INSTALLATION M-ALL MDVR-2012_Q2_Ver 1.0

Installation Manual

For
ALL MDVRs
Mobile Digital Video Recorder
1/30

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MDVR Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Premier Hazard MDVR Series

  • Page 1: Installation Manual

    INSTALLATION M-ALL MDVR-2012_Q2_Ver 1.0 Installation Manual ALL MDVRs Mobile Digital Video Recorder 1/30...
  • Page 2: Table Of Contents

    INSTALLATION M-ALL MDVR-2012_Q2_Ver 1.0 Table of Content NOTICE ................................. 3 Installation General Instruction ..........................4 Part 1 MDVR Device Installation .......................... 5 Pre-Installation Preparation ..........................5 Technical Requirement........................... 5 Installer and Supervisor Qualification ...................... 5 Pre-installation Investigation and Installation Plan Making ................ 5 Reference Installation Tool ........................
  • Page 3: Notice

    INSTALLATION M-ALL MDVR-2012_Q2_Ver 1.0 NOTICE Before you install the MDVR system in the vehicle, please be familiar with this system and read this manual carefully. Meanwhile the whole installation process must be guided by the professional persons. MDVR is electronic recording and storage system which must be delivered very carefully. Use only a regular 12-volt DC or 24-volt DC (3 ~ 5 Amps) certified power supply for installation in vehicles.
  • Page 4: Installation General Instruction

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 Installation General Instruction Before install the recorder system and accessories, the most important is to know the vehicle construction especially for power. Please check following: Which MDVR model and accessories will be installed? In which part of the vehicle can install the MDVR? How big the size is? Cables and installation tools (for example: electric drill, screw driver, screws, multimeters etc…) Manpower distribution General concept for wiring...
  • Page 5: Part 1 Mdvr Device Installation

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 Part 1 MDVR Device Installation Pre-Installation Preparation Technical Requirement Be familiar with the MDVR device functions and application Be familiar with the whole MDVR solution Be familiar with the vehicle electrical circuit, vehicle structure and installation skills. Installer and Supervisor Qualification Supervisor Qualification and responsibility 1.
  • Page 6: Reference Installation Tool

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 Reference Installation Tool Item Name Photo Specification Function Remark Drill the holes Electric Drill To drill the hole in the vehicle to get the Drill bit 12mm power cable out getting the power for the MDVR. To drill the hole for Drill bit 2.8mm cameras, monitor...
  • Page 7: Mdvr Device Installation

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 Insulating for wrapping up the tape wires soldering iron for welding Tin Bar Diagonal for cable connecting Pliers Crimping for cable connecting Pliers Scissors shrinkable tube cut shrinkable tube Heat Gun encapsulation Glass glue for hole sealing and fixation.
  • Page 8: The Hard Disk Installation

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 a) Anti-vibration: The MDVR device must be installed the place with week vibration (for example: behind the driver’s seat). Installing the MDVR on the rear of the vehicle with strong vibration or closing to the engine is forbidden. b) Ventilation: The MDVR device must be far away for the heating source in the vehicle.
  • Page 9: The Power Connection

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 2.2.2 The Power Connection The power supply is the basic and critical for MDVR device working. The connection and wiring is very rigid for installation. 1) The MDVR power must be provided by the battery of the vehicle. It must be connected with the positive and negative polarity of the battery directly (Below left diagram).
  • Page 10 ISTM-ALL MDVR-2012_Q2_Ver 1.0 Fuse Device to control the ignition of vehicle The ACC signal cable MDVR power input positive polarity(red) (yellow). Positive MDVR power input negative polarity The voltage polarit Negative polarity is ≥7.5V The lock for removable hard disk case (lock it before booting up the MDVR) Vehicle Battery Mobile DVR...
  • Page 11: How To Choose And Install Cameras

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 ACC cable requirements (1) ACC wire working principle Actual wire: red is positive, black is negative, yellow is ignition signal. The MDVR device does not work if yellow ignition signal wire is connected ground or nothing. Make sure ACC voltage is higher than 7.5V (Please test the voltage before connection) before booting up the MDVR system for ensuring normal operation.
  • Page 12 ISTM-ALL MDVR-2012_Q2_Ver 1.0 (1) The camera should be far away from heat source and electromagnetic interference in the vehicle. (2) The installation point should be safe avoiding camera damaged humanly. (3) How many cameras should be installed is depends on the vehicle size. Please make sure the camera (4)...
  • Page 13 ISTM-ALL MDVR-2012_Q2_Ver 1.0 MDVR Driver’s seat Rear Door Front Door 4) The Installation Photos for Reference Mainly the installation point for camera is really depends on different vehicle and different application. Here please see some photos for reference. 13/30...
  • Page 14 ISTM-ALL MDVR-2012_Q2_Ver 1.0 rear camera For police car, taxi or some other vehicles, the camera installation point will be different. Here are some photos for reference. Install 2 cameras on the roof of the police car For taxi installation The PTZ for police car application 14/30...
  • Page 15: Antenna (Gps/Wifi/3G) Connection

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 Antenna (GPS/WIFI/3G) Connection For the products with WIFI, GPS, 3G functions, the antenna will be shipped with the MDVR together to customers. 3G Antenna WIFI Antenna Built-in GPS Antenna External GPS Here are some tips for antenna connection and fixation: (1)...
  • Page 16 ISTM-ALL MDVR-2012_Q2_Ver 1.0 The WIFI antenna near dash mounted panel in bus 3) How to Connect GPS Antenna GPS should be installed on the roof of vehicles for good reception of satellite signals. If drilling the hole on the vehicle roof is forbidden, then please try to get the GPS cable outside of the vehicle (please put the cable hidden)).
  • Page 17: Monitor Installation

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 6) Installation Tips: (1) The WIFI antenna must be fixed by the glass cerement and the WIFI antenna bottom plane must be parallel with the vehicle roof. Standing or side installation are not allowed. (2) GPS antenna should be installed in open air on top of vehicle, The bottom plane must be parallel with the vehicle roof and fixed by glass cerement.
  • Page 18 ISTM-ALL MDVR-2012_Q2_Ver 1.0 In MDVR GUI, you can setup different sensor inputs as following. You can define any or the sensor inputs to be different function. For example, if you define sensor 1 is for panic button please connect panic button with sensor 1 signal on the alarm box (the photo is below).
  • Page 19: How To Connect Alarm System

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 Alarm output 24V/12V How to Connect Alarm System Alarm system (we say panic button as well) is one of the MDVR I/O sensor input function. This function is used to deal with some emergency. For example if some accidents happens, the driver or the passengers can press the button to trigger the alarm video to centre server by 3G network.
  • Page 20 ISTM-ALL MDVR-2012_Q2_Ver 1.0 2) The Photos for Reference Alarm System for Passengers Signal wire of this alarm button is 4*0.2 wires. The wiring diagram as picture below: Pin 2: Power Positive polarity………Red Pin 4: Power negative polarity……..Black Pin1: Alarm input…………………..Green 20/30 Pin3: Alarm output…………………White...
  • Page 21: How To Deal With The Connection For Cables And Wire

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 Generally the alarm system for passenger are installed near by the passenger and the wiring should go with the air-conditioner. Different vehicle has different internal environment. Every vehicle should have the suitable installation method. Here introduce the installation steps for the vehicle with air-conditioner: (1)...
  • Page 22: Mdvr Device Testing

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 MDVR Device Testing Inspection before Power Connection After all the equipments are installed, please follow the steps to check before power supply for MDVR: Wiring Inspection (1) Cable wiring should be cross-vertical strokes, orderly to keep the vehicle clean and safe (2)...
  • Page 23: Accessories Testing

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 (4) Check the image from the monitor (5) Check the MDVR output voltage is normal or not (12V,5A) (6) Check the firmware version, communication module and GPS module if the signal is strong or not. (7) HDD format. After formatting, the MDVR system will reboot up. After that, please check the REC LED on the front panel of the MDVR to ensure that MDVR can record.
  • Page 24: I/O Sensor Testing

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 1.4.2 I/O Sensor Testing Please enter into the MDVR GUI and select the function “Sensor” (Setup Event Sensor). Select "ON“ or “OFF” for enable option. Define the name according to sensor connected. EN: Enable, to active this function NAME: Press ENTER on the Name field to display the soft keyboard.
  • Page 25: Vehicle Speed And Pulse Testing

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 Get the video files embed the I/O sensor information and playback on the PC software. Check whether the data is correct. If the MDVR system support wireless transmission, please check the alarm report to CMS as well. 1.4.3 Vehicle Speed and Pulse Testing Please connect the SPEED-A on the alarm box with the vehicle speed signal cable and the GND on the alarm box to...
  • Page 26 ISTM-ALL MDVR-2012_Q2_Ver 1.0 If you cannot find out the GPS and network information here, please check following: 1) Whether the antenna connection is correct 2) Whether you setup the right parameter for network 3) The SIM card inserting is correct or not 4) Does the SIM card support huge data transfer (Note: Some of the SIM card are just used for cell phone service, not for data transmission) 1) GPS function setting...
  • Page 27: 1.4.5 Software Upgrade

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 GPS location debugging: Enter into the OSD interface to check the longitude and latitude. 2) Internet function Testing ( local IP.WIFI,3G) For the details please check the Streamax CMS and 3G connection manual. 1.4.5 Software Upgrade Create a folder named ‘dvrupgrade’ in the thumb drive and then copy the firmware upgrade file to this folder.
  • Page 28: Setup Machine Registration Information

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 1.4.6 Setup Machine Registration Information Please check the details in the MDVR GUI manual 1.4.7 Storage Format (HDD or SD Card) Format the storage before using or replacing the storage. Please check the details from the ,DVR GUI manual. Appendix 28/30...
  • Page 29: Bus Application

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 Bus Application 29/30...
  • Page 30: The Table For Bandwidth And Frame Rate

    ISTM-ALL MDVR-2012_Q2_Ver 1.0 The Table for Bandwidth and Frame Rate. BitRate GOP Size Frame Rate (Frms/S) (Kbps) Default: P(N) Range: P(N) Default Range 50(60) 25-100(30-120) 50(60) 25-100(30-120) 50(60) 25-100(30-120) 50(60) 25-100(30-120) 50(60) 25-100(30-120) 5-11 50(60) 25-100(30-120) 5-12 50(60) 25-100(30-120) 5-12 50(60) 25-100(30-120) 6-13...
