- Page 1 PV-100S User Manual 1/12...
-
Page 2: Main Features
PV-100S Overview Congratulations on purchasing the MPEG-4 Portable Video Recorder (for Security Surveillance Use).Now you can monitor and record anywhere you want from CCTV Camera with our Motion Detection Recording, Schedule Recording, Date & Time Stamped function. You can also view videos on the Windows Pocket PC with its recording format support. -
Page 3: Package Contents
PV-100S Package Contents MPEG-4 Video Recorder Power Adapter User Manual Remote Control 3-in-1 AV Cable (x2) 3/12... -
Page 4: Getting Started
Getting started PV-100S Following is the preliminary steps that required to set up the Recorder and make connections before starting to use the device. Instruction for installing the Remote Control Battery. 1. Push in the clip at the side of the battery holder . - Page 5 PV-100S Connect to the TV (Viewing only) Note : Connect the A/V connectors (red, white, and yellow) of the A/V cable, to the corresponding input connectors on the TV. Connect the other end to the AV Out socket at the back of the recorder.
-
Page 6: Connecting Power
PV-100S Connecting power Connect the power adaptor to the DC-in socket on the rear panel of the recorder. Plug the other end of the adaptor into a power outlet. Turning the MPEG-4 recorder on Once the recorder is plugged in, the green power LED turns on. -
Page 7: Hardware Components
PV-100S Hardware Components Front View Rear View 1. Power LED (Green) 2. Recording LED 3. IR Receiver 4. CF Card Slot 5. Memory Stick Pro SD Slot 6. DC Power 7. AV Out 8. AV In 7/12... -
Page 8: Remote Control
PV-100S Remote Control Function Key 1 Function Key 2 Power Menu Return/Stop Enter Record/Stop Function Key 1 : When you have two memory cards at the same time, you could switch/display its contents from two differents cards. Function Key 2 : Delete the files that is selected and highlighted. -
Page 9: Software Function
PV-100S Software Function V.Resolution : Set video format / modes while recording. V.Resolution options : 640x240 / 320x240 V.Quality : Set Video definition while recording. V.Quality options : HIGH / MID / LOW Manual Rec : Set video recording time. - Page 10 PV-100S Motion Rec : Motion detection recording. Motion Rec options : OFF / ON ļSelect “ON” before recording. Motion Setup : Choose detect ranges. ļUse the button to choose detect ranges ( Red frame indicates the detect ranges that be selected).
-
Page 11: File Browsing
PV-100S File Browsing The file browser allows you to view the contents of both SD and CF Memory Cards at the same time. Play – 1. Press the button on the Remote Control and choose PVR file. 2. Select the file (xxxx.ASF) that you want to view then press the button to play . -
Page 12: Safety Information
PV-100S Warning Information in this document has been carefully checked for accuracy; however, no guarantee is given as to the correctness of the contents. The information in this document is subject to change without notice. This document contains proprietary information protected by copyright.
