Panasonic DVD-LS80P Service Manual

Portable dvd/cd player
Table of Contents

Advertisement

Quick Links

Specifications

Operating temperature
range:
Operating humidity range:
Region number:
Discs played
[8cm (3") or 12cm (5")]:
+5 to +35°C (+41 to +95°F)
5-85% RH (no condensation)
Region No.1
DVD [DVD-Video, DivX(*6,8)]
DVD-RAM [DVD-VR(*9),
JPEG(*4,6,7), MP3(*2,6),
MPEG4(*5,6), DivX(*6.8)]
DVD-R [DVD-Video, DVD-VR(*9),
JPEG(*4,6,7), MP3(*2,6),
MPEG4(*5,6), DivX(*6.8)]
DVD-R DL [DVD-Video, DVD-VR(*9)]
DVD-RW [DVD-Video, DVD-
VR(*9),JPEG(*4,6,7), MP3(*2,6),
MPEG4(*5,6), DivX(*6.8)]
+R/RW (Video)
+R DL (Video)
CD, CD-R/RW [CD-DA, Video-CD,
SVCD(*1), MP3(*2, 6), WMA(*3, 6),
JPEG (*4,6,7), MPEG4(*5,6),
DivX(*6.8),HighMAT Level 2 (Audio
and Image)]
*1: Conforming to IEC62107
*2: MPEG-1 Layer3, MPEG-2 Layer3
*3: Windows Media Audio Ver9.0 L3.
Not compatible with Multiple Bit Rate
(MBR)
Portable DVD/CD PLAYER
RAE1909Z-C Mechanism Series
Colour
(S).................Silver Type (LS82)
(K).................Black Type (LS80/LS850)
Signal system:
LCD screen:
Composite-video output/
input:
© 2007 Matsushita Electric Industrial Co., Ltd. All
rights
reserved.
distribution is a violation of law.
ORDER NO.CHM0703008CE
*4: Exif Ver 2.1 JPEG Baseline files
Picture resolution: between 160×120
and 6144×4096 pixels (sub sampling
is 4:0:0, 4:2:0, 4:2:2 or 4:4:4)
*5: MPEG4 data recorded with the
Panasonic SD multi cameras or DVD
recorders.
Conforming to SD VIDEO
specifications (ASF standard)/MPEG4
(Simple Profile) video system/G.726
audio system.
*6: The total combined maximum
number of recognizable audio, picture
and movie contents and groups:
4000 audio, picture and movie
contents and 400 groups.
*7: Extremely long and slender
pictures may not be displayed.
*8: Plays all versions of
(including
6) with standard
playback of
media files.
Certified to the DivX Home Theater
Profile.
*9: CPRM doesn't cope with it.
NTSC
8.5"
-Si, TFT wide-screen LCD
Unauthorized
copying
B12
video
and
