- Page 1 Melife Technology Co., Ltd User Manual Model : T86+ WiFi Action Camera Made by: Melife Technology Co., Ltd Version: Melife-V1.0 - 1 -...
-
Page 2: Product Diagram
Melife Technology Co., Ltd Product Diagram A WiFi Activation (Down select) F POWER(and menu) B LED power indicator G USB interface C LCD screen H Micro SD card port D SHOOT (menu select) I Mini HDMI interface E Microphone J Removable Li-Battery... -
Page 3: Remote Diagram
Melife Technology Co., Ltd Left Side Right Side Remote Diagram Please note: with the remote controller you cannot turn the camera on. Please ensure the camera is switched on before using the remote. A LED Indicators B Shoot Photo C Record Video... - Page 4 Turn the camera on- press and hold the POWER button for several seconds. When the camera is on, the Melife logo will appear on the screen and the three red LED lights will glow red. The camera is now in video mode.
- Page 5 Melife Technology Co., Ltd Red LED light Red LED light Red LED light - 5 -...
-
Page 6: Video Mode
Melife Technology Co., Ltd Video Mode Video mode screen Once the camera is turned on, it goes to the video capture mode by default. Press SHOOT button to start recording. When the recording starts, you will see the red lights start flashing. To end recording, press the SHOOT button again. -
Page 7: Video Settings
Melife Technology Co., Ltd Video Settings Video Settings Screen This allows user to adjust Video quality settings. Navigation: Use WiFi button to navigate, SHOOT button to Enter/Confirm selection, POWER button to go back. Resolution This allows user to set the recording video resolution: ... -
Page 8: White Balance
Melife Technology Co., Ltd 5 Mins- In this mode, camera will generate new file on every 5 mins White Balance Factory default is Auto. If you switch Auto OFF, remember to adjust when lighting conditions change. Following pre-set modes are also availableDaylight, Cloudy, Tungsten,... -
Page 9: General Settings
Melife Technology Co., Ltd General Settings General Settings Screen (Page 1) This allows user to adjust the general device settings To enter General Settings, enter the Settings menu first by pressing POWER button, then press and hold the SHOOT button for 3secs Navigation: Use WiFi button to navigate, SHOOT button to Enter/Confirm selection, POWER button to go back. -
Page 10: Light Frequency
Melife Technology Co., Ltd Date & Time This allows user to adjust the date &time. Note: Use the WiFi button to change the date and time, use SHOOT button to confirm. The date is entered in Year/Month/Day format. Time is based on a 24hr clock. -
Page 11: Time Lapse
Melife Technology Co., Ltd Time lapse This feature allows you to set the intervals/frequency at which a frame is captured. You can set the time Frequency here System Factory Reset; to reset the camera to factory default. System Info; to check the firmware version ... -
Page 12: Picture Mode
Melife Technology Co., Ltd General Setting Screen (Page 3) Format This is to format the card. Choosing to format the card will permanently erase all data on the card. Picture Mode This mode will allow users to take snapshots Picture Mode Screen... -
Page 13: Picture Settings
Melife Technology Co., Ltd Picture Settings Picture Setting Screen 1 To enter the SETUP menu for Picture Mode, press POWER button (press and release immediately-if it is held too long the camera will switch off). Resolution To select the image resolution... - Page 14 Melife Technology Co., Ltd lighting conditions change. Picture Setting Screen 2 This is the measurement of how sensitive a digital camera’s sensor is to light. Exposure This allows user to set the light exposure value Self-timer This allows user to set the timer for auto image capture Date Stamp ...
-
Page 15: Charging The Battery
Melife Technology Co., Ltd Using Your T86+ Preparation Charging the battery Before using the T86+ for the first time you should fully charge the battery. Procedure: 1. Connect T86+ to a computer (or other USB power source) using the USB cable (provided). -
Page 16: Video Recording
Melife Technology Co., Ltd There is only one correct direction to insert the Micro SD card into the slot. Do not force the card into the card slot, as it may damage both the camera and the card. It is recommended to format new cards of cards that have been previously used in other cameras. -
Page 17: Playback Mode
Melife Technology Co., Ltd Playback Mode Navigation: Use WiFi button to navigate, SHOOT button to Enter/Confirm selection, POWER button to go back. This will allow you to watch the captured videos & images. Enter the Picture mode first, then press and hold the SHOOT button for 3secs. - Page 18 Melife Technology Co., Ltd Connect Mini HDMI end to the port on camera and HDMI end to HDMI port on the TV Select the right source on the TV Turn the camera on WiFi Setup The T86+ allows full camera control, live previewing and playback of photos/videos on most Smart-phones and Tablets.
-
Page 19: Saving And Viewing Options
Melife Technology Co., Ltd Note: You can change the WiFi password in the menu setting. 6.Open the app “iSmart DV” Important: Before connecting camera via WiFi , you need to download the “iSmart DV” App on your smart phone or tablet. -
Page 20: Specifications
Melife Technology Co., Ltd Micro SD card and use a card reader (not included) to achieve the same result. 1.Select the file(s) you want to transfer to your computer by highlighting them. 2.Either drag the files to the desired place on your computer (this will make a copy of the file on your computer) OR right-click the file, select “Copy”... -
Page 21: System Requirements
Melife Technology Co., Ltd Video: 1080p@60fps, 1080p@30fps, 720p@120fps, 720p@60fps Resolution Still photo: 8 megapixels (12 megapixels interpolated) Storage type Micro SD card up to 32GB (not included) Lens 150°-view fixed lens Lens aperture F/2.8 Lens focus 0.5m to infinity Shutter speed... -
Page 22: What's In The Box
Melife Technology Co., Ltd The Manufacturer hereby declares that the CE marking was applied to T86+ in accordance with the basic requirements and other relevant provisions of the following CE Directives: 2011/65/EC RoHs Directive 2004/108/EC Low Voltage Directive 1999/5/EG R&TTE Directive... -
Page 23: Safety Precautions
Do not attempt to open the case of the camera or modify it in any way. If the camera has been opened, the warranty will be void. Maintenance and repairs can only be performed by Melife. Keep the camera away from water and other liquids (unless used in the waterproof case). - Page 24 Melife Technology Co., Ltd malfunction. Recharge the battery using the micro USB Connector. Any variation to voltage or current will cause the camera to fail. The T86+ should not be used if outside the temperature range of -10℃~ 60℃ (14℉~140℉).
