3. INSTALLATION
3.1 Unpacking
The following is included with each D Series Modem:
•
Modem and external 120 VAC power supply
• Cable for connection to phone line
•
Manual
• Information regarding warranty, maintenance contracts and
repair
3.2 Setup For Use With SR Series Multiplexers
To configure your SR Multiplexers to work with external DCB dial-
up modems first connect the modems to the multiplexers using the
Modem to Composite cable supplied. Next attach a terminal or PC to
the SR Network Management Port using the green cable and the
appropriate adapter (supplied). Set the terminal for 9600 8,N,1.
When you see "AT YOUR COMMAND >>", follow the instructions
below. User responses are shown in BOLD.
5
