- Page 1 User Manual Model : T96 WiFi Action Camera Made by: Melife Technology Co., Ltd Version: Melife-V1.0 - 1 - Melife Technology Co., Ltd...
-
Page 2: Key Features
1080p@30fps, 720p@120fps, 720@60fps. Image resolution: 12.4MP Support WiFi connection, range up to 15 meters Support 2.4G Wireless remote control Bundle with waterproof case can support underwater 30m 2” TFT LCD screen 3.7V/1000mAh Detachable Lithium-ion battery - 2 - Melife Technology Co., Ltd... - Page 3 3M adhesive for curved mount x 1 Waterproof case x 1 Quick release mount x 1 Portable case x 1 USB Cable x 1 Curved mount x 1 Knuckle x 1 Flat mount x 1 Lock bolt x2 - 3 - Melife Technology Co., Ltd...
-
Page 4: Camera Diagram
3. Camera Diagram - 4 - Melife Technology Co., Ltd... -
Page 5: Using Your Camera
There is only one correct direction to insert the Micro SD card into the slot.. Do not force the card into the card slot, as it may damage both the camera and the Micro SD card. A new Micro SD card should be formatted before using. - 5 - Melife Technology Co., Ltd... -
Page 6: Recharge The Battery
4.3 Recharge the battery Before using the T96 for the first time, please fully charge the battery first. Procedure: 1. Connect T96 with chargers or devices by Micro USB cable (provided). 2. Recharging Indicator will turns red during recharging. 3. A completely flat battery will take about 3.5 hours to be fully charged. The battery icon at the right bottom is full when the battery is fully charged. - Page 7 5. Setup your camera 5.1 Video Mode Press "POWER" button once to go into Video mode setting. Resolution UHD P24, QHD P30, FHD P60, FHD P30, HD P120, HD P60 are for your choose. - 7 - Melife Technology Co., Ltd...
-
Page 8: Recording Interval
Off, 1Second, 5Seconds, 10Seconds, 30Seconds, 1 Minute, 5 Minutes, 10 Minutes. Stabilization Open this function will start built-in Gyroscope to make the video shooting more steadily, less shaking. - 8 - Melife Technology Co., Ltd... -
Page 9: White Balance
Users can adjust it when the lighting condition changed, Auto, Daylight, Cloudy, Tungsten, Fluorescent. Default mode is Auto. Color Mode Users can choose different color mode from options including Normal, Black&White, Sepia, Dive Mode Metering Users can choose Average, Center, Spot - 9 - Melife Technology Co., Ltd... -
Page 10: Record Audio
You can display the time and date on video or not. Off: not display date on videos Date: display date on videos 5.2 General Setting Press and hold “SHOOT” button to switch from Video mode setting to general setting. - 10 - Melife Technology Co., Ltd... -
Page 11: Screen Save
3 Minutes: The camera will be off after 3mins; 5 Minutes: The camera will be off after 5mins; 10 Minutes: The camera will be off after 10mins; Beep Sound Off: Turn the key tone off. On: Turn the key tone on. - 11 - Melife Technology Co., Ltd... - Page 12 TV Mode Select the NTSC or PAL to suit your TV system. TV Out Users can choose OFF or ON. Frequency Select correct light frequency to avoid strobing, options including 50Hz or 60Hz. - 12 - Melife Technology Co., Ltd...
-
Page 13: Default Setting
Note: Use the WiFi button to navigate, use SHOOT button to confirm. The name is showed as “WIFI_ T96_XXXXXX”, you can change the WIFI SSID which is displayed with cycle letters or numbers, such as “A-Z” “a – z” “1 -0”. - 13 - Melife Technology Co., Ltd... -
Page 14: Wifi Password
You can change the WIFI password which is displayed with cycle letters or numbers, such as “A-Z” “a – z” “1 -0”. Use the WiFi button to navigate, use SHOOT button to confirm. - 14 - Melife Technology Co., Ltd... -
Page 15: Picture Mode
Capture Mode Single: Shoot a single picture; 2S Timer: Shoot a single picture every 2 seconds; 5S Timer: Shoot a single picture every 5 seconds; 10S Timer: Shoot a single picture every 10 seconds; - 15 - Melife Technology Co., Ltd... - Page 16 If on, the camera will continuously shoot pictures automatically. If off, normal picture shooting, press “SHOOT” button once to shoot a single picture. Quality To set the image quality from Fine, Normal, Economy. - 16 - Melife Technology Co., Ltd...
-
Page 17: Color Mode
Strong, Standard, Low.. White Balance You can adjust it when the lighting condition changed, Auto, Daylight, Cloudy, Tungsten, Fluorescent. Default mode is Auto. Color Mode Setup different color mode from Normal, Black&White, Sepia, Dive mode. - 17 - Melife Technology Co., Ltd... - Page 18 This allows user to set the light exposure value, +2/3, +1/3, +0.0, -1/3, /2/3, -1.0, -4/3, -5/3, -2.0. Stabilization Open this function will start built-in Gyroscope to make the video shooting more steadily, less shaking. - 18 - Melife Technology Co., Ltd...
-
Page 19: Quick Review
Date Stamp You can display the time and date on pictures or not; Off: not display date & time on pictures; Date: display date on pictures Date/Time: display date & time on pictures. - 19 - Melife Technology Co., Ltd... -
Page 20: Remote Control
Photo Button: Press once to take a single picture. Video Button: Press once to start recording a video,press again to stop. Power Button: Press and hold for 4 seconds to turn off the camera. - 20 - Melife Technology Co., Ltd... - Page 21 The camera will turn on automatically, and shows two options, “ Mass Storage” & “ PC Camera”, then choose PC Camera. Use the WiFi button to navigate, use SHOOT button to confirm. - 21 - Melife Technology Co., Ltd...
-
Page 22: App Download
Android users can download Apps by searching “T96 DV” in Google Play Store. Apple Users Apple users can download Apps by searching “T96 DV” in Apple App Store. 7. Data Transfer 7.1 Connect with TV You can playback captured videos and pictures on TV via a Micro HDMI cable. -
Page 23: Reset The Camera
Do not attempt to open the case of the camera or modify it in any way. If the camera has been opened, the warranty will be void. Maintenance and repairs can only be performed by Melife. - 23 - Melife Technology Co., Ltd...
