Foxun SX-MX88-3DCAT Quick Start Manual

Hdmi matrix 8x8 built-in wifi
Hide thumbs Also See for SX-MX88-3DCAT:

Advertisement

Quick Links

Download this manual
HDMI Matrix
8x8 built-in WiFi
SX-MX88-3DCAT
Features
•Any eight Sources to Any eight Displays,Each port supports HDMI or DVI inputs.
•Transmission distance up to 50m under 1080P@60Hz over Single Cat5e or Cat6 cable.
•Transmission distance up to 30m under 1080P@60Hz over double Cat5e or Cat6 cable.
•The HDMI input is compensated, clock/phase adjusted and jitter free so all the user sees is
a high quality HDMI signal.
•Independent switch able EDID function for choosing which resolution to display.
•Support high definition resolutions 1080p, 1080i, 720p and other standard video formats.
•Supports LPCM 7.1 channel output from each of the independent HDMI ports.
•Switching modes: panel buttons, local IR, RS232 and Smart phone.
•Support HDCP .
•1U'srack design for easy installation.
•Support 3D.
•With WIFI .
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SX-MX88-3DCAT and is the answer not in the manual?

Questions and answers

Related Manuals for Foxun SX-MX88-3DCAT

Summary of Contents for Foxun SX-MX88-3DCAT

  • Page 1 HDMI Matrix 8x8 built-in WiFi SX-MX88-3DCAT Features •Any eight Sources to Any eight Displays,Each port supports HDMI or DVI inputs. •Transmission distance up to 50m under 1080P@60Hz over Single Cat5e or Cat6 cable. •Transmission distance up to 30m under 1080P@60Hz over double Cat5e or Cat6 cable.
  • Page 2 TABLE OF CONTENTS Packing contents Package Contents 1) Main Unit: 8x8 HDMI Matrix Dimensional drawing 2) Power supply DC 12V 4A Speci cations 3) Remote Controller Panel Descriptions 4) IR-RX cable x 1PCS Connecting and Operating 5) M3x5 Screw x 8PCS Typical Application 6) Operating Instructions Maintenance...
  • Page 3 -5 to +35 C(+23 to +95 5 to 90%RH (No Condensation) 225MHz/6.75Gbps Up to 1080p@60Hz@24 b/pixels, support 3D HDMI receptacle. Power connector terminal Power DC receptacle IR Extender RJ45 receptacle 1080P 30m over Dual Cat5e/6 cable 1080P 50m over single Cat5e/6 cable 110-240V/ 12VDC power supply 24Watts Cold-Rolled (Cold Rolled) Steel...

  • Page 4: Connecting And Operating

    ALL: Press this button to set all the outputs to display with the same input. frist pressing the “All”button then press an input number to confirm the selection. D/S: Press this button to Double LAN cable mode and press it again to single LAN cable mode. WIFI: This slot is used to install the antenna.

  • Page 5: Operation

    Operation 8-8 D 1. Front panel control The HDMI matrix front panel control switching inputs to the various outputs. There are four groups of LEDs for each output port. The LED lit on the position means that the output port selects this input as its source. 2.
  • Page 6 2.1 Receive Window The “receive window” will show the message received from matrix. When you click the Control Buttons (see step 4) or send Control Command (see 2.3) to matrix, it will send out the message about “operation results” as right: 2.2 Status Button Click this button to read the status of Matrix.
  • Page 7 4 Setting Button Click this button to enter Setting menu. If the signal is not stable, please turn on the HDMI long cable mode. 4.1 EDID Set button Select the Output Port in “Port Select” column, click “Read EDID” button to get EDID from display equipment.
  • Page 8 5.Android OS control 5.1 Install android apk(Matrix88.apk) 5.2 Connect device Set the Wifi in your phone/ pad, run “matrix 88” , input equipment Wifi module’s IP address (10.10.100.254), then click “connect” to enter. Main menu...
  • Page 9 6.IOS control 6.1 Go to “App store ”， search “Matrix88” ,download and install the APP. 6.2 Connect device Set the Wifi in your iPhone/iPad ,run “Matrix88”, input equipment WIFI module’s IP address (10.10.100.254) ,then click “Button” to enter. Main menu...
  • Page 10 RS-232 pin assignment HDMI Matrix Remote Control Console Assignment Assignment...

  • Page 11: Hdmi Matrix

    HD camera IPTV Blue-ray player Xbox HDMI matrix HDMI cable Dual Cat5e/6 cable...
  • Page 12 RS-232 Commands command feedback description cir_0x\r\n 63 69 72 20 30 xx 0D 0A Output 1 select input 1~8 “x” : indicate the input port, range from 0~7. “y” : indicate the input port, range from 1~8. cir_1x\r\n 63 69 72 20 31 xx 0D 0A Output 2 select input 1~8 “x”...
