- Page 1 E-112 : ASSEMBLY GUIDE Revision 3.0 - 06-02-2016...
-
Page 2: Table Of Contents
E-112 : Table of contents Assembly overview........2-3 1. -
Page 3: Assembly Overview
E-112 : Assembly overview 1. Frame inspection 2. Headset installation 3. Cable housing installation IMPORTANT NOTICE: It is easier to install the cables and cable housings before the bearings. 4. Seatpost installation 5. Saddle adjustment 6. Derailleur hanger adjustment... -
Page 4: Assembly Overview
E-112 : Assembly overview Images are for reference only. Proportions are not accurate. 7. Parts listing... -
Page 5: Frame Inspection
E-112 : 1. Frame inspection When assembling a new frame, be sure to check if the following parts are assembled correctly. Parts installed on the frame Description Screw Torque Detail type Front derailleur hanger Screw (2) Loctite Rear derailleur hanger... -
Page 6: Headset Installation
E-112 : 2. Headset installation Install the 3D headset (9) according to the pressfit assembly guide. You can choose from 3 different heights : 25mm, 15mm or 0mm. -
Page 7: Cable Housing Installation
E-112 : 3. Cable housing installation 1. Install the front and rear derailleur cable housing starting at the head tube. 2. Install the rear brake cable housing starting at the head tube. For the derailleur and brake housing, measure a sufficient length of housing to be able to turn the handlebar both ways correctly. -
Page 8: Cable Housing Installation
E-112 : 3. Cable housing installation Remove the cable guide and add a plastic cap on each cable housing (front and rear derailleur). Insert the plastic cap into the cable guide, then fix the guide to the frame with the M5 screw. -
Page 9: Seatpost Installation
E-112 : 4. Seatpost installation CARBON FIBER ASSEMBLY COMPOSITE 1. Make sure the clamp (4e) sits GREASE correctly on the seat tube. 2. Insert the seatpost (6) on which some carbon fiber assembly gel has been applied. 3. Position the seatpost at the desired... -
Page 10: Saddle Adjustment
E-112 : 5. Saddle adjustment 1. Install the saddle on the rocker (3f) and slightly tighten the rail clamp (3e) using a ball end hex key. 2. Tighten the upper screw of the rocker clamp (3a) by keeping a space of 2 to 3mm between the aluminum and carbon parts. -
Page 11: Saddle Adjustment
E-112 : 5. Saddle adjustment The 2waypost ASP-4000 can be flipped to achieve a triathlon or a road position (75°/78°). The seat clamp offset can be set by flipping the rail clamp (3d) and the rocker (3f). Road : -10mm to -15mm... -
Page 12: Derailleur Hanger Adjustment
E-112 : 6. Derailleur hanger adjustment The front derailleur hanger can be adjusted according to the front derailleur angle to obtain an equal curve between the derailleur and the big chain ring. Once at the right angle, use blue 242 Loctite and screw in at 6Nm. -
Page 13: Parts Listing
E-112 : 7. Parts listing Images are for reference only. Proportions are not accurate. - Page 14 E-112 : 7. Parts listing Name A18 SKU# Frameset Parts E-112 frame E-112 fork Seat post with the following parts assembled E-112 seat post (ASP-4000) • Upper HexSocket screw (M6*20mm S) for rocker clamp • Lower HexSocket screw (M6*20mm S) for rocker clamp •...
