- Page 1 92-2619-01 Rev. B Performance Series Cutter Installation Guide...
-
Page 3: Warnings And Cautions
Safety Warnings and Cautions The following Warnings and Cautions are used throughout this manual: Warning: Warnings alert you to possible safety risks. Caution: Cautions alert you to the potential for equipment damage. General Safety Information Caution: This product is intended for indoor use only. All service procedures should be done by properly trained and qualified service personnel. - Page 4 2 | Safety Cutter Installation Guide...
- Page 5 Cutter Installation Guide Cutter and Tray Option Figure: 2 - 1 Cutter Assembly Figure: 2 - 2 Tray Assembly Note: Cutter Tray only available with the 4-inch model. Cutter Installation Guide...
-
Page 6: Safety Overview
Caution: ESD protection is required when performing these steps. Warning: The cover set may only be removed by a Datamax-O’Neil Authorized Service Center. Unauthorized service will void the manufacturer’s warranty. Warning: The printer must be powered off and disconnected from utility power prior to performing these procedures. - Page 7 Cutter Installation Guide | 2 Cutter and Tray Installation Procedure Warning: To prevent serious injury, never place a finger or object other than media near the cutter mechanism. Caution: Never cut paper or media in an area where adhesives exist. Doing so will damage the cutter and void the manufacturer’s warranty.
- Page 8 2 | Cutter Installation Guide 2. Loosen and remove the media plate captive screw and the media plate. Figure: 2 - 4 Remove Media Plate Note: Retain the captive screw for cutter installation. 3. Align the cutter with the power/data connector and install the captive screw to secure it to the platen carriage assembly.
- Page 9 Cutter Installation Guide | 2 4. Rotate the cutter until it magnetically locks into place. 5. Activate the cutter option in the Options menu by selecting Menu > Advanced > Printer > Options > Cutter. Note: Feed a label through the printer and observe the cut distance to ensure it cuts on the gap.
