Summary of Contents for Nextorch GT6A-RL
- Page 1 FLASHLIGHT OPERATOR’S MANUAL GT6A-RL...
- Page 3 Screw off the tailcap. Insert the battery correctly according to the anode and cathode indicated on the barrel. Screw the tailcap back to the barrel.
- Page 4 RUBBER TAILCAP LITHIUM BATTERY NT18650 1W LUXEON LED O-RING BARREL O-RING BRAINPAN POLYCARBONATE REFLECTOR FULL CLEAR GLASS LENS...
- Page 5 GT6A-RL F L A S H L I G H T F E AT U R E S Product Model GT6A-RL 1W LUXEON LED Bulb Max Output 35 Lumens NT18650 Lithium Battery Battery Material Durable Nylon Fibre Lens' Material Full Clear Glass Lens...
- Page 6 Press to switch ON and OFF Remove the head by rotating the barrel until it is free of the barrel.Put the replacing lamp assembly back to the barrel and repert the reverse steps to finish your lamp replacement.
- Page 7 Put the battery into slot of the charger with right polarity. Connect the battery slot with the plug. Insert the plug to the electrical socket .The indicator LED turns on when charging,it turns red to green when charging completed. Attention: It takes about 4 hours for charging a single NT18650.
-
Page 8: Maintenance
To keep your flashlight always in a perfect condition, follow the instructions as below. 1. Clean your flashlight with a soft clean cloth (NexTORCH offers you a professional lens cleaning tool (Item #LC6). Please check the accessories right after this instruction). - Page 9 NexTORCH LIFETIME WARRANTY NexTORCH guarantees that all products under NexTORCH brand are free from manufacture defects. NexTORCH will repair or replace any defective products,Please contact your local dealer or e-mail to info@nextorch.com. This warranty excludes the following: 1). Failure of product due to misuse and/or lack of maintenance.
- Page 10 A C CE S SOR I ES NexTORCH offers a full range of product accessories suited for your flashlight. NT18650 NT123A Rechargeable lithium battery Lithium battery V30F TIT12 LED upgrade assembly Attack head Attack head Infrared filter RM83 LT2113 Gun mount...
- Page 11 RF/BF/GF Red/Blue/Green filter lens Lens V1438 Car express charger Holster TS7-L TS7-S Long rat-tail switch Short rat-tail switch Silicone grease Lens cleaner V2844 PC176 Police cone Holster Gun mount...
- Page 12 索引 GT6A-RL电筒结构 ....13,14 GT6A-RL快速安装指引 ....15 GT6A-RL电筒具体参数 ....16 GT6A-RL使用方法...
- Page 13 GT6A-RL 电筒结构 按钮开关 NT18650可充电电池 防水圈 LUXEON 1W LED 筒身 防水圈 头盖 PC反光杯 镀膜增透玻璃镜片 GT6A-RL 装配图...
- Page 14 第一步：逆时针旋转拧开尾盖。 第二步：放入电池，注意正确放置正负极。 第三步：拧上尾盖。...
- Page 16 打开/关闭 按下橡胶尾盖直至听到“滴答”声响，以打开电筒，重复 以上动作，即关闭电筒。 灯头替换 手持筒身，逆时针方向旋转头盖，直到头盖离开筒身，取 出灯头并放入替换灯头，重复相反步骤，即可成功实现灯头替 换。...
- Page 17 如何充电 为了方便您正确对NT18650电池充电，请遵循以下顺序： 将电池放进充电器电池仓内。（请按照电池仓内正负 极标识正确放置电池） 用插头连接电池仓。 将充电器插脚端插口插入取电接口。充电时，红色充 电指示灯点亮。当指示灯从红色变为绿色，充电完成。 注：单节NT18650电池充电时间为4小时。...
- Page 18 感谢您选择了品质卓越的NexTORCH 系列电筒。由于电 筒在工作时会散发较大的热量。为了避免使您的电筒和物品 造成损失，使用时请注意以下事项： 1. 不要将光线直射入人的眼睛，较强的光线会对眼睛造成 永久性伤害。 2. 灯头不要经常拆解，以免造成反光杯或灯泡损伤。...
- Page 20 附件 为了满足您对电筒的不同需求，并使电筒得到全面 的维护，我们设计了一系列的配件。请根据您的个人需 要进行选择，如需详细了解附件参数请联系当地或登陆 我们的网站www.nextorch.com。 NT18650 NT123A 可充式锂电池 锂锰电池 V30F TIT12 LED灯头组 攻击头 攻击头 红外滤镜 RM83 LT2113 枪夹 电筒套 FT32 红绿蓝滤镜 红外滤镜镜片...
- Page 21 RF/BF/GF 镜片 红/蓝/绿光滤镜镜片 V1438 快速车载充电器 电筒套 TS7-L TS7-S 长鼠尾开关 短鼠尾开关 硅油 擦镜布 V2844 PC176 电筒套 导光棒 枪夹...
- Page 22 WWW.NEXTORCH.COM...
