- Page 1 Users Manual Intelligent Keyboard Controller Before attempting to connect or operate this product, Please read instructions cardfully and save this manual for future use. Copyright(c)2008...
- Page 2 PREFACE Specification of function: 1. It is compatible with all functions of HK’s DVR panel; 2. One Keyboard Controller control several embedded devices with video signal switch function and truly realize the function of digital video matrix. 3. Conveniently control high speed Dome and decoder, fill up the deficiency of the embedded devices.
- Page 3 EXPLAIN Users Manual Intelligent Keyboard Controller Caution: ◇ Please connect t h e k e y b o ard controller corre c t l y a s t h i s m a n u a l requires. ◇ L C D d i s p l a y c a n b e e a s i l y d a m a g e d . P l e a s e d o n ’ t p r e s s o r e x p o s u r e i n s u n s h i n e f o r a l o n g t i m e .
-
Page 4: Table Of Contents
CONTENTS Users Manual Intelligent Keyboard Controller CONTENTS 1. Introduction of front/rear panel ......3 1.1 Front panel function buttons introduction . -
Page 5: Introduction Of Front/Rear Panel
INTRODUCTION Users Manual Intelligent Keyboard Controller 1.1Front panel function button introduction T h e r e a r e 3 1 p c s b u t t o n s , 1 p c L C D d i s p l a y a n d 1 p c j o y s t i c k d i s t r i b u t i n g i n I n t e l l i g e n t Ke y b o a r d C o n t r o l l e r f r o n t p a n e l . - Page 6 INTRODUCTION Users Manual Intelligent Keyboard Controller 【Addr】 Select the address of decoder, high speed dome and DVR. PTZ address code is among 0-254 and DVR address code is among 1-14. 【Clear】 Clean current input content. 【0-9】 Number button:0,1,2,3,4,5,6,7,8,9. 【Enter】 Confirm current input content 【Focus+/A】...
-
Page 7: Lcd Screen
INTRODUCTION Users Manual Intelligent Keyboard Controller 1.1.2 LCD screen All operation through buttons will be displayed on LCD correspondingly, LCD will switch to power-save mode if the keyboard doesn’t receive any input for more than 30 seconds.(switch to lowest brightness). 1.1.3 Status indicator light ［P W Power indicator light. -
Page 8: Rear Panel Interface Terminal Introduction
INTRODUCTION Users Manual Intelligent Keyboard Controller 1.2 Rear panel interface terminal introduction 25PIN ports, 1 DC-12V port, 3 LED indicator Shown in the following diagram: Number Function introduction Description Item Mark Interface Control high Connect to RS485 port of speed dome and decoder: speed PTZ PTZ-CON Ta to RS485+,Tb to RS485-... -
Page 9: Operation Introduction
OPERATION Users Manual Intelligent Keyboard Controller 2.1 PTZ Control Operation introduction 2.1.1 Select PTZ operation mode LCD display as right figure 1,means keyboard is in PTZ operation mode, if shown as right figure 2, means keyboard is in DVR operation mode, ... -
Page 10: Set Ptz Preset Position
OPERATION Users Manual Intelligent Keyboard Controller (previous page) 2.1.3 Joystick and Keyboard control PTZ <<<<<< Left <<<<<< Down <<<<<< Right <<<<<< figure 1 figure 2 figure 3 figure 4 Rtz: focus-near Ptz: focus-far Ptz: zoom-wide figure 5 figure 6 figure 7 Ptz: zoom-tele Ptz:... -
Page 11: Dvr Operation Introduction
OPERATION Users Manual Intelligent Keyboard Controller 2.2 DVR operation introduction 2.2.1 Select DVR operation mode LCD display as the following figure 1, which indicate that intelligent Keyboard controller is in DVR mode; If LCD display as the following ... -
Page 12: Query For Keyboard Parameter
OPERATION Users Manual Intelligent Keyboard Controller Edit DVR inputting content, LCD display as right figure 12 【EDIT】 Select DVR’s PTZ control function, LCD display as right figure 13 【PTZ】 【FOCUS+】,【FOCUS-】,【ZOOM+】, 【ZOOM-】,【IRIS+】,【IRIS-】 , 【WIPER】and【LIGHT】have relevant control function under this condition. Please press 〔Esc〕and exit DVR’s PTZ control mode. DVR setting menu appear, LCD will display as right figure 14 【MENU】... -
Page 13: Installation Introduction
CONNECTION DIAGRAM Users Manual Intelligent Keyboard Controller 3.1 Intelligent Keyboard controller control DVR Auxiliary keyboard No.7 pin Ra of the main-keyboard No.8 pin Rb of the main-keyboard connect to No.9 pin Ta of the Sub-keyboard connect to No.10 pin Tb of the Sub-keyboard. host keyboard DVR KB D + No.9 pin Tb of the DVR KB D - No.10 pin Tb of the... -
Page 14: Keyboard Controller Control Ptz
CONNECTION DIAGRAM Users Manual Intelligent Keyboard Controller 3.2 Intelligent Keyboard controller control PTZ Auxiliary keyboard No.3 pin Ra of the main-keyboard No.4 pin Rb of the main-keyboard connect to No.1 pin Ta of the Sub-keyboard connect to No.2 pin Tb of the Sub-keyboard. host keyboard RS485A(or RX+) of speed dome RS485B(or RX-) of speed dome... -
Page 15: Dvr And Keyboard Controller Connection And Setup
DVR AND KB CONNECTION AND SETTING Users Manual Intelligent Keyboard Controller Operation procedure: DVR’s Device number should be same as KB’s DVR address when KB need to control DVR. The procedure of DVR device number setting is as following: 1.Enter primar y menu- Local show-Device number ; 2.Change device number into the number needed;... -
Page 16: Other Function Setup
OTHER FUNCTION SETUP Users Manual Intelligent Keyboard Controller 5.1 Password setup Get into KB setup mode, move joystick to page down the LCD display information to show as right figure 1,press【Enter】it will show as right figure 2, press【Enter】again,it show as right figure 3,key in ... -
Page 17: Keyboard Controller Id Setup
OTHER FUNCTION SETUP Users Manual Intelligent Keyboard Controller 5.5 Keyboard ID setup Get into setup mode, move joystick to make the LCD to display as show on right figure 1. Press【Enter】, it will show as right figure 2, move ... - Page 18 Keyboard controller 006.08.09-4101...
