YOUR FRIDGE FREEZER 1. Ensure that the appliance has been installed as recommended and that it is level. 2. Clean the inside of the fridge and freezer compartments (see ‘Care and Maintenance’) 3. Ensure that the appliance has been left for a minimum of 2 hours before switching on the power, to allow the refrigeration system to stabilise. -
Page 9: Fridge Compartment
Temperature Setting 1. Press the Mode button to select the user’s setting (Smart and Super indicators off) 2. Press the Adjust button to select the set temperature for the fridge. The temperature of the freezer compartment is automatically controlled at around -18°C. -
Page 10: Freezer Compartment
Daily Use x Do not put hot food into the fridge. x Do not place food products directly against the rear wall. x Do not pack food close together as this prevents air circulating. x Do not set the fridge temperature lower than necessary. x Cover or wrap up the food, particularly if it has a strong flavour. -
Page 11: Technical Specifications
TECHNICAL SPECIFICATIONS FF250IHE Energy efficiency class Annual energy consumption (kWh/ annum) Storage Volume (fridge) (litres) Storage volume (4* freezer) (litres) Freezing capacity (kg/24h) Climate class SN, N, ST Airborne acoustical noise emissions (dB (A)) Installation Built-in CARE & MAINTENANCE Warning: Always unplug the appliance before cleaning or defrosting the freezer. - Page 12 Replacing the Lamp WARNING: Turn off the supply and unplug the appliance before replacing the lamp. 1. Turn off the mains supply and unplug the appliance. 2. Remove the screw from the lamp cover. 3. Remove the lamp cover. 4. Unscrew the lamp. 5.
-
Page 13: Customer Service
Power Failure x If the mains power should go off, avoid opening the doors so that the interior remains as cool as possible. x The food inside the freezer should remain frozen as long as the power is off for less than 24 hours. x If the power is due to be off for more than 24 hours then the frozen food should be quickly moved to another freezer. -
Page 14: Troubleshooting Guide
TROUBLESHOOTING GUIDE In the unlikely even of a problem with your fridge freezer, please consult the guide below before calling a Service Engineer. PROBLEM POSSIBLE CAUSE Appliance not plugged in or mains not switched on. Appliance does not operate The fuse or circuit breaker has operated. Appliance is turned off. -
Page 15: Disposal Information
DISPOSAL INFORMATION This appliance is marked according to the European Directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE). At end of life this product should be recycled and not disposed in household waste. Contact your retailer, council or local authority for further information. - Page 16 Supplied by Crosslee plc, Halifax, West Yorkshire, HX3 8DE CKWK-G01-B...
