General instructions and regulations
Use
All local regulations including those referring to national and European standards must be observed when installing
•
the appliance.
Ensure there is sufficient ventilation/air supply in the room where the stove is installed. Air extractors such as a
•
cooker hood may cause problems due to flue gases escaping from the stove into the room.
The appliance is not suitable for a shared flue system.
•
The appliance must be installed on a floor having sufficient bearing capacity.
•
Ensure adequate access for cleaning the appliance, the flue-gas connection and the chimney.
•
Safety instructions
•
Glass is quite susceptible to breaking and broken glass is quite sharp. Take appropriate measures.
•
For general safety, we refer to the VCA guidelines.
•
Note: After installation, ensure there is no inflammable and/or explosion-hazardous material in or on the stove such
as a spray can, packing material and the like.
Safety distances for Boxer Plus
•
Rear wall: 20cm. Temperature at safety test; 65°C.
•
Side wall: 40cm. Temperature at safety test; 77°C.
Specifications for Boxer Plus
•
Nominal power = 10 kWh.
•
Flue gas mass flow = 8.3 g/s
•
Appliance weight = 245 kg
•
Minimum chimney draught = 12 Pa
•
Flue gas temperature directly over the stove = 263 °C
Installation
To secure the warranty, the Boxer Plus must be installed by a properly qualified person employed by a dealer
•
recognized by Harrie Leenders Haardkachels. See leenders.nl for a current list of addresses of recognized
dealers or contact the manufacturer.
The stove is susceptible to scratching. Handle with care.
•
After installation, check the draught by burning some kindling wood.
•
1-6
Boxer Plus Manual, subject to change, October 2012. Harrie Leenders Haardkachels BV
Boxer Plus
Installation instructions • EN
Advertisement
Table of Contents
Related Manuals for Harrie Leenders Boxer Plus
Summary of Contents for Harrie Leenders Boxer Plus
- Page 1 Flue gas temperature directly over the stove = 263 °C Installation To secure the warranty, the Boxer Plus must be installed by a properly qualified person employed by a dealer • recognized by Harrie Leenders Haardkachels. See leenders.nl for a current list of addresses of recognized dealers or contact the manufacturer.
- Page 2 (sliding pieces, pieces of carpet, etc.) under the Boxer Plus. • Then fix the pipe and any connection to be made for air supplied from the floor or wall. • Finally remove the transport brace. Boxer Plus Manual, subject to change, October 2012. Harrie Leenders Haardkachels BV...
- Page 3 There is hardly anything that can resist a really hot fire. Your stove, too, could be damaged by overheating. To prevent this from happening, you must not burn more than 4 kg of dry wood at a time in your Boxer Plus. 4 kg equals roughly 4 solid oak- wood logs having a 15% residual moisture content.
- Page 4 Make sure you leave a layer of ashes (abt. 3 cm) for the next fire to be made. • When the weather is foggy, it is preferable not to use the stove since the draught in the flue will then be too low. Boxer Plus Manual, subject to change, October 2012. Harrie Leenders Haardkachels BV...
- Page 5 To remove soot/waste after the chimney has been swept, you can push the first baffle slightly up and slightly lift the second baffle. Any soot/waste still left on the second baffle can be removed using a vacuum cleaner. Boxer Plus Manual, subject to change, October 2012. Harrie Leenders Haardkachels BV...
- Page 6 Harrie Leenders Haardkachels Industrieweg 25, 5688 DP Oirschot, The Netherlands, hereby declares that the product Boxer Plus is in conformity with the provisions of the following EU Directives when installed in accordance with the installation instructions contained in the product documentation:...
