Thank you for purchasing our product.
Please read this User's Manual before
using the
product.
Change without Notice

4 Channel Digital Video Recorder

User's Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVR-0420TF and is the answer not in the manual?

Questions and answers

Related Manuals for Otima DVR-0420TF

Summary of Contents for Otima DVR-0420TF

  • Page 1: Channel Digital Video Recorder

    Thank you for purchasing our product. Please read this User’s Manual before using the product. Change without Notice 4 Channel Digital Video Recorder User’s Manual...
  • Page 2 Safety Precautions CAUTION RISK OF ELECTRICAL SHOCK. DO NOT OPEN ! CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK), NO USER SERVICEABLE PARTS REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This label may appear on the bottom of the unit due to space limitations. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of insulated dangerous Voltage within the product’s enclosure that may be...
  • Page 3 About this document Before installing stand alone DVR, be sure to thoroughly review and follow the instructions in this Users Manual. Pay particular attention to the parts that are marked NOTICE. Also, when connecting with external application, first turn the power OFF and follow manual instruction for appropriate installation.

  • Page 4: Play Button

    Unit Description of Front Panel : 4 quad screen mode button / Mode function key / 4 or 9 split display on playback mode : Channel 1 full screen button CHANNEL 1 : Channel 2 full screen button CHANNEL 2 : Channel 3 full screen button CHANNEL 3 : Channel 4 full screen button...
  • Page 5 Unit Description of Rear Panel Power code in 12V/5A, power switcher (ON / OFF) Camera 1 ~ 4 in and 75 Ohm ON/OFF (high/low adjust) looping out Audio channel input x 1 and output x 1 VG A Monitor out S-Video (Y/C) monitor VGA output.

  • Page 6: Installation

    Installation Procedure 1) Camera Connection Connect the camera to the CAMERA INPUT LEVEL VIDEO MONITOR on the Rear Panel of the 4 CH DVR. VIDEO LENS AC24V/DC12 Rear part of CAMERA 2) Monitor Connection (Composite Connection Method) Connect the monitor to the MONITOR OUT on MONITOR the Rear Panel of the 4 CH DVR.
  • Page 7 NOTICE: Sensor input is RECOGNIZED as LOW when alarm signal is on a level with GND, and it is recognized as HIGH when alarm signal is FLOATING or 5V. Following is internal circuit. Internal Circuit Thus, there is a danger of damage, when the sensor input goes to a Negative level or voltage higher than 5V. 5) HDD connection How to connect single HDD How to connect 2 HDD...
  • Page 8 Picture Full screen or quad screen display Press quad button to display 4 quad screen. Press numeric 1 / 2 / 3 / 4 buttons to display a desired camera image in full screen. 1.) FREEZE Mode 1. In live and the quad mode press (FREEZE) button to freeze image.
  • Page 9 6.) BACKUP / PIP. Image backup mode.(Image back up must be done on playback mode only.) Locate the playback point of which you want. Press BACKUP, the BACKUP CAUTION window pop-up. Press ENTER to begin data back up. Capacity of CF card is not limit, but the maximum capacity display is 9999MB. On playback mode, presses BACKUP: Lower-Right corner of the screen: ** BACKUP CAUTION **...
  • Page 10 7.) Alarm Sensor Recording >See the alarm recording setup page 8.) Scheduled Recording >See the scheduled recording setup page 9.) Motion detection Recording >See the motion detection recording setup page 10.) Key Lock function >On the Live or Playback mode, press (lock), Only, numeric, freeze, auto, pip, and zoom buttons could work.
  • Page 11 Playback 1. Playback Mode 1) Press button to begin playback. (System playback the images backward) PLAY 2. T-SRH button MAIN PLAY PAGE 1) T-SRH: Playback by time search. 1.MASTER TIME LIST Press T-SRH button to active playback function. 2.SLAVE TIME LIST 3.MASTER EVENT LIST Press direction button 4.SLAVE EVENT LIST...

  • Page 12: Event List

    2) EVENT LIST (Alarm List): Event source- Video loss / Alarm trigger / Motion / Record EVENT LIST NO Y / M / D H / M _ _ _ _ Motion 10 items display on each page / Total 5000 items display for 500 pages. When event list is out of compass, the total items are less then 5000.

  • Page 13: Function Setup

    FUNCTION SETUP LOGIN MENU 1) Press button to enter into menu. You could do the system function setup in MENU. 2) Password enter window pop-up: CHECK PASSWORD MENU Default password (Account-Admin) : 44444 Default password (Account-User) : 11111 PASSWORD (*****) 3) Press numeric (1 ~ 4 )button or remote controller ( 0 ~ 9 )to choose password.
  • Page 14 Basic Operation Press MENU button to enter MAIN SETUP PAGE. MAIN SETUP PAGE 1. HDD INFORMATION 2. DATE-TIME SETUP 3. DISPLAY SETUP 4. CAMERA SETUP 5. BUZZER SETUP 6. SYSTEM SETUP 7. ADVANCED SETUP MENU, ESC: EXIT, ENTER: RUN 1) Use direction button up/down button to select setup item.

  • Page 15: Hdd Information

    1. HDD INFORMATION MAIN SETUP PAGE POSITION SIZE USED BRAND 1. HDD INFORMATION 2. DATE-TIME SETUP MASTER 3. DISPLAY SETUP LAST TIME 4. CAMERA SETUP SLAVE 5. BUZZER SETUP LAST TIME 6. SYSTEM SETUP 7. ADVANCED SETUP MENU, ESC: EXIT, :PAGE MENU, ESC: EXIT, ENTER: RUN - 2 hard disk information display.
  • Page 16 2. DATE-TIME SETUP MAIN SETUP PAGE DATE-TIME SETUP PAGE 1. HDD INFORMATION 1. DATE 2000 / 00 / 00 2. TIME 2. DATE-TIME SETUP 3. DISPLAY SETUP 3. DISPLAY AT xx LINE(S) 4. CAMERA SETUP 4. DAYLIGHT SAVING 5. BUZZER SETUP 6.
  • Page 17 3. DISPLAY SETUP MAIN SETUP PAGE DISPLAY SETUP PAGE 1. HDD INFORMATION 1. DATE-TIME 2. DATE-TIME SETUP 2. CAMERA TITLE 3. PB DATE-TIME 3. DISPLAY SETUP 4. CAMERA SETUP 4. PB CAMERA TITLE 5. BUZZER SETUP 5. DVR STATUS 6. SYSTEM SETUP 6.

  • Page 18: Default Reset

    4. CAMERA SETUP MAIN SETUP PAGE CAMERA SETUP PAGE 1. HDD INFORMATION 1. COLOR SETUP 2. DATE-TIME SETUP 2. TITLE SETUP 3. DISPLAY SETUP 3. SCREEN POSITION SETUP 4. CAMERA SETUP 4. V-LOSS DISPLAY SETUP 5. BUZZER SETUP 5. VIDEO MASK SETUP 6.

  • Page 19: Title Setup

    (2.) TITLE SETUP: Input TITLE of each camera. 18 characters can be input. CAMERA-TITLE SETUP PAGE CH1 (CAM01 CAMERA SETUP CH2 (CAM02 1. COLOR SETUP CH3 (CAM03 2. TITLE SETUP CH4 (CAM04 3. SCREEN POSITION SETUP 4. V-LOSS DISPLAY SETUP 5.

  • Page 20: Screen Position Setup

    (3.) SCREEN POSITION SETUP **** SCREEN POSITION**** CAMERA SETUP 1. COLOR SETUP LEFT RIGHT 2. TITLE SETUP 3. SCREEN POSITION SETUP DOWN 4. V-LOSS DISPLAY SETUP ENTER for Default 5. VIDEO MASK SETUP ESC to QUIT Press direction buttons up/down/left/right to move screen position. 2.
  • Page 21 (4.) V-LOSS DISPLAY SETUP VLOSS SETUP PAGE **VLOSS FUNCTION: CH1 VLOSS DISPLAY CAMERA SETUP CH2 VLOSS DISPLAY 1. COLOR SETUP CH3 VLOSS DISPLAY 2. TITLE SETUP CH4 VLOSS DISPLAY 3. SCREEN POSITION SETUP 4. V-LOSS DISPLAY SETUP 5. VIDEO MASK SETUP MENU, ESC: EXIT: : MODIFY ** VLOSS FUNCTION: ON / OFF...
  • Page 22 (5.) VIDEO MASK SETUP VIDEO MASK SETUP PAGE CAMERA SETUP CH1 VIDEO MASK 1. COLOR SETUP CH2 VIDEO MASK 2. TITLE SETUP CH3 VIDEO MASK 3. SCREEN POSITION SETUP CH4 VIDEO MASK 4. V-LOSS DISPLAY SETUP 5. VIDEO MASK SETUP MENU, ESC: EXIT: : MODIFY CH1 VIDEO MASK: ON / OFF...
  • Page 23 5. BUZZER SETUP MAIN SETUP PAGE BUZZER SETUP PAGE 1. HDD INFORMATION **SYSTEM BUZZER 2. DATE-TIME SETUP BUTTON BUZZER 3. DISPLAY SETUP ALARM BUZZER 4. CAMERA SETUP MOTION BUZZER 5. BUZZER SETUP VLOSS BUZZER 6. SYSTEM SETUP 7. ADVANCED SETUP MENU, ESC: EXIT: : MODIFY MENU, ESC: EXIT, ENTER: RUN...

  • Page 24: Watermark Check

    6. SYSTEM SETUP MAIN SETUP PAGE SYSTEM SETUP 1. HDD INFORMATION 1. DWELL INTERVAL 2. DATE-TIME SETUP 2. LANGUAGE 3. DISPLAY SETUP 3. VIDEO INPUT 4. CAMERA SETUP 4. WATERMARK CHECK 5. BUZZER SETUP 5. RS-485 ID 6. RS-485 PROTOCOL 6.

  • Page 25: Advanced Setup

    8. ADVANCED SETUP MAIN SETUP PAGE 1. HDD INFORMATION ADVANCED SETUP PAGE 2. DATE-TIME SETUP 1. ALARM SETUP 3. DISPLAY SETUP 2. MOTION SETUP 4. CAMERA SETUP 3. RECORD SETUP 5. BUZZER SETUP 4. PASSWORD SETUP 6. SYSTEM SETUP 5. HDD FORMAT 6.

  • Page 26: Motion Setup

    2. MOTION SETUP MOTION SETUP PAGE **MOTION FUNCTION ON ADVANCED SETUP PAGE **MOTION DURATION 1. ALARM SETUP **CHANNEL NUMBER 1. SENSITIVITY 2. MOTION SETUP 3. RECORD SETUP 2. VELOCITY 4. PASSWORD SETUP 3. MOTION ACTIVE 5. HDD FORMAT 4. MOTION RELAY 6.

  • Page 27: Motion Area Setup

    > MOTION AREA SETUP < All area detect with factory default. Press quad button to change mode and then increase or reduce. For example: Clear lattices Press value change button to reduce. Add lattices Press value change button to reduce. Icon: Press to increase all area, press...

  • Page 28: Record Setup

    3. RECORD SETUP RECORD SETUP ADVANCED SETUP PAGE 1. HDD FULL 1. ALARM SETUP 2. RECORD SPEED 2. MOTION SETUP 3. RECORD MODE 4. RECORD AUDIO 3. RECORD SETUP 4. PASSWORD SETUP 5. QUALITY 5. HDD FORMAT 6. SCHEDULE SETUP 6.
  • Page 29 Additional: 2. RECORD SPEED. 1/30(1/30), 1/15(1/15), 1/10(1/10), 1/5 (1/5), 1/3 (1/3), 1/2 (1/2), 1(1), 2(2), 3(3.13), 5(5), 10 (8.33), 15(12.5), 30(25), 60(50), 120(100). -120 for the real time recording. When playback, it displays 30 frames per each channel on FULL screen, 15 frames per each channel on 4-split screen.

  • Page 30: Schedule Setup

    >SCHEDULE SETUP< RECORD SETUP 1. HDD FULL Press direction buttons up/down to 2. RECORD SCHEDULE SCHEDULE items. 3. RECORD MOTION 4. RECORD ALARM Press values change button to change values. 5. RECORD POWER ON 6. RESOLUTION Factory default is everyday all schedules time on >SCHEDULE SETUP<...
  • Page 31 30MIN SCHEDULE SETUP CURSOR STEP 00:00 01:00 02:00 03:00 04:00 05:00 06:00 07:00 08:00 09:00 10:00 11:00 12:00 13:00 14:00 15:00 16:00 17:00 18:00 19:00 20:00 21:00 22:00 23:00 00:30 01:30 02:30 03:30 04:30 05:30 06:30 07:30 08:30 09:30 10:30 11:30 12:30 13:30 14:30 15:30 16:30 17:30 18:30 19:30 20:30 21:30 22:30 23:30 00:00 01:00 02:00 03:00 04:00 05:00 06:00 07:00 08:00 09:00 10:00 11:00 12:00 13:00 14:00 15:00 16:00 17:00 18:00 19:00 20:00 21:00 22:00 23:00 00:30 01:30 02:30 03:30 04:30 05:30 06:30 07:30 08:30 09:30 10:30 11:30 12:30 13:30 14:30 15:30 16:30 17:30 18:30 19:30 20:30 21:30 22:30 23:30 00:00 01:00 02:00 03:00 04:00 05:00 06:00 07:00 08:00 09:00 10:00 11:00 12:00 13:00 14:00 15:00 16:00 17:00 18:00 19:00 20:00 21:00 22:00 23:00...

  • Page 32: Password Setup Page

    5. PASSWORD SETUP ADVANCED SETUP PAGE 1. ALARM SETUP PASSWORD SETUP PAGE 2. MOTION SETUP 1. LEVEL:( 3. RECORD SETUP 2. ADMIN:( 4. EVENT USER :( 5. PASSWORD SETUP 6. HDD FORMAT 7. FACTORY DEFAULT Press direction buttons up/down/left/right to LEVEL (Log In level ID type setup) Choose items position.

  • Page 33: Hdd Format

    6. HDD FORMAT ADVANCED SETUP PAGE Press direction buttons up/down to 1. ALARM SETUP HDD FORMAT items position. 2. MOTION SETUP Press ENTER to format all HDD. 3. RECORD SETUP 4. EVENT Caution: User can format HDD only when 5. PASSWORD SETUP all HDD stop record or playback.
  • Page 34 CF card data read on PC 1. CD folder, save setup.exe to PC hard disk or double click it. 2. Install Shield Wizard processing.
  • Page 35 3. Click Next. 4. Choose folder.
  • Page 36 5. After choose folder, click OK. 6. Click install to start.
  • Page 37 7. Installing 8. Click Finish...
  • Page 38 Start Program Video Viewer Video Viewer Click Local Search. Left key of mouse click Local Search.
  • Page 39 Choose folder Click folder. Choose new removable hard disk BACKUP.DVR file. OPEN.
  • Page 40 Start to playback Left key of mouse click play Icon: Folder Play Stop First Forward / Reverse Still playback...
  • Page 41 Picture capture save. (.JPG file saves.) Only camera full channel save, no quad pictures save. For example: Channel 1 .jpg save. Mouse click 1 channel once, then click mouse right button. Choose save as choose the folder you want to save. Type any file name you want, and then click save.
  • Page 42 Or choose save all. Save all cameras full channel picture. Choose folder and type file name.
  • Page 43 Click mouse left button, blue bar display. Click mouse right button to choose 1 ~ 4 cameras to change position. Icon function: Setting: Video Format: NTSC or PAL. Choose Codec: AVI encode format. Show Watermark: Water mark function on or off.
  • Page 44 Video Format: Chose NTSC or PAL. Choose Codec: File format. We strongly recommend user to choose Microsoft Windows Media Video 9. Confirm Cancel Information Half and Full screen choose and Record frame rate 1 ~ 30...
  • Page 45 Show Watermark: Water mark function or off. To check file has been modify or not. AVI file save: AVI button: AVI file save. Choose folder and type file name...
  • Page 46 Click save: Choose 1 ~ 4, and then click OK. Click OK, and then AVI red light on: Click play button to start record, Click AVI button to stop. AVI red light on, start to record.
  • Page 47 JPG file save: Help Choose folder and type file name Choose camera 1 ~ 4 or save all.
  • Page 48 Hard Disk Data Read 1. Take HDD out from DVR to personal computer. Make sure hard disk in PC is Master or Slave, switch hard disk jumper to Master or Slave. 2. Computer power on, do not need to BIOS setup, just login Windows system. 3.
  • Page 49 Hard Disk list on: Click here, hard disk list on. Click the correct DVR hard disk, data will not loose if choose wrong HDD. Click correct hard disk model, after function on, user can start to data read. Function access is same as prior pages.
  • Page 50 Record Time Table: 80GB HD Record Quality: Low. KB Range: Lowest: 13, Highest: 20. Average: 17. REC FPS REC Hour 21.7 21.7 43.5 87.1 130.7 REC FPS REC Hour 261.4 435.7 653.5 1307.1 2614.3 REC FPS 1/10 1/15 1/30 REC Hour 4357.2 6535.9 13071.8...
