ESTEAM CLEANING SYSTEMS
500 MODELS
OWNER'S MANUAL
Congratulations on your selection of a new E1050 soil extractor built in
Canada by "Esteam Cleaning Systems." Our goal has been to produce the
best high performance line of carpet cleaning equipment on the market
today. Reading your owners manual will help to achieve maximum benefit
from your purchase.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E1050 and is the answer not in the manual?

Questions and answers

Related Manuals for Esteam Cleaning Systems E1050

Summary of Contents for Esteam Cleaning Systems E1050

  • Page 1 ESTEAM CLEANING SYSTEMS 500 MODELS OWNER’S MANUAL Congratulations on your selection of a new E1050 soil extractor built in Canada by “Esteam Cleaning Systems.” Our goal has been to produce the best high performance line of carpet cleaning equipment on the market today.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Page No. Introduction on the E1050 Specifications Maintenance Safety Information Operating Instructions Trouble Shooting Schematic Warranty Registration Warranty...

  • Page 3: Introduction On The E1050

    The E1050 incorporates a unique single 3 stage vacuum producing 150 inches of water lift or 185 inches of water lift with optional dual 3 stage vacuum. To compliment the vacuum lift the E1050 comes standard with a 500 PSI PumpTec pump. No cleaning job is too large for the E1050.

  • Page 4: Maintenance

    MAINTENANCE DAILY: Clean high water level float screen inside the recovery tank. Ensure high level float ball is working properly. Rinse out recovery tank after use. Clean dirt and obstructions from the (recovery tank) drain valve rubber gaskets to prevent premature wear. Rinse out pump with clean water at conclusion of work day.

  • Page 5: Operating Instructions

    TO USE YOUR E1050 HEATER: A. Hook the wand solution hose to the quick connect of your machine. B. Plug the heater power cord into a wall that is on a separate circuit form the other cord.
  • Page 6 OPERATING INSTRUCTIONS (CONTINUED) WARNING: If your heater does not work DO NOT attempt to repair it yourself, call your distributor for repair procedures. Using solvents in heaters can be hazardous and will void your warranty. Allowing heaters to freeze will crack the heater cartridge and will also void your warranty.

  • Page 8: Trouble Shooting

    TROUBLE SHOOTING WARNING: Prior to inspection or repair of this machine, disconnect all electrical cords rendering the machine powerless. Failure to do so could result in serious or fatal injury. PROBLEM CAUSE SOLUTION 1. Entire unit will not 1. Unit not plugged in 1.
  • Page 9 TROUBLE SHOOTING (CONTINUED) PROBLEM CAUSE SOLUTION 5. 500 PSI Plunger 1. Pressure regulator valve 1. Adjust pressure using pump runs but has out of adjustment regulator located at the loss of pressure front of the machine 2. Partial kink in solution hose 2.
  • Page 10 TROUBLE SHOOTING (CONTINUED) PROBLEM CAUSE SOLUTION 8. Machine spits water 1. High level float not working 1. Check auto shut off float out of exhaust port properly cage and ball for proper operation 9. Machine blowing 1. Damaged (leaking) recov- 1.

  • Page 11: Schematic

    E1050 ( P. 1 )
  • Page 12 E1050 ( P. 2 )
  • Page 13 E1050...
  • Page 14 NOTES: 305-230 Switch, Rocker 20 Amp 315-015 Cord, 25' Black 14/3 SJTW-A 315-040 Cord, Fan - Muffin 333-010 Fan, Muffin 6"- 110V E1050-05 333-015 Fan, Muffin 6"- 220V E1050-20-05 335-005 Strain Relief, 12 Gauge 340-155 Circuit Breaker, 5 Amp 350-005...
  • Page 15 485-000 Copper 3/8" 495-021C Rec Tank & Lid 495-035 Base 495-040 Sol Tank 512-542 Pump 500 PSI & M110 Motor E1050 512-545 Pump 500 PSI 512-551 Motor Model M110 (110V) E1050 512-552 Motor Model M110 (220V) E1050-20 530-025 Regulator, MV500 545-100 Dump Valve, 1 1/2"...
  • Page 16 E1050 2-3 STAGE VAC...
  • Page 17 E1050 2-3 STAGE VAC PART NO. DESCRIPTION NOTES: 305-230 Switch, Rocker 20 Amp 315-015 Cord, 25' Black 14/3 SJTW-A 315-040 Cord, Fan - Muffin 333-010 Fan, Muffin 6"- 110V E1050-05 333-015 Fan, Muffin 6"- 220V E1050-20-05 335-005 Strain Relief, 12 Gauge...
  • Page 18 Gasket, 1/8 x 1" 485-000 Copper 3/8" 495-021C Rec Tank & Lid 495-035 Base 495-040 Sol Tank 512-542 Pump, 500 PSI & M110 Motor (110v) E1050-05 512-545 Pump, 500 PSI 512-551 Motor Model M110(110v) E1050-05 512-552 Motor Model M110(220v) E1050-20-05 530-025 Regulator, MV500 545-100 Dump Valve, 1 1/2"...
  • Page 19 597-010 Float Screen Cage 597-061 Adpt (RM) 30 Degree 845-010 Baffle, S/S 845-030 Switch Plate 845-040 Solution Tank Cover...
  • Page 20 E1050 HEATER MATE...
  • Page 21 E1050 H.M (P. 1) PART NO. DESCRIPTION NOTES: 263-013 H.P Hose 28” 305-210 Switch, Toggle 110v/220v 305-225 Switch Plate ON/OFF 305-230 Switch, Rocker 20 Amp 315-015 Cord, 25' Black 14/3 SJTW-A 315-040 Cord, Fan - Muffin 320-110 Lamp, Panel 110v...
  • Page 22 E1050 H.M (P. 2) 425-005 Clamp, # 6 Hose 1/2 x 1 425-130 Clamp Tube 3” 435-015 Handle, Brass/Chrome 440-006 S.S. Hinge 2" x 2" 445-015 Latch, Machine 445-020 Latch, Striker 455-075 Caster, 4" Swivel 455-052 Wheel Cap Dome 455-057 Wheel, 8"...
  • Page 23 E1050 H.M (P. 3) 555-634 Tee,1/4 FPT. 555-636 Tee, 1/4" Street Extruded 560-030 Screen, Acorn 560-116 Strainer, Inline Barred 1/2" 560-330 Guard, Finger, 6" Muffin Fan 572-125 Pulse Hose, 3/8" 572-155 Polyspring Hose, 1/2" 580-010 Q.C. 1/4" Fem (Closed) 581-055 Crimp Ftng, 3/8"...
  • Page 24 PUMP 500 PARTS LIST...
  • Page 25 INTERNAL HEATER MATE...
  • Page 26 INTERNAL HEATER MATE (490-005/490-006) PART NO. DESCRIPTION NOTES: 305-245 Thermo Cut-Out 305-265 Thermostat 200F 318-005 Heater Element 1850W 110V Use For 490-005 318-900 Heater Element 1850W 220V Use For 490-006 325-005 Connector, Butt - Blue 325-120 Spade, 3/16 F - Blue 325-230 Terminal Ring, #10 - Blue 325-500...
  • Page 27 E1050 WIRING...
  • Page 28 E1050 2-3 STAGE VAC WIRING...
  • Page 29 E1050 HEATER MATE WIRING P. 1...
  • Page 30 E1050 HEATER MATE WIRING P. 2...

  • Page 32: Warranty

    ESTEAM® CLEANING SYSTEMS E-Series Extractor Warranty E1700, E1000, E600, E250 NOTICE: REVIEW THIS WARRANTY CAREFULLY AS THIS DOCUMENT CONTAINS LIMITATIONS AND EXCLUSIONS. PART I: Esteam Manufacturing Ltd. (hereinafter referred to as "Esteam") warrants each new E- Series Extractor, subject to the limitations as defined in the specific details of its warranty coverage defined below.
  • Page 33 PART II - REPLACEMENT PARTS (UNDER WARRANTY) Replacement warranty parts will be genuine Esteam parts, or parts of similar kind and quality. All replacement warranty parts are warranted to be free from defects in materials or workmanship from the date of the original unit purchase for the balance of the original warranty period namely: 90 days, 12 months, or the Lifetime, whichever is applicable;...
  • Page 34 (vi) No warranty is provided as to any extra expenses incurred by the customer, including but not limited to economic, incidental, consequential loss or damage (e.g. all labour charges, rental equipment, down time, lodging, commercial or business loss of any nature or kind due to product failure); whether direct or indirect, exemplary or punitive damage or loss, and whether in contract, tort or otherwise;...
  • Page 35 PART VIII - TRANSFERABILITY This warranty is not transferable to any subsequent owner. PART IX - NOTICE - CUSTOMER OBLIGATIONS Your responsibility as a customer includes but is not limited to cleaning, lubricating, seasonal maintenance (e.g. winterizing), replacement of worn parts and all regular scheduled or unscheduled maintenance.

This manual is also suitable for:

E1050-20E1050-05E1050-20-05E1050-10E1050-20-10
